DFI CB64-BX User manual
CB64-BX/ZX
Rev. A+
System Board
Users Manual
39700913
Copyright
This publication contains information that is protected by copyright. No
part of it may be reproduced in any form or by any means or used to
make any transformation/adaptation without the prior written permission
from the copyright holders.
This publication is provided for informational purposes only. The
manufacturer makes no representations or warranties with respect to
the contents or use of this manual and specifically disclaims any express
or implied warranties of merchantability or fitness for any particular purpose.
The user will assume the entire risk of the use or the results of the use of
this document.Further,the manufacturer reserves the right to revise this
publication and make changes to its contents at any time, without obligation
to notify any person or entity of such revisions or changes.
All Rights Reserved. © 1999
Trademarks
Microsoft®MS-DOS®,WindowsTM,Windows®95 andWindows®98 are
registered trademarks of Microsoft Corporation. Intel®and CeleronTM
are registered trademarks of Intel Corporation. Award is a registered
trademark of Award Software, Inc. Other trademarks and registered
trademarks of products appearing in this manual are the properties of
their respective holders.
Caution:
Danger of explosion if battery incorrectly replaced.
Replace only with the same or equivalent type recommended by the
manufacturer.
Dispose of used batteries according to the battery manufacturers
instructions.
FCC and DOC Statement on Class B
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a residential
installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the receiver.
Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
Consult the dealer or an experienced radio TV technician for
help.
Notice:
1. The changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority
to operate the equipment.
2. Shielded interface cables must be used in order to comply with
the emission limits.
Table of Contents
Chapter 1 - Introduction
1.1 Features and Specifications..................................................................................
1.2 Package Checklist.........................................................................................................
Chapter 2 - Hardware Installation
2.1 System Board Layout .............................................................................................
2.2 System Memory.............................................................................................................
2.3 DIP Switch Settings for Processors............................................................
2.4 Jumper Settings for the CPUs Front Side Bus................................
2.5 Jumper Settings for Clearing CMOS Data..........................................
2.6 Jumper Settings for Wake-On-Keyboard/Wake-On-Mouse......
2.7 Connecting the Ribbon Cables and Wires of the Ports
and Connectors.............................................................................................................
Chapter 3 - Award BIOS Setup Utility
3.1 The Basic Input/Output System.....................................................................
3.1.1 Standard CMOS Setup....................................................................
3.1.2 BIOS Features Setup..........................................................................
3.1.3 Chipset Features Setup....................................................................
3.1.4 Power Management Setup............................................................
3.1.5 PNP/PCI Configuration....................................................................
3.1.6 Load Fail-Safe Settings......................................................................
3.1.7 Load Optimal Settings......................................................................
3.1.8 Integrated Peripherals.........................................................................
3.1.9 Supervisor Password..........................................................................
3.1.10 User Password.........................................................................................
3.1.11 IDE HDD Auto Detection...........................................................
3.1.12 Save & Exit Setup.................................................................................
3.1.13 Exit Without Saving..............................................................................
Chapter 4 - Supported Softwares
4.1 Desktop Management Interface.....................................................................
4.2 Hardware Doctor Utility........................................................................................
4.3 Drviers and Utility.......................................................................................................
6
11
33
33
36
39
43
48
50
50
51
55
56
56
57
57
12
14
15
16
17
18
19
58
61
63
64
64
66
Appendix A - System Error Messages
A.1 POST Beep.......................................................................................................................
A.2 Error Messages..............................................................................................................
Appendix B - Troubleshooting
B.1 Troubleshooting Checklist....................................................................................
6
1.1 Features and Specifications
1.1.1 Features
Chipset
CB64-BX
Intel440BX AGPset
ESS Solo-1 PCI AudioDrive
CB64-ZX
Intel440ZX-100 AGPset
ESS Solo-1 PCI AudioDrive
Processor
The system board is equipped with Intel®Socket 370 for installing
an Intel CeleronTM PPGA processor. The system board is also
equipped with a switching voltage regulator that supports 1.30V to
2.05V core voltage for various processors.
300A/333/366/400/433/466MHz and future 100MHz FSB
CeleronTM processor (PPGA for Socket 370)
System Memory
CB64-BX
-16MB to 384MB memory using unbuffered DIMMs
- 32MB to 768MB memory using registered DIMMs
- Three 168-pin DIMM sockets
- Uses x64 or x72 PC SDRAM, 3.3V
: PC-66 SDRAM DIMM for 66MHz FSB processors
: PC-100 SDRAM DIMM for 100MHz FSB processors
- ECC supported (uses x72 PC SDRAM DIMM)
Chapter 1 - Introduction
1
Introduction
7
Expansion Slots
The system board is equipped with 1 dedicated AGP slot. AGP is an
interface designed to support high performance 3D graphics cards. It
utilizes a dedicated pipeline to access system memory for texturing,
z-buffering and alpha blending; delivering up to 533MB/sec.
bandwidth for 3D graphics applications. AGP in this system board
will deliver faster and better graphics with your PC.
The system board is also equipped with 4 dedicated PCI slots, 2
dedicated 16-bit ISA slots. All PCI and ISA slots are bus masters
except PCI 4 in the CB64-ZX which is slave only.
