Dnake 280M-S8 User manual
Model: 280SD-C12
280SD-R2
280SD-R5
Quick Start Quide
Door Station
The picture is only a schematic diagram. The actual product shall prevail.
USER MANUAL
Please follow the user manual for correct installation and
testing. If there is any doubt please call our tech-supporting
and customer center.
Our company applies ourselves to reformation and
innovation of our products. No extra notice for any change.
The illustration shown here is only for reference. If there is
any difference, please take the actual product as the
standard.
The product and batteries must be handled separately from
household waste. When the product reaches the end of
service life and needs to be discarded, please contact the
local administrative department and put it in the designated
collection points in order to avoid the damage to the
environment and human health caused by any disposal. We
encourage recycling and reusing the material resources.
REMARK
CATALOG
Product Features .....................................................1
Technical Parameters .............................................1
Package Contents...................................................2
Pictures.....................................................................2
Operations ...............................................................3
1. Security .................................................................4
2. Smart ....................................................................9
3. Intercom .............................................................12
4. Message ..............................................................14
5. Setup ...................................................................15
Web Settings..........................................................18
System Configuration..........................................20
System Diagram ....................................................21
Installation .............................................................23
Troubleshooting....................................................24
Safety Instructions................................................25
PRODUCT FEATURES
1. Building intercom application:
Talkback: Support video call, monitoring, unlocking and checking of
call records.
Security: Support 8 alarm zones with three states, zone and scene
setup.
Smart: Support smart home extension by RS485 communication.
2. Operating system: Linux.
TECHNICAL PARAMETERS
Voltage: DC 12V
POE
Rated power: 9W
Standby power consumption: 1.5W
Display screen: 7''
Touch screen: Capacitive touch screen
Resolution: 800x480
Working Temperature: -10℃ to +55℃
Storage Temperature: -10℃ to +60℃
Working Humidity: 10% to 90% (non-condensing)
1
Package Contents
Quick Start Guide
Indoor Monitor
MODEL: 280M-S8
Please make sure the package contains the following items:
Screw
PACKAGE CONTENTS
2
PICTURES
Microphone
7'' capacitive
touch screen
Speaker
3
OPERATIONS
Main menu: Security, Smart, Intercom, Message and Setup.
Status bar: Network connection and security precautions.
Shortcut key: Do Not Disturb, Message, Records.
Instructions of status bar and shortcut key:
1. DND :Click icon, the system will enter DND or undo DND. You can
use Do Not Disturb service when you don't want to be disturbed by
calls(The valid time is 8 hours).
2. Message : Click it to enter the Message interface.
3. Network connection : When the icon keeps lit, the indoor monitor is
connected to the network.
4. Security precautions : The icon flashes during activation time and
keeps lit after arming successfully.
5. SIP Registration Status : This icon keeps lit when SIP account is
registered.
Clicking “Security” icon on the main interface, the system will enter the
following interface:
1.Security
1.1 ON/OFF
Clicking “ON/OFF” icon, the system will enter the following interface:
1.1.1 ON
Click “Out” “Home”, or “Sleep” icon to activate the alarm sensors. The
corresponding icon on the main interface will be lit up with a beep and it
will stay lit.
1.1.2 OFF
(1) During the delay time of arming, clicking “OFF” icon, the system will emit
a beep. Then the alrm will be stopped.
(2) Input user password(the default password is 1234) to stop the alarm
under ON status.
4
1.2.1 IP Camera Setting
Login the webpage of indoor monitor by username: user, password:1234,
and then you can access the following webpage:
1.2 Camera
Clicking “Camera” icon, the system will enter into the following interface:
Click icon or icon button to select the camera you want, and then
click to monitor the IP camera. If you want to cancel monitoring, click
to stop it.
5
Clicking “Camera” icon, the system will enter into the following interface:
Click icon or icon button to select IP Camera to monitor, and then
click icon to monitor. Click to stop monitoring.
Fill in with the RTSP format: rtsp:// user: password@ Camera IP. IP is the IP
address of your IP Camera. Then you can monitor IP Camera in Security
menu on your indoor monitor:
1.3 Zone
Remark: It should be set when the alarm is OFF.
Click “Zone” icon and input 1-16 digits password(the default password is 1234),
the system will enter into the following interface:
6
NO.Type Mode Delay Sensor
1
2
3
4
5
6
7
8
24 Hour 3C
3C
3C
3C
3C
3C
3C
3C
0s
0s
0s
0s
0s
0s
0s
0s
Smoke
OK
24 Hour
24 Hour
24 Hour
24 Hour
24 Hour
24 Hour
24 Hour
Smoke
Smoke
Smoke
Smoke
Smoke
Smoke
Smoke
1.3.2 Mode
Clicking mode setting box, it will pop up a dialog box as the following
interface. On this interface, you can set mode as: 3C, NO, NC or BELL.
1.3.1 Alarm Type
Clicking input box of type, a dialog box will pop up as below. On this
interface, you can set alarm type as: Normal, Emergency or 24H. 24H and
Emergency type are always active.
NO.Type Mode Delay Sensor
1
2
3
4
5
6
7
8
24 Hour 3C
3C
3C
3C
3C
3C
3C
3C
0s
0s
0s
0s
0s
0s
0s
0s
Smoke
OK
24 Hour
24 Hour
24 Hour
24 Hour
24 Hour
24 Hour
24 Hour
Smoke
Smoke
Smoke
Smoke
Smoke
Smoke
Smoke
Normal
Emerg.
24 Hour
NO.Type Mode Delay Sensor
1
2
3
4
5
6
7
8
24 Hour 3C
3C
3C
3C
3C
3C
3C
3C
0s
0s
0s
0s
0s
0s
0s
0s
Smoke
OK
24 Hour
24 Hour
24 Hour
24 Hour
24 Hour
24 Hour
24 Hour
Smoke
Smoke
Smoke
Smoke
Smoke
Smoke
Smoke
3C
NO
NC
BELL
7
