Dorma ED700 User manual

ED700

Low Energy

Automatic Swing Door

DORMA

LOW ENERGY

AUTOMATIC SWING DOOR

INSTALLATION AND TUNE IN MANUAL

Distributed by:

DORMA AUTOMATICS, Inc. 924 Sherwood Drive Toll-Free: 877-367-6211

Lake Bluff, IL 60044 Fax: 877-423-7999

DL3038-010 Rev. B 6/08

E-mail: [email protected] Subject to change without notice

Contents

ED700 LOW ENERGY AUTOMATIC DOOR OPERATOR

Page Number

1. Cover

2. Contents

3. Instructions, Safety Standards and Suggested Tools

4. Sales Packages Surface Applied

5. Arm Styles

6. Mounting the Header

7. Installing the Operator

8. Installing the Controller

9. Connecting the Controller and On Off Hold Switch

10. Wiring Diagram

11. Open to Hard Stop

12. Electronic Stop

13. Push Arm

14. Pull Arm (0”to 6”) Reveal

15 Pull Arm General Information

16 Pull Arm (0”) Reveal

17, Basic Set Up

18. Basic Set Up continued

19. Customized Set Up

20. Simultaaneous Pairs

21. Semi-Independant Pairs

22. Electronic Locks

23. Operating Instructions Care and Maintenance

24 Sinage and Safety Check

25. Technical Data

26 Controller Codes

ED700

Low Energy

Automatic Swing Door

DORMA

DORMA AUTOMATICS, Inc. 924 Sherwood Drive Toll-Free: 877-367-6211

Lake Bluff, IL 60044 Fax: 877-423-7999 DL3038-010 Rev. B 6/08

E-mail: [email protected] Subject to change without notice

Important Installation Instructions

Compliance with Safety Standards

1. Carefully Read And Follow All Installation Instructions

2. Always disconnect the power supply before servicing.

3. After installation and adjustment, the installers final responsibility is to properly

Instruct the owner in the safe use of the door. He must also present the owner

With the ED700 Owner’s Manual and carefully explain how to perform the Daily

Safety Check.

4. Save These Instructions for Future Reference

Your door system was designed to the latest operating and safety standards. In

Order to ensure the continued safe operation of your door, it is important that:

- Your door system be maintained in compliance with the standards of the industry,

BHMA/ANSI 156.19.

- Proper decals and labels to be applied, per BHMA/ANSI standards, and maintained

On your doors.

Suggested Tools:

Screwdrivers

Small straight flat blade-for small terminals

#2 Phillips (cross point)

#3 Phillips (cross point)

Wrench / Sockets

9/16” Socket for arm attachment

1/2” Wrench / Socket

7/16” Wrench / Socket

3/8” Wrench / Socket

Electric Drill / Screwgun

Various bits 1/8”, 7/32”, 1/4”, 3/8”, 1/2”

1’ Holesaw

Countersink

Level

Step Ladder

Tape Measure

Electrical Wire Strippers / Cutters

Various Wire Nuts

ED700

Low Energy

Automatic Swing Door

DORMA

DORMA AUTOMATICS, Inc. 924 Sherwood Drive Toll-Free: 877-367-6211

Lake Bluff, IL 60044 Fax: 877-423-7999 DL3038-010 Rev. B 6/08

E-mail: [email protected] Subject to change without notice

ED700

Low Energy

Automatic Swing Door

DORMA

DORMA AUTOMATICS, Inc. 924 Sherwood Drive Toll-Free: 877-367-6211

Lake Bluff, IL 60044 Fax: 877-423-7999 DL3038-010 Rev. B 6/08

E-mail: [email protected] Subject to change without notice

ED700 SALES PACKAGES:

SURFACE APPLIED

See page 25 for minimum and maximum header lengths and door weights.

