Avision FL-0914S User manual

Mobile Scanner

User’s Manual

Regulatory model: FL-0914S

Avision Inc.

Trademarks

Microsoft is a U.S. registered trademark of Microsoft

Corporation.

Windows and MS-DOS are trademarks of Microsoft Corporation.

IBM, IBM PC are registered trademarks of International Business

Machines Corp.

ENERGY STAR®is a U.S. registered mark.

Other brands and product names herein are trademarks or

registered trademarks of their respective holders.

reproduced, transmitted, transcribed, stored in a retrieval

system, or translated into any language or computer language,

in any form or by any means, electronic, mechanical, magnetic,

optical, chemical, manual, or otherwise, without the prior

written permission of Avision Inc.

Material scanned by this product may be protected by

governmental laws and other regulations, such as copyright

laws, the customer is solely responsible for complying with all

such laws and regulations.

Warranty

The information contained in this document is subject to

change without notice.

Avision makes no warranty of any kind with regard to this

material, including, but not limited to, the implied warranties

of fitness for a particular purpose.

Avision shall not be liable for errors contained herein or for

incidental or consequential damages in connection with the

furnishing, performance, or use of this material.

FCC Radio Frequency Interference Statement

This product has been tested and found to comply with the

limits for a class B digital device, pursuant to Part 15 of

the FCC rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful

interference, and (2) this device must accept any

interference received, including interference that may

cause undesired operation. The FCC Class B limits are

designed to provide reasonable protection against harmful

interference in a residential installation. This equipment

generates, uses, and can radiate radio frequency energy

and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio

communications. However, there is no guarantee that

interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or

television reception, which can be determined by turning

the equipment off and on, the user is encouraged to try to

correct the interference by one or more of the following

measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and

receiver.

Connect the equipment into an outlet on a circuit

different from that to which the receiver is connected.

Consult your point of purchase or service representative

for additional suggestions.

CE Warning

This product satisfies the Class B limits of EN55022, EN55024

and safety requirements of EN 60950.

iii

Disposal of Waste Equipment

This symbol on the product or on its packaging indicates that

the product can not be disposed of with your other household

waste. Instead it should be sent to appropriate facilities for

recovery and recycling in an effort to protect human health and

the environment. Fore more information about where you can

drop off your waste equipment for recycling, please contact

your local city office, your household waste disposal service or

the shop where you purchased the product.

As an ENERGY STAR®Partner, Avision Inc. has

determined that this product meets the ENERGY

STAR guidelines for energy efficiency.

*This machine is certified as Class 1 laser product. This means

that this machine does not produce hazardous laser radiation.

System Requirements

¾IBM compatible PC 586, Pentium or higher

¾Microsoft Windows 2000, Windows XP, Windows Vista,

Windows 7

¾USB port 2.0 (compatible with USB 1.1)

¾At least 100 MB of free hard disk space (500 MB is

recommended)

¾At least 128 MB of system memory (512 MB of RAM is

recommended)

At least 1 GB of RAM for Windows Vista/7

¾A CD-ROM drive

Table of Contents

1. Introduction..............................................1-1

2. Scanner Installation..................................2-1

2.1 Installing the Scanner Driver and Cables .......2-1

2.1.1 Installing the Scanner Driver .............2-2

2.1.2 Connecting to Computer ...................2-3

3. Completing Your First Scan .......................3-1

3.1 Placing Your Document ...............................3-1

3.1.1 Notice on Using the ADF....................3-1

3.1.2 Loading Paper to the Paper Feed Slot..3-2

3.1.3 Loading A Card to the Paper Feed Slot 3-3

3.2 Verifying Your Scanner Installation ...............3-4

3.2 A Glance of the Scanner Properties Dialog Box3-8

3.3 Scan from the scanner button......................3-9

4. Using the Scanner Properties Dialog Box ..4-1

4.1 Buttons on the Scanner Properties Dialog Box 4-2

4.2 The Image Tab ..........................................4-4

4.2.1 The Image Selection Box...................4-5

4.2.2 Other Image Options........................4-8

4.2.3 Scanning color images.................... 4-18

4.2.4 Scanning grayscale images.............. 4-19

4.2.5 Scanning B&W images.................... 4-19

4.2.6 Editing Profiles............................... 4-20

4.3 The Compression Tab ............................... 4-23

4.4 The Color Dropout Tab.............................. 4-25

4.4.1 Color Dropout Selection .................. 4-25

4.4.2 Other Color Dropout Options............ 4-27

4.5 The Paper Tab ......................................... 4-29

4.5.1 Cropping....................................... 4-30

4.5.2 Other Paper Selection..................... 4-32

4.6 The Multi-Feed Detection Tab..................... 4-35

4.6.1 Relative to Document ..................... 4-43

vii

4.7 The Preview Tab ...................................... 4-46

4.8 The Options Tab....................................... 4-47

4.9 The Setting Tab ....................................... 4-55

4.10 The Imprinter Tab ................................. 4-58

4.11 The Information Tab .............................. 4-61

5. The ISIS Interface Operation....................5-1

6. Using the Buttons......................................6-1

6.1 Installing Button Manager............................6-1

6.2 Checking Button Configurations Before

Scanning..................................................6-1

6.3 Scanning From One Touch of the Button........6-3

7. Care and Maintenance...............................7-1

7.1 Cleaning the Scanner Glass .........................7-1

8. Troubleshooting........................................8-1

8.1 Clearing a Paper Jam..................................8-1

8.2 Frequently Asked Questions.........................8-1

8.3 Technical Service .......................................8-2

9. Specifications............................................9-1

Index .................................................................. a

1-1

1. Introduction

Congratulations on your purchase of the color image

scanner. With this scanner, you can scan documents at a

fast rate to increase productivity.

Before you install and operate the new scanner, please take

a few minutes to read through this manual. It provides

proper instructions for you to unpack, install, operate and

maintain the scanner.

The following figure indicates the package contents. Please

check all the items against your checklist. If you do not

receive all the items, please contact your authorized local

dealer immediately.

1. Scanner

2. Quick guide/CD

3. USB cable

Note:

Please unpack the packing carefully, and check the contents

against the checklist. If any items are missing or damaged,

please contact your dealer immediately.

2 3

2. Scanner Installation

Precautions

Keep the scanner out of direct sunlight. Direct

exposure to the sun or excessive heat may cause

damage to the unit.

Do not install the scanner in a humid or dusty place.

Place the scanner securely on an even, flat surface.

Tilted or uneven surfaces may cause mechanical or

paper-feeding problems.

Retain the scanner box and packing materials for

shipping purposes.

2.1 Installing the Scanner Driver and Cables

Note:

1. The Windows system CD may be required when installing

on some PC’s.

2. To ensure your computer can identify the USB scanner,

please install scanner driver first before connecting the

scanner to your computer.

2-1

2.1.1 Installing the Scanner Driver

1. Place the supplied CD-ROM onto your CD-ROM drive.

2. The software installation graphic appears. If not, run

“setup.exe”.

Contents on the installation graphic:

•Install Button Manager: To use the buttons on

the scanner, you need to install Button Manager. To

ensure Button Manager works properly, please FIRST

install Button Manager before installing the scanner

driver.

•Install Scanner Driver: To communicate with your

scanner, you need to install the scanner driver. After

installing the Button Manager software, click Install

Scanner Driver to install the scanner driver on

your computer.

2-2