Onboard Audio Features
Sound Blaster, Sound Blaster Pro and WSS compatible
Supports PC games and applications
Sample rates from 4KHz up to 48KHz
Full duplex operation for simultaneous record and playback
ESS proprietary AudioRack application
*Supported only when CB64-BX
uses registered DIMMs.
DIMMs
2MBx64/x72
4MBx64/x72
8MBx64/x72
16MBx64/x72
32MBx64/x72
Memory Size
16MB
32MB
64MB
128MB
256MB*
DIMMs
2MBx64
4MBx64
8MBx64
16MBx64
Memory Size
16MB
32MB
64MB
128MB
CB64-ZXCB64-BX
CB64-ZX
-16MB to 256MB memory using unbuffered DIMMs
- Two 168-pin DIMM sockets
- Uses x64 PC SDRAM, 3.3V
: PC-66 SDRAM DIMM for 66MHz FSB processors
: PC-100 SDRAM DIMM for 100MHz FSB processors
Introduction
1
8
Desktop Management Interface (DMI)
The system board comes with a DMI 2.0 built into the BIOS. The
DMI utility in the BIOS automatically records various information
about your system configuration and stores these information in the
DMI pool, which is a part of the system board's Plug and Play
BIOS. DMI, along with the appropriately networked software, is
designed to make inventory, maintenance and troubleshooting of
computer systems easier. Refer to Chapter 4 for instructions on
using the DMI utility.
ATX Double Deck Ports
2 USB ports
2 DB-9 serial ports
1 DB-25 parallel port
1 mini-DIN-6 PS/2 keyboard port
1 mini-DIN-6 PS/2 mouse port
1 game/MIDI port
3 audio jacks: line-out, line-in and mic-in
Connectors
1 connector for IrDA interface
2 IDE connectors
1 floppy connector
1 20-pin ATX power supply connector
1 3-pin WOL (Wake-On-LAN) connector
3 CD audio-in connectors
3 fan connectors for CPU, chassis and AGP fans
PCI Bus Master IDE Controller
Two PCI IDE interfaces support up to four IDE devices
Supports ATA/33 or ATA/66 hard dirves
PIO Mode 3 and Mode 4 Enhanced IDE (data transfer rate up
to 16.6MB/sec.)
Bus mastering reduces CPU utilization during disk transfer
Supports ATAPI CD-ROM, LS-120 and ZIP and SCSI sequential
boot-up
1
Introduction
9
IrDA Interface
The system board is equipped with an IrDA connector for wireless
connectivity between your computer and peripheral devices. It
supports peripheral devices that meet the IrDA or ASKIR standard.
USB Ports
The system board is equipped with two USB ports. USB allows
data exchange between your computer and a wide range of
simultaneously accessible external Plug and Play peripherals.
BIOS
Award BIOS, Windows95/98 Plug and Play compatible
Flash EPROM for easy BIOS upgrades
Includes NCR 810 SCSI BIOS
2MB flash memory
1.1.2 System Health Monitor Functions
The system board is capable of monitoring the following system
health conditions.
Monitors processor/system temperature and processor overheat
alarm
Monitors 1.5V/3.3V/±5V/±12V/VCORE voltages and failure
alarm
Monitors processor/chassis fan speed and failure alarm
Automatic processor/chassis fan control
Read back capability that displays accurate temperature, voltage
and fan speed
Introduction
1
10
1.1.3 Intelligence
Automatic CPU/Chassis Fan Off
The CPU and chassis fans will automatically turn off once the system
enters the Suspend mode.
Dual Function Power Button
Depending on the setting in the BIOS setup, this switch will allow
the system to enter the Soft-Off or Suspend mode.
External Modem Ring-on
The Modem Ring-on feature allows the system that is in the
Suspend mode or Soft Power Off mode to wake-up/power-on to
respond to incoming calls.
Note:
This feature supports external modem only.
RTC Timer to Power-on the System
The RTC installed on the system board allows your system to
automatically power-on on the set date and time.
Wake-On-LAN Ready
The Wake-On-LAN function allows the network to remotely wake
up a Soft Power Down (Soft-Off) PC.Your LAN card must support
the remote wakeup function.
Important:
The 5VSB power source of your power supply must support
≥
720mA (minimum).
Wake-On-Keyboard/Wake-On-Mouse
This function allows you to use the keyboard or mouse to power-on
the system. Refer to Jumper Settings for Wake-On-Keyboard/Wake-
On-Mouse in Chapter 2 and Keyboard/Mouse Power On in the
This manual suits for next models
1
Table of contents
Other DFI Motherboard manuals
DFI
DFI AK74-SU User manual
DFI
DFI lanparty UT nF3 250Gb User manual
DFI
DFI LanParty NF3 Ultra-DF User manual
DFI
DFI CW65 Series User manual
DFI
DFI CP100-NRM User manual
DFI
DFI EB3486-TN User manual
DFI
DFI CS350-C246 User manual
DFI
DFI 915P-TAL User manual
DFI
DFI CS30-TC User manual
DFI
DFI ADS310-R680E Series User manual
