Dell PowerEdge 2450 User manual

(Rev. 11/3/98) FILE LOCATION: C:\Dell\docs\2450\2post\81HFFfc0.fm

www.dell.com

™

Dell™ PowerEdge™ 2450 Systems

TWO -POST RACK

INSTALLATION

Notes, Notices, Cautions, and Warnings

Throughout this guide, blocks of text may be accompanied by an icon and printed in

bold type or in italic type. These blocks are notes, notices, cautions, and warnings,

and they are used as follows:

NOTE: A NOTE indicates important information that helps you make better use of

your computer system.

NOTICE: A NOTICE indicates either potential damage to hardware or loss

of data and tells you how to avoid the problem.

CAUTION: A CAUTION indicates a potentially hazardous situation which, if

not avoided, may result in minor or moderate injury.

WARNING: A WARNING indicates a potentially hazardous situation which,

if not avoided, could result in death or serious bodily injury.

____________________

Information in this document is subject to change without notice.

Reproduction in any manner whatsoever without the written permission of Dell Computer Corpo-

ration is strictly forbidden.

Trademarks used in this text: Dell, the DELL logo, and PowerEdge are trademarks of Dell Computer

Corporation. Other trademarks and trade names may be used in this document to refer to either

the entities claiming the marks and names or their products. Dell Computer Corporation disclaims

any proprietary interest in trademarks and trade names other than its own.

February 2000 P/N 81HFF Rev. A00

support.dell.com Dell PowerEdge 2450 Systems - Two-Post Rack Installation 1

(Rev. 11/3/98) FILE LOCATION: C:\Dell\docs\2450\2post\81HFFts0.fm

DELL CONFIDENTIAL - Preliminary 9/27/01

Dell™ PowerEdge™ 2450 Systems

Two-Post Rack Installation

This document provides instructions for installing a Dell PowerEdge 2450 system in a

two-post open-frame relay rack, such as those found in telecommunications equip-

ment facilities.

The two-post open-frame relay rack must be properly secured to the floor, to the ceil-

ing or upper wall, and where applicable, to adjacent racks, using floor and wall

fasteners and bracing specified or approved by the rack manufacturer or by industry

standards. Refer to the two-post open-frame relay rack manufacturer’s installation

documentation for precautionary warnings and information before attempting this

installation.

CAUTION: Do not attempt to install the PowerEdge system into a two-post

open-frame relay rack that has not been securely anchored in place. Dam-

age to the system and personal injury may result.

Refer to the safety instructions in your Dell system documentation for additional

safety information regarding rack installation.

Rack Kit Components

The rack kit includes the following items (see Figure 1):

•One tray assembly (PowerEdge 2450 two-post)

•Four 12-24 x 0.5-inch pan-head Phillips screws

2 Dell PowerEdge 2450 Systems - Two-Post Rack Installation

DELL CONFIDENTIAL - Preliminary 9/27/01

(Rev. 11/3/98) FILE LOCATION: C:\Dell\docs\2450\2post\81HFFts0.fm

Figure 1. Rack Kit Contents

Recommended Tools

You need the following tools and equipment to install the system in a two-post open-

frame relay rack:

•#2 Phillips screwdriver

•Masking tape and/or felt-tip marker pen, for use in marking the mounting holes to

be used

Marking the Rack

1. Determine where you want to place the bottom of the 2-U support tray.

2. Mark the top and bottom holes on the rack.

Each 1-U (1.75-inch) vertical space has three holes, with center-to-center spacing

between holes (beginning at the top of a 1-U space) of 0.625, 0.625, and 0.5

inches (see Figure 2).

tray assembly

12-24 x 0.5 inch pan-head screw

support.dell.com Dell PowerEdge 2450 Systems - Two-Post Rack Installation 3

DELL CONFIDENTIAL - Preliminary 9/27/01

(Rev. 11/3/98) FILE LOCATION: C:\Dell\docs\2450\2post\81HFFts0.fm

Figure 2. Two-Post Open-Frame Relay Rack 1-U Hole Spacing

Installing the Support Tray in the Rack

CAUTION: The 2-U support tray is designed to support a single

PowerEdge 2450 system. Do not attempt to install any other system in this

support tray. Damage to the system and personal injury may result.

1. Place the support tray into the rack with the bottom of the tray at the marks you

made earlier for the location of the bottom of the installed system.

2. Install four 12-24 x 0.5-inch screws provided to secure the support tray using the

top and the bottom holes on the support tray’s front-mounting flange (see

Figure 3).

An internally threaded stud projecting from the front of the tray flanges accepts

the captive fastener on the front of the PowerEdge server.

3.5 inches (2 U)

1.75 inch (1 U)

4 Dell PowerEdge 2450 Systems - Two-Post Rack Installation

DELL CONFIDENTIAL - Preliminary 9/27/01

(Rev. 11/3/98) FILE LOCATION: C:\Dell\docs\2450\2post\81HFFts0.fm

Figure 3. Installing the Support Tray in the Rack

Installing the System in the Rack

CAUTION: Due to the size and weight of the computer system, never

attempt to install the computer system by yourself.

1. If your system has an optional plastic bezel, remove it (see the Installation and

Troubleshooting Guide for instructions).

2. Lift the system into position on the support tray.

3. Slide the system completely into position and secure it to the rack using the cap-

tive fasteners at the lower edge of the front panel (see Figure 4).

12-24 x 0.5 inch

screws (4)

support.dell.com Dell PowerEdge 2450 Systems - Two-Post Rack Installation 5

DELL CONFIDENTIAL - Preliminary 9/27/01

(Rev. 11/3/98) FILE LOCATION: C:\Dell\docs\2450\2post\81HFFts0.fm

Figure 4. Securing the Computer System in the Rack

4. Attach the front bezel, if one is available, to the system (see the Installation and

Troubleshooting Guide for instructions).

This completes the two-post rack installation.

captive

fasteners

6 Dell PowerEdge 2450 Systems - Two-Post Rack Installation

DELL CONFIDENTIAL - Preliminary 9/27/01

(Rev. 11/3/98) FILE LOCATION: C:\Dell\docs\2450\2post\81HFFts0.fm
