Cornelius 2306 User manual

191933 12/9/96

IMICORNELIUSINC.

OneCorneliusPlace

Anoka.MN55303-6234

Telephone(800)238--3600

Facsimile(612)422--3246

INSTALLATION INSTRUCTIONS

KIT,P/N 2306

Forinstalling Scotsman Model CM450,500,&650 SeriesIceMakerson RemcortModel DB200 SeriesIce/

Drinkdispenser.

1.Bin Level Control

A.Locate and drill three (3)5/16”diameterholes(Ref. Fig.1).

B. Install mounting clamps.

2.Seal icemakertotop ofDispenserasfollows:

A.Run a bead ofRTVon the dispensercoveraround the outline of the icemakerand inside edge ofcov-

eropening.

B.Seticemakerontocoverand install binlevelthermostatcapillarytube inclampsand tighten screws

(Ref. Fig 1).Position icemakeras shown.

C.Wipe awayexcess RTV.

3.SecureicemakertoDispenserwithmounting bracketsas show.Drill holesand install sheetmetalscrews

provided intoicemakercabinetand dispensercover.Screwsmustnotinterferewithicemakercompo-

nents.

4. Install adhesive backed gasketstriptoremovablelid,and install withscrewprovided.

5.Followthe manufacturer’sinstructionstocompletethe installation of the icemaker.Binlevelthermostat

capillarytube mustnotinterferewith agitator.

29193312/9/96

2808028080

24 30

ROUTEICEMAKER BINLEVEL

THERMOSTATCAPILLARYTUBE

AS SHOWN. INSTALL ON

HOPPER AS SHOWNINFIG.1

ICEMAKERTOBE

FLUSHWITH BACK

EDGEOFCOVER.

APPLYRTVAROUND INSIDE

OFICEMAKEROUTLINEON

DISPENSER COVERTO

FORMASEAL.

REMOVE SCREWSAND TURN

BRACKETSAROUND 180_.

REPLACE SCREWS.USING

BRACKETASTEMPLATE,

DRILL (4).136 DIA.HOLES

INTOICEMAKER CABINET

FORSHEETMETALSCREWS

PROVIDED.DRILLINGISNOT

TOINTERFEREWITH

ICEMAKER COMPONENTS.

REMOVABLEFRONT LID

FORMANUALICEFILLING.

ADD ADHESIVE BACKEDGAS-

KETSTRIPS TOREMOVABLELID.

391933 12/9/96

15”

4--5/8

1”

DRILL 5/16 DIA.HOLES FOR8--32

WELD NUT

PLASTICTUBING

USE ASREQUIREDLARGECLAMP

(IFNEEDED)

CAPILLARYTUB-

ING

TOP-

VIEW

ICEMAKER

FRONTWALL

OFHOPPER

THERMOSTAT

CAPILLARYTUBE

1--5/8

INSERT8-32 WELL NUTSINTO5/16

DIA.HOLES,TIGHTENINGSCREWS

WILL SECURE

BINLEVEL THERMOSTATCAPILLARY

TUBINGASSEMBLY

LOCATEAND ADD

CLAMPHOLEIF

NEEDEDTORETAIN

CAPILLARYTUBING
