BGS technic 9246 User manual

BGS technic KG

Bandwirkerstr. 3

D-42929 Wermelskirchen

Tel.: 02196 720480

Fax.: 02196 7204820

mail@bgs-technic.de

www.bgstechnic.com

BGS 9246

Workshop Press | 20 t

FEATURE

1. Used for parts straightening, bending and pressing.

2. Multi-position bed for work height adjustment.

3. With air pump can reduce labor and improve working efficiency

WARNING

•This press is designed and intended for use by properly trained and experienced personnel only.

If you are not familiar with the proper and safe operation of a hydraulic press, do not use until

proper training and knowledge has been obtained.

•Do not operate this press beyond it rated capacity.

•DO NOT compress springs or other objects that could be ejected from the press. DO NOT

compress objects that could shatter.

•Please understand the max. working stroke before operate, Do not overload the max. working

stroke, so as not to damage parts.

•Check the press for loose or damaged parts before each operation. Replace damaged parts and

tighten all loose bolts before operating.

•Some parts being pressed may have a tendency to pop out of the press or explode under

pressure. Protect yourself accordingly.

BGS technic KG

Bandwirkerstr. 3

D-42929 Wermelskirchen

Tel.: 02196 720480

Fax.: 02196 7204820

mail@bgs-technic.de

www.bgstechnic.com

OPERATION

1. Place work piece on bed frame.

2. Locate and close release valve.

3. Pump handle until the ram nears work piece.

4. Apply load to work piece by pumping handle. Do not overload work piece.

5. Remove load from work piece by turning release valve. Stabilize work piece so it does not fall

while pressure is released.

6. Remove work piece after ram is fully retracted.

MAINTENANCE

•

Periodically, lightly oil all moving parts including the pump piston and hydraulic ram.

•

Check hydraulic connections and hoses before each use.

•

Do not use if cut, damaged, leaking or otherwise damaged connections and/or hoses are noted

DISASSEMBLE DRAWING

No.

Description

Qty.

Pressure gauge

Damping nut M16

Washer M16

Jack

Pole

Bolt M1

0×15

Washer M10

Tighter the scres

Damping nut M10

Connect board

Bolt M1

0×25

Leg

Handle

Pump

Adjust beam

Arbor plate

Limit circle

Limit ring

Cross beam

Bolt M1

6×40

BGS technic KG

Bandwirkerstr. 3

42929 Wermelskirchen

Tel.: 02196 720480

Fax.: 02196 7204820

mail@bgs-technic.de

www.bgstechnic.com

EU-Konformitätserklärung

EC DECLARATION OF CONFORMITY

DÉCLARATION „CE“ DE CONFORMITE

DECLARATION DE CONFORMIDAD UE

Wir erklären in alleiniger Verantwortung, dass die Bauart der:

We declare that the following designated product:

Nous déclarons sous propre responsabilité que ce produit:

Declaramos bajo nuestra sola responsabilidad que este producto:

Werkstatt-Presse 20 to ( BGS Art. 9246 )

Hydraulic Shop Press

Presse d’atelier

Prensa de taller

folgenden einschlägigen Bestimmungen entspricht:

complies with the requirements of the:

est en conformité avec les réglementations ci-dessous:

esta conforme a las normas:

Machinery Directive 2006/42/EC

Angewandte Normen:

Identification of regulations/standards:

Norme appliquée:

Normas aplicadas:

EN ISO 12100-1:2003

EN ISO 12100-2:2003

EN 1494:2000

Certification No. : GB/1067/1528/09 / ZD07202

Reference: CE2009WF119/9

Wermelskirchen, den 24.01.2014

ppa.

Frank Schottke, Prokurist

BGS technic KG, Bandwirkerstrasse 3, D-42929 Wermelskirchen