DS2419-02A OR DS2419-02B

PULL (IN) PULL (IN)

PUSH (OUT)

LH, PUSH (OUT)

RH, PUSH (OUT)

DS2416-02A OR DS2416-02B

DS1350-02A OR DS1350-02B

Left Hand Double Egress Right Hand Double Egress

DS2519-02A OR DS2519-02B

DS2521-02A OR DS2521-02B

DS2520-02A OR DS2520-02B

DS2420-02A OR DS2020-02B

DS1400-02A OR DS1400-02B

DS2418-02A OR DS2418-02B

DS2417-02A OR DS2417-02B

DS2415-02A OR DS2415-02B

ED700

Low Energy

Automatic Swing Door

DORMA

DORMA AUTOMATICS, Inc. 924 Sherwood Drive Toll-Free: 877-367-6211

Lake Bluff, IL 60044 Fax: 877-423-7999 DL3038-010 Rev. B 6/08

E-mail: [email protected] Subject to change without notice

Slide Track Arm (Pull)

0’- 6” Reveals

1. DC0847-01A ARM, UNIVERSAL SCISSOR CL

DC0847-01B ARM, UNIVERSAL SCISSOR DB

DK2494-01A KIT, DOUBLE EGRESS SISSOR ARM

EXTENDED SPINDLE REQUIRED FOR DOUBLE EGEESS APPLICATIONS

2. DS2516-01A ASSY, TRACK ARM RH CL

DS2516-01B ASSY, TRACK ARM RH DB

DS2219-01A ASSY, TRACK ARM LH CL

DS2219-01B ASSY, TRACK ARM LH DB

3. DS2409-01A ASSY, SLIDE TRACK

DS2409-01B ASSY, SLIDE TRACK

Scissor Arm (Push)

ED700

Low Energy

Automatic Swing Door

DORMA

DORMA AUTOMATICS, Inc. 924 Sherwood Drive Toll-Free: 877-367-6211

Lake Bluff, IL 60044 Fax: 877-423-7999 DL3038-010 Rev. B 6/08

E-mail: [email protected] Subject to change without notice

Aling

MOUNTING THE HEADER

1-1/2”1-

Unit Width

(= Door width + 3”)

Unit Width

(= Door width + 3”)

1-1/2”1-

Incoming 120VAC

(opposite pivot)

1-1/2”1-1/2”

PULL ARM TRACK OR DOUBLE EGRESS PAIR

Incoming 115VAC

(opposite pivot)

4” 1- ”

11”

1/4

“

23-1/2

”

1/2

The header should overlap the door opening 1-1/2” on each side of the frame.

If the header is shorter then the door opening the pivot side should overlap the

frame by 1-1/2” the centerline of the drive shaft should be 4” from the pivot side

of the opening in most applications.

If the header is not predrilled with mounting holes, locate and predrill at least six

mounting locations.

For outswing applications using a Push arm the header should be flush with the

bottom of the frame opening, for frames with a standard stop.

For inswinging doors using Pull Arms or Double Egress applications the header

should be located 1-1/4’ from top of the door.

The header must be plumb and level and fastened securely to the mounting

surface. Fasteners will vary with the mounting surface but the unit is supplied with

fasteners that provide adequate support for most applications. Drywall mounting

surfaces or stucco surfaces will require additional backing to support the header.

ED700

Low Energy

Automatic Swing Door

DORMA

DORMA AUTOMATICS, Inc. 924 Sherwood Drive Toll-Free: 877-367-6211

Lake Bluff, IL 60044 Fax: 877-423-7999 DL3038-010 Rev. B 6/08

E-mail: [email protected] Subject to change without notice

INSTALLING THE OPERATOR

TO INSTALL THE OPERATOR:

Align the bottom two holes with the two holes on the header

and fasten the operator to the header with (2) #1/4-20 X 1/2” FH screws.

WARNING: DO NOT ROTATE THE SHAFT, INSTALL THE ARM OR CONNECT TO THE DOOR

WITHOUT FIRST CONNECTING THE CONTROLER TO THE OPERATOR.

THE CLOSING SPEED CONTROL IS IN THE CONTROLER, ALLOWING THE OPERATOR TO SLAM

CLOSED WITHOUT THE CONTROLER CONNECTED MAY RESULT IN DAMAGE TO THE OPERATOR.

