Black Box 39625 User manual

Black Box Corporation • 1000 Park Drive • Lawrence, PA 15055-1018 • Tech Support: 72 -7 6-5500 • www.blackbox.com • e-mail: [email protected]

11/26/2003 #22 88

Black Box Corporation.

Fast, transparent,

dial-in access for

the keyholder.

No passwords or

dialback calls.

Hardware-based

authentication uses

dynamically changing

encrypted ID codes to

block hackers.

Operates with any C

and any modem.

Defeats bad calls

within a half a second.

Any unit can act as a

lock or key.

Provide hassle-free access for legitimate

users while keeping out hackers.

KeyFeatures

LOCKANDKEYSET

ive quick, easy, dial-in access

to authorized users while

keeping out dangerous hackers.

The Lock and Key Set will give

you the peace of mind you need

without the headache of

passwords or dialbacks.

The Lock and Key Set is an

authentication system for dial

modem security. The lock installs

between the receiving modem

and analog line at your secured

site; the key installs between the

remote caller’s modem and

analog line. The lock trans-

parently passes calls made from

the modem with the key, but it

prevents all other calls from

connecting to the modem at your

secured site.

By special-ordering more

auxiliary units, you can expand

your secure system. There’s only

one master lock in each system.

It may be used as a functional

lock or key, but it’s also used to

program the other locks and keys.

Each master lock has a different

factory-programmed system ID

code that becomes a part of the

encrypted handshake. Call

Technical Support for a quote on

individual auxiliary units.

Note: Each Lock and Key Set

has a unique system code, so

MODEM TELCO

1234

<SWT>

LOCK KEY

MODEMTELCO

locks or keys from one system

can’t be used on another.

Switches: Master unit: -position

DIP switch; Auxiliary unit: Slide

switch (Lock or Key)

Connectors: (2) RJ-11 jacks with

12-inch (30.5-cm) RJ-11 cable

included

Temperature Tolerance:

Operating: 32 to 122°F (0 to 50°C);

Storage: - 0 to +158°F

(- 0 to +70°C)

Humidit Tolerance: 5 to 95%,

noncondensing

Maximum Altitude: 10,000 feet

(30 8 m)

MTBF: 86,000 hours

Power: From the telco line

Size: Lock: 0.8"H x 3. "W x 1.7"D

(2 x 8.6 x .3 cm);

Key: 0.8"H x 3"W x 1.7"D

(2 x 7.6 x .3 cm)

Weight: 0.3 lb. (0.1 kg)

Specifications

Ordering Information

ITEM CODE

Lock and Key Set.............................................................39625

You might also need

Phone Line Surge Protector...............................SP365A-R2

U.S. Robotics 56K V.92 Data Faxmodem............USR5686E
