Enclume LR7 Instruction manual

Enclume HEARTH RACK

LR7

Quality, design, strength and function.

Congratulations for owning one of the finest

Storage racks made.

WARNING:

READ ALL OF THE INSTRUCTIONS

BEFORE ASSEMBLING AND USING

YOUR RACK.

All of our hammered steel racks are finished with an industrial wax designed to

give years of protection to the rack. Cleaning is easily done with a damp cloth. Dry

thoroughly after cleaning. If a touch-up is ever needed we recommend a "Pledge"

like wax product.

Enclosed you will find everything needed for the assembly

and use of your storage rack. Two people make assembly

and installation easier. The parts and hardware included are:

Hardware included:

4 – 3/8” x 5/8” Button head screws

1 – 7/32” Allen wrench

4 – Hard floor glides

Components included:

2 – Upright body pieces

2 – Legs

See reverse side for ASSEMBLY AND INSTALLATION INSTRUCTIONS

Limited Warranty:This product is warranted to be free of material defects for a period of five years from the date of purchase. Customer's exclusive remedy shall

be the repair or replacement of the defective product and shall be subject to the following conditions: (1) notice of any defect is received by Enclume within the

warranty period and (2) customer returns the defective product to Enclume Design Products, Inc. , 24 Colwell St.. , Port Hadlock, WA 98339, postage prepaid

within 20 days following a return authorization number (which may be obtained by telephoning the number at the bottom of this instructions) being provided to the

customer by Enclume. There are no other warranties, expressed or implied. THERE ARE NO WARRANTIES OF MERCHANTABILITY OR FITNESS

FOR A PARTICULAR PURPOSE. ENCLUME SPECIFICALLY DISCLAIMS ANY AND ALL INCIDENTAL OR CONSEQUENTIAL DAMAGES

ARISING OUT OF THE PURCHASE OR USE OF ENCLUME'S PRODUCTS.

If you need help, please call 1-877-ENCLUME

Enclume Design Products, Inc.

24 Colwell Street, Port Hadlock, WA. 98339

Phone 360-385-6100 •Fax 360-385-6156

www.enclume.com

NorthlineExpress.com www.NorthlineExpress.com Toll-FreeToll-Free 1-877-734-2458

NorthlineExpress.com www.NorthlineExpress.com

ASSEMBLY AND INSTALLATION INSTRUCTIONS for LR7

Enclosed you will find everything needed for the assembly

and use of your storage rack. Two people make assembly

and installation easier. The parts and hardware included are:

Hardware included:

4 – 3/8” x 5/8” Button head screws

1 – 7/32” Allen wrench

4 – Hard Plastic floor glides

Components included:

2 – Upright body pieces

2 – Legs

ASSEMBLY AND INSTALLATION INSTRUCTIONS

Rack Assembly

1) Slip the floor glides over the ends of the legs.

2) Place the two upright body pieces on top of and perpendicular to the legs. Using the Allen wrench and the four 3/8” x 5/8”

button head screws, attach the legs and the uprights together. The screws should be inserted from the top down toward the

floor. Tighten the screws only finger tight.

3) Square up your rack and tighten all the screws firmly.

4) All of our hammered steel racks are finished with an industrial wax designed to give years of protection to the rack.

Cleaning is easily done with a damp cloth. Dry thoroughly after cleaning. If a touch-up is ever needed we recommend a

"Pledge" like wax product.

It is important that your rack is assembled correctly. If the unit is assembled or used incorrectly, it

could become unstable and collapse, possibly causing injury.

WARNING

Enclume Design Products, Inc.

24 Colwell Street, Port Hadlock, WA. 98339

Phone 360-385-6100 •Fax 360-385-6156

www.enclume.com

NorthlineExpress.com www.NorthlineExpress.com Toll-FreeToll-Free 1-877-734-2458

NorthlineExpress.com www.NorthlineExpress.com
