D-Link DUB-1312 User manual
Version 1.00
User Manual
USB 3.0 to Gigabit Ethernet Adapter
DUB-1312
iD-Link DUB-1312 User Manual
Manual Overview
D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify any
person or organization of such revisions or changes. Information in this document may become obsolete as our services and
websites develop and change. Please refer to your local D-Link website for the most current information.
Trademarks
D-Link and the D-Link logo are trademarks or registered trademarks of D-Link Corporation or its subsidiaries in the United
States or other countries. All other company or product names mentioned herein are trademarks or registered trademarks of
their respective companies.
Copyright © 2013 by D-Link Corporation.
All rights reserved. This publication may not be reproduced, in whole or in part, without prior expressed written permission
from D-Link Corporation.
iiD-Link DUB-1312 User Manual
Table of Contents
Package Contents ................................................................................. 1
System Requirements ......................................................................... 1
Introduction ........................................................................................... 2
Features ...................................................................................................3
Hardware Overview ............................................................................. 4
Software Installation ...........................................................................5
Windows 7 ....................................................................................... 5
Windows Vista ................................................................................ 7
Windows XP .................................................................................... 8
Mac OS X ........................................................................................11
Linux 2.6.14 ...................................................................................14
Table of Contents
Connecting the Adapter to a Network .......................................16
Completing the Installation ............................................................17
Troubleshooting .................................................................................18
Technical Specications ...................................................................21
1D-Link DUB-1312 User Manual
Section 1 - Product Overview
DUB-1312 USB 3.0 to Gigabit Ethernet Adapter
DUB-1312 Drivers and Manual on CD-ROM
Quick Installation Guide
Package Contents
System Requirements
System Requirements
Computer with the following:
• Microsoft Windows® 8/7/Vista®/XP, Linux, or Mac OS X 10.6 to 10.8
• Pentium 2.0 GHz or higher with a minimum of 32 MB RAM
• Available USB port (USB 3.0 required for Gigabit speeds)
• CD-ROM drive
If any of the above items are missing or damaged, please contact your reseller.
2D-Link DUB-1312 User Manual
Section 1 - Product Overview
Introduction
Thank you for choosing the D-Link DUB-1312 USB 3.0 to Gigabit Ethernet Adapter. The DUB-1312 is specically designed to
plug into an available Universal Serial Bus (USB) port on a desktop, laptop, or netbook computer running Microsoft Windows
8/7/Vista/XP/2000, Mac OS X, or Linux. Based on the USB 3.0 standard, the DUB-1312 extends the transfer speed of earlier USB
Fast Ethernet adapters to true 1 Gbps connectivity. Power for the DUB-1312 is provided directly by the USB port, eliminating
the need for an external power adapter. It also supports USB energy-saving suspend and resume functions to minimize power
consumption, which is especially useful for laptop/notebook users.
3D-Link DUB-1312 User Manual
Section 1 - Product Overview
Features
Designed for versatility and performance, the DUB-1312 USB 3.0 to Gigabit Ethernet Adapter has the following features:
• Compliant with the latest USB 3.0 specication. Also backwards compatible with USB 2.0/1.1/1.0 specications.
• True 1 Gbps network connectivity
• Compliance with IEEE 802.3ab gigabit Ethernet standards and IEEE 802.3 Ethernet standards
• Plug-and-Play installation (operating system dependent)
• Auto 10/100/1000 Mbps speed detection
• Supports half and full-duplex at 10 Mbps, half /full-duplex at 100 Mbps, and half/full duplex at 1 Gbps
• Built-in RJ-45 connector
• Autonegotiation to the highest available speed
• Two LED indicators: Connection Speed, Link/ACT
• Driver support:
• Microsoft Windows 8
• Microsoft Windows 7 (x86, x64)
• Microsoft Windows Vista
• Microsoft Windows XP
• Linux (kernel 2.6.14 & above)
• Macintosh OS X (10.4 to 10.8)
• Microsoft Windows 2000
4D-Link DUB-1312 User Manual
Section 1 - Product Overview
Hardware Overview
ID COMPONENT DESCRIPTION
1 Ethernet Port Plug an Ethernet cable from a switch, hub, or router into this port.
2 USB Connector Plug this connector into a USB port on your PC (use USB 3.0 for best performance).
12
5D-Link DUB-1312 User Manual
Section 2 - Installation
Software Installation
Insert the CD included with the DUB-1312 into your computer’s DVD or CD drive, then proceed to the appropriate installation
section on the following pages according to your operating system.
Note: If the user interface does not start up, please go to the Autorun folder in your PC’s CD drive and open Autorun.exe manually.
After you have inserted the CD into the CD drive, the DUB-1312 user interface
menu screen will appear. Click on Install to begin the DUB-1312 driver
installation. The InstallShield Wizard will then pop up and run automatically.
Note: The DUB-1312 user interface may dier in appearance depending on
your region.
Windows 7
6D-Link DUB-1312 User Manual
Section 2 - Installation
When the InstallShield Wizard is completed, plug the DUB-1312 into your PC
and the driver software installation will be completed automatically.
When the Windows 7 driver installation is complete, please then proceed to
”Connecting the Adapter to a Network” on page 16.
7D-Link DUB-1312 User Manual
Section 2 - Installation
Windows Vista
After you put the CD into the CD drive, the DUB-1312 user interface menu
screen will appear. Click on Install to begin the DUB-1312 driver installation.
The InstallShield Wizard will then pop up.
This driver is not WHQL signed. If you receive a warning message, you will
have to accept the unsigned driver installation in order to continue. Windows
Vista x64 user will have need to disable WHQL checking in order to install
the driver.
Note: The DUB-1312 user interface may dier in appearance for dierent
regions.
Plug the DUB-1312 into your PC and the driver software installation will be
completed automatically.
When the Windows Vista driver installation is complete, you can connect
the DUB-1312 to a USB port on your computer. Please then proceed to
”Connecting the Adapter to a Network” on page 16.
