Embedded EPIA-N700 User manual
March 22, 2018 Version 1.00
Operating Guide
EPIA-N700 Mainboard
EPIA-N700 Operating Guide
March 22, 2018 - i - Version 1.00
Table of Contents
Table of Contents .................................................................................................................. i
VIA EPIA-N700 verview ...................................................................................................... 1
VIA EPIA-N700 Layout .......................................................................................................... 2
VIA EPIA-N700 Specifications ................................................................................................ 3
VIA EPIA-N700 Processor SKUs .............................................................................................. 4
VIA VX800 Chipset verview ................................................................................................. 5
VIA EPIA-N700 Dimensions ................................................................................................... 6
VIA EPIA-N700 Height Distribution ......................................................................................... 7
VIA EPIA-N700 Side Profile .................................................................................................... 8
Power Consumption .............................................................................................................. 9
VIA EPIA-N700-15L ........................................................................................................... 9
A. Playing DVD – Power DVD 5.0 ...................................................................................... 9
B. Playing MP3 – Media Player .......................................................................................... 9
C. Running Network Application – Files Copy ...................................................................... 9
D. Idle........................................................................................................................... 9
E. Running C.C. Winstone 2004 ...................................................................................... 10
F. S3 mode .................................................................................................................. 10
VIA EPIA-N700-05LE ........................................................................................................ 11
A. Playing DVD – Power DVD 5.0 .................................................................................... 11
B. Playing MP3 – Media Player ........................................................................................ 11
C. Running Network Application – Files Copy .................................................................... 11
D. Idle......................................................................................................................... 11
E. Running C.C. Winstone 2004 ...................................................................................... 12
F. S3 mode .................................................................................................................. 12
VIA EPIA-N700 Microsoft and Linux Driver Support ................................................................. 13
Microsoft Driver Support................................................................................................... 13
Linux Driver Support ........................................................................................................ 13
Contact ............................................................................................................................. 14
EPIA-N700 Operating Guide
March 22, 2018 - 1 - Version 1.00
VIA EPIA-N700 Overview
The VIA EPIA-N700 Nano-ITX mainboard is a super compact native x86 mainboard optimized for
entry level systems in embedded and productivity applications. The mainboard is based on the VIA
VX800 Unified Digital Media IGP chipset featuring the VIA C-9 HC3 with 2D/3D graphics and video
accelerators for rich digital media performance.
The VIA EPIA-N700 includes a choice of VIA C7
®
or Eden™ ULV NanoBGA2 processors. The VIA
NanoBGA2 processors are powerful, secure, and efficient. They include the VIA Padlock Security
Engine, VIA CoolStream™ Architecture, VIA StepAhead™ Technology Suite, and VIA TwinTurbo™
technology.
The VIA EPIA-N700 supports up to 2 GB of 667/533 MHz DDR2 memory. The VIA EPIA-N700
provides support for high fidelity audio with its included VIA VT1708B High Definition Audio codec.
In addition it supports two SATA (3.0 Gbps) storage device. ther supported storage includes
CompactFlash and IDE.
The VIA EPIA-N700 is compatible with a full range of Nano-ITX, Mini-ITX, FlexATX, and MicroATX
enclosures. The VIA EPIA-N700 is fully compatible with Microsoft
®
and Linux operating systems.
EPIA-N700 Operating Guide
March 22, 2018 - 2 - Version 1.00
VIA EPIA-N700 ayout
Figure 1: EPIA-N700 layout
EPIA-N700 Operating Guide
March 22, 2018 - 3 - Version 1.00
VIA EPIA-N700 Specifications
Model Name - EPIA-N700-15L - EPIA-N700-05LE
Processor - VIA C7
®
1.5 GHz NanoBGA2
processor (400 MHz FSB)
- VIA Eden ULV 500 MHz
NanoBGA2 processor
(400 MHz FSB)
Chipset - VIA VX800 Unified Digital Media IGP Chipset
System Memory - 1 x DDR2 533/667 S DIMM slot
-
Up to
2
GB memory size
VGA - Integrated VIA C-9 HC3 DX9 3D/2D Graphics and unified video decoding
accelerat
ion
Onboard
IDE
-
1
x
UltraDMA 133/100
/66/33
pin
connector
(2.0 mm / 44
-
pin)
Onboard AN - 1 x VIA VT6130 PCIe Gigabit LAN controller
Onboard Audio - VIA VT1708B High Definition Audio Codec
Onboard I/O Connectors - 1 x USB pin header for two additional USB 2.0 ports
- 1 x Front audio pin header for headphone-out/MIC-in or amplifier module
- 1 x Dual-channel LVDS panel connector
- 1 x Backlight control connector (for inverter power and brightness control)
- 1 x CF Type I connector (shared with IDE)
- 2 x SATA connectors
- 2 x +5V SATA power connectors
- 1 x SPI pin header
- 1 x Digital I/ pin header
- 1 x KB/MS pin header
- 1 x SMBus pin header
- 3 x RS-232 serial port pin header (with 5V/12V selector)
- 1 x Front panel pin header
- 1 x System temperature reading pin header
- 2 x Fan connectors for CPU and system fans
- 1 x 12V power connector
- 1 x Power mode select connector (PS-on, 5Vsb)
Expansion Slot
-
1 x
Mini
PCI slot
Back Panel I/O - 1 x Serial port (supports RS-232/422/485)
- 1 x VGA port
- 1 x RJ-45 LAN port
- 2 x USB 2.0 ports
BIOS - Award BI S
- SPI 4/8 Mbit flash memory
Operating System Windows 2000/XP, Linux, WinCE, XPe
System Monitoring &
Management
- CPU voltage monitoring
- Wake-on-LAN, Keyboard power-on, RTC Timer power-on, Watch Dog Timer
- Fan speed detection
- System power management and temperature monitoring
-
AC Power failure recovery
Operating Temperature
0
°
C ~
6
0
°
C
Operating Humidity
0% ~ 95% (relative humidity; non
-
condensing)
Form Factor - Nano-ITX (8-layer)
- 12 cm x 12 cm
Note: This specification is subject to change without prior notice.
EPIA-N700 Operating Guide
March 22, 2018 - 4 - Version 1.00
VIA EPIA-N700 Processor SKUs
The VIA EPIA-N700 is available in two speed grades as follows:
•1.5 GHz VIA C7
®
NanoBGA2 Processor
•500 MHz VIA Eden ULV NanoBGA2 Processor
EPIA-N700 Operating Guide
March 22, 2018 - 5 - Version 1.00
VIA VX800 Chipset Overview
The VIA VX800 Unified Digital Media Chipset is designed to enable high quality digital video
streaming and DVD playback in a new generation of fanless, small form factor PCs and IA devices.
The VIA VX800 features VIA C-9 HC3 with 2D/3D graphics and video acceleration, DDR2 667/533
MHz support, motion compensation and dual display support to ensure a rich overall entertainment
experience. utstanding connectivity features include USB 2.0, 10/100/1000 LAN, SATA (3.0
Gbps), and ATA/133.
Figure 2: VX800 as implemented in EPIA-N700
EPIA-N700 Operating Guide
March 22, 2018 - 6 - Version 1.00
VIA EPIA-N700 Dimensions
Figure 3: EPIA-N700 mounting layout and dimensions
EPIA-N700 Operating Guide
March 22, 2018 - 7 - Version 1.00
VIA EPIA-N700 Height Distribution
Figure 4: EPIA-N700 height distribution
EPIA-N700 Operating Guide
March 22, 2018 - 8 - Version 1.00
VIA EPIA-N700 Side Profile
Figure 5: EPIA-N700 back panel ports