Connect Motor and Encoder Harnesses

#1 Endcap

SYNC

TXD

GND

RXD

PGM

ENC

Breakout

2-1/8”

#2 Header Bottom

Recommended Locations for Mode Switch.

(Phillips screwdriver required).

#6-32 x ½”

SYNC

TXD

GND

RXD

Breakout

PGM

ENC

Place Mode Switch in opening and fasten.

ED700

Low Energy

Automatic Swing Door

DORMA

DORMA AUTOMATICS, Inc. 924 Sherwood Drive Toll-Free: 877-367-6211

Lake Bluff, IL 60044 Fax: 877-423-7999

DL3038-010 Rev. B 6/08

E-mail: [email protected] Subject to change without notice

ENC

Controller installation.

Fasten using supplied mounting pads to

the back of the controller and the header.

SYNC

TXD

GND

RXD

PGM

Breakout

INSTALL THE CONTROLLER and ON OFF HOLD SWITCH (PROGRAM)

DO NOT PLUG MOTOR HARNESS INTO POWER, IT WILL DAMAGE MOTOR!

PGM

ENC

Breakout

SYNC

GND

TXD

RXD

3/4”

1 1/2”

Drill #36 (Ø.107)

(2plcs)

Drill Ø1”hole for clearace.

Motor

Controller

Brown

Black

Green

Mode Switch

Hold open

OFF

Connect Operator Internal Wiring to Control

Jumper

Required

ENCODER

Black

Use supplied

green connector

Sensor connections

see page - 10

Green

Red

Left Side Right Side

Use supplied

green connector

Connecting the Controller

Breakout

PGM

ENC

SYNC

TXD

GND

RXD

To RXD

To TXD

To GND

Optional: use when

synchronizing two operators

MICROPROCESSOR CONTROL

115 VAC 60 Hz 2A

DORMA AUTOMATICS

Phone: 877-367-6211

Motor: 4A slow blow

Line: 2A fast acting

THIS OPERATOR CONTROLLER MUST BE

ADJUSTED TO MEET ANSI STANDARDS

POWER

115 Vac

White

Black

Green

GROUND ATTACHED TO HEADER

NOTE: For LH or

LHR, Red and Black

leads must switch

Jumper

Required

Brown

Black

Green

Mode Switch Function

Brown

Black

Green

ED700

Low Energy

Automatic Swing Door

DORMA

DORMA AUTOMATICS, Inc. 924 Sherwood Drive Toll-Free: 877-367-6211

Lake Bluff, IL 60044 Fax: 877-423-7999 DL3038-010 Rev. B 6/08

E-mail: [email protected] Subject to change without notice

ED700

Low Energy

Automatic Swing Door

DORMA

DORMA AUTOMATICS, Inc. 924 Sherwood Drive Toll-Free: 877-367-6211

Lake Bluff, IL 60044 Fax: 877-423-7999 DL3038-010 Rev. B 6/08

E-mail: [email protected] Subject to change without notice

THI

(Optional)Swing Side Door Mounted Sensor

MOUNTED TO SWING SIDE OF DOOR

MOUNTED TO APPROACH OF DOOR

GREEN (N.O.)

BLACK (-24 VDC)

RED (+24VDC)

WHITE (COM)

SMOKE

DETECTOR

(Optional)

PUSH BUTTON OR

ANY OTHER KNOWING

ACT ACTIVATION DEVICE

GREEN (N.O.)

BLACK (-24 VDC)

RED (+24VDC)

WHITE (COM)

Please see Sensors Manufacturer’s Installation Guides

for further instructions and wiring details.

Follow the installation and adjustment instructions accompanying the sensors

to be installed. Insure compliance with BHMA/ANSI Standards.

Jumper MUST be installed

if an optional smoke

detector is not present.

extra

(Optional)Approach Side Door Mounted Sensor

WIRING DIAGRAM FOR PUSH PLATES AND OPTIONAL ACCESSORIES

Isolation Relay

for electric locks

see page 22.

MOUNTED TO THE HEADER

Data+

Data-

COM

24V

(Optional)

OVERHEAD

SWING AREA

PRESENCE

SENSOR

Do not connect electric strike

or magnetic lock directly to

the control
