Datalogic DLL2020 User manual

DLL2020

User’s Manual

DLL2020

USER'S MANUAL

DATALOGIC S.p.A.

Via Candini 2

40012 - Lippo di Calderara di Reno

Bologna - Italy

DLL2020 User's Manual

Ed.: 11/2003

Datalogic reserves the right to make modifications or improvements without prior

notification.

Datalogic shall not be liable for technical or editorial errors or omissions contained

herein, nor for incidental or consequential damages resulting from the use of this

material.

Product names mentioned herein are for identification purposes only and may be

trademarks and or registered trademarks of their respective companies.

820000884 (Rev. D)

iii

CONTENTS

INTRODUCTION................................................................... v

COMPLIANCE..................................................................... vi

FCC ..................................................................................... vi

Warranty ............................................................................. vi

1GETTING STARTED............................................................... 1

1.1 Unpacking the DLL2020.......................................................... 1

1.2 Available Models..................................................................... 2

1.3 Scanning Bar Codes with the DLL2020................................... 3

1.4 Scanner Labelling ................................................................... 5

1.5 Maintaining the Scanner.......................................................... 7

1.6 Controlling the Scanner from the POS System........................ 8

2INSTALLING THE DLL2020................................................... 9

2.1 Connecting the Scanner.......................................................... 9

2.1.1 RS232 Direct Power.............................................................. 10

2.1.2 Keyboard Wedge Direct Power............................................. 10

2.2 Interface Selection ................................................................ 11

3CONFIGURATION ................................................................ 13

3.1 Change Scanner Settings ..................................................... 13

3.2 Factory Default Settings........................................................ 14

3.3 Default Message Format....................................................... 15

3.4 Editing Commands................................................................ 16

3.5 RS232................................................................................... 17

RS232 Presets...................................................................... 17

3.6 Keyboard Wedge .................................................................. 19

PC/Terminal Type................................................................. 19

Keyboard Nationality............................................................. 20

3.7 Operating Parameters........................................................... 22

3.8 Code Selection...................................................................... 24

3.9 Data Formatting .................................................................... 27

Pre-defined Terminators........................................................ 27

Code Identifiers..................................................................... 28

A CONNECTOR AND PIN DEFINITIONS ................................ 30

B TECHNICAL FEATURES...................................................... 31

C TROUBLESHOOTING.......................................................... 33

INTRODUCTION

The Datalogic DLL2020 is a high performance omni-directional scanner,

which provides optimal scanning conditions.

Together with its compact and ergonomic design, operator fatigue and

other discomforts are less than any competitive omni-directional scanner.

These characteristics make the DLL2020 especially suitable for

installation in small counters such as in drugstores, pharmacies,

department stores, tobacconists, kiosks, petrol stations, and

convenience stores.

The omni-directional scan field of the DLL2020 generates a scan pattern

of 16 lines, ensuring high performance scanning. Featuring an

unequalled scan rate of 800 scans per second, the DLL2020 is an

aggressive scanner.

Barcodes are read simply on presentation to the scanner window.

However, the ergonomic design of DLL2020 rubber sleeve, which fits

naturally in the hand, makes the unit easy to pick up when larger or

heavier products have to be scanned.

The scanner con be installed ‘free-standing’ on a counter surface using

its protective rubber sleeve or without the sleeve, flush or surface fixed to

check-out furniture, making for a very neat installation.

This manual contains three chapters and three appendices. The first

chapter describes the DLL2020 scanner, its general features as well as

the way in which it can be used. The precise instructions for installing the

scanner are listed in the second chapter. Default settings can be

changed using the bar code labels in chapter 3 "Configuration".

Appendix A shows the connector types of the scanner. Technical

specifications of the DLL2020 can be found in Appendix B. Refer to

Appendix C for troubleshooting if the scanner is not working properly.

COMPLIANCE

FCC

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to EN55022, and with the limits for a class A digital device,

pursuant part 15 of the FCC rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a

commercial environment. This equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in accordance with the user's manual,

may cause harmful interference to radio communications. Operation of the

equipment in a residential area is likely to cause harmful interference in which case

the user will be required to correct the interference at his own expense. Any

unauthorized changes or modifications to this equipment could void the user's

authority to operate this equipment.

For CE-countries:

- The DLL2020 is in conformity with the CE standards.

For USA & Canada:

- To be used with UL listed and CSA certified computers/POS systems.

- À utiliser avec des ordinateurs/systèmes POS registrés UL/certifiés CSA.

Radio and Television Interference

Operation of this equipment in a residential area can cause interference to radio or

television reception. This can be determined by turning the equipment off and on.

The user is encouraged to try to correct the interference by one or more of the

following measures:

• Re-orientate the receiving antenna

• Relocate the device with respect to the receiver

• Move the device away from the receiver

• Plug the device into a different outlet in order to have the device and

receiver on different branch circuits.

WARRANTY

Datalogic warranties this product against defects in workmanship and materials, for a

period of 24 months from the date of shipment, provided that the product is operated

under normal and proper conditions.

Datalogic has the faculty to repair or replace the product, these provisions do not

prolong the original warranty term.

The warranty does not apply to any product that has been subject to misuse,

accidental damage, unauthorized repair or tampering.

GETTING STARTED

1 GETTING STARTED

1.1 UNPACKING THE DLL2020

Take the scanner and its accessories out of the box and remove all

packing materials. Refer to the packing list in order to ensure that you

have received all the items ordered. Visually inspect the scanner and

accessories for any visible traces of damage. Refer to the figure in

paragraph 1.4 to locate the interface label and verify if the scanner

interface corresponds with the host system interface. Immediately

contact your supplier if anything appears to be damaged, or if the

supported interface does not correspond with the host system interface.

Green Led Red Led Good read beeper

Rubber sleeve

Sleep mode switch

DLL2020

The various parts of the DLL2020 are:

Sleep mode switch: If a sleep mode time-out has been programmed,

the scanner can be reactivated by pressing this switch. The sleep-mode

feature can be programmed using the Software Configuration Guide part

number 90ACC1620.

NOTE

The default value for the sleep mode time-out is set to

30 minutes. When the scanner is in sleep mode, the

LED is intermittently flashing red.

Red LED:The red LED indicates that the scanner is ready to read a bar

code.

Green LED: The green LED indicates a good read.

Good read beeper: The beeper sounds whenever data have been

correctly read. The frequency can be adjusted using the Software

Configuration Guide part number 90ACC1620.

Rubber sleeve: A rubber sleeve encloses the scanner. The sleeve

protects the scanner, and takes care that it does not slide when installed

‘free-standing’ on a counter surface. Furthermore, its ergonomic design

makes the unit easy to pick up; it fits naturally in the hand.

1.2 AVAILABLE MODELS

The following two models are available:

− DLL2020, standard model

− DLL2021, with single line option (see par. 3.7 for details).

GETTING STARTED

1.3 SCANNING BAR CODES WITH THE DLL2020

15cm

The DLL2020 is an omnidirectional scanner featuring a 4-directional scan

field with a 16-line scan pattern. Bar codes can easily be read by

presenting them to the scanner. The scan volume is illustrated in the

figure above. The optimal reading zone lies between 3 and 15 cm from

the scanner window. However, bar codes can still be read up to 25 cm

(10 inches) from the scanner window.

X 25 cm 15 cm 3 cm
