Avalue Technology ERX-G41 User manual

Part No: E2047RX4100R

ERX-G41

Intel®G41 LGA775 socket for Intel®Core™ 2 Quad

Micro-ATX Motherboard

User’s Manual

2nd Ed –15 November 2011

ERX-G41

ERX-G41 User’s Manual

FCC Statement

THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS

SUBJECT TO THE FOLLOWING TWO CONDITIONS:

(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.

(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING

INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS

FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.

THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST

HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A

COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN

RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTALLED AND USED IN

ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL

INTERFERENCE TO RADIO COMMUNICATIONS.

OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE

HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO

CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.

No part of this document may be reproduced, copied, translated, or transmitted in any form

or by any means, electronic or mechanical, for any purpose, without the prior written

permission of the original manufacturer.

Trademark Acknowledgement

Brand and product names are trademarks or registered trademarks of their respective

owners.

Disclaimer

Avalue Technology Inc. reserves the right to make changes, without notice, to any product,

including circuits and/or software described or contained in this manual in order to improve

design and/or performance. Avalue Technology assumes no responsibility or liability for the

use of the described product(s), conveys no license or title under any patent, copyright, or

masks work rights to these products, and makes no representations or warranties that

these products are free from patent, copyright, or mask work right infringement, unless

otherwise specified. Applications that are described in this manual are for illustration

purposes only. Avalue Technology Inc. makes no representation or warranty that such

application will be suitable for the specified use without further testing or modification.

User’s Manual

Life Support Policy

Avalue Technology’s PRODUCTS ARE NOT FOR USE AS CRITICAL COMPONENTS IN

LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT THE PRIOR WRITTEN APPROVAL

OF Avalue Technology Inc.

As used herein:

1. Life support devices or systems are devices or systems which, (a) are intended for

surgical implant into body, or (b) support or sustain life and whose failure to perform,

when properly used in accordance with instructions for use provided in the labeling, can

be reasonably expected to result in significant injury to the user.

2. A critical component is any component of a life support device or system whose failure

to perform can be reasonably expected to cause the failure of the life support device or

system, or to affect its safety or effectiveness.

A Message to the Customer

Avalue Customer Services

Each and every Avalue’s product is built to the most exacting specifications to ensure

reliable performance in the harsh and demanding conditions typical of industrial

environments. Whether your new Avalue device is destined for the laboratory or the factory

floor, you can be assured that your product will provide the reliability and ease of operation

for which the name Avalue has come to be known.

Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To

ensure you get the full benefit of our services, please follow the instructions below carefully.

Technical Support

We want you to get the maximum performance from your products. So if you run into

technical difficulties, we are here to help. For the most frequently asked questions, you can

easily find answers in your product documentation. These answers are normally a lot more

detailed than the ones we can give over the phone. So please consult the user’s manual

first.

To receive the latest version of the user’s manual; please visit our Web site at:

http://www.avalue.com.tw/

If you still cannot find the answer, gather all the information or questions that apply to your

problem, and with the product close at hand, call your dealer. Our dealers are well trained

ERX-G41

ERX-G41 User’s Manual

and ready to give you the support you need to get the most from your Avalue’s products. In

fact, most problems reported are minor and are able to be easily solved over the phone.

In addition, free technical support is available from Avalue’s engineers every business day.

We are always ready to give advice on application requirements or specific information on

the installation and operation of any of our products. Please do not hesitate to call or e-mail

us.

Headquarters and Branch

Avalue USA

Avalue Technology Inc.

7F, 228, Lian-cheng Road, Chung Ho City, Taipei,

Taiwan

Tel:+886-2-8226-2345

Fax : +886-2-8226-2777

Information :sa[email protected]

Service: service@avalue.com.tw

Avalue Technology Inc.

9 Timber Lane, Marlboro, NJ 07746-1443

Tel : (732) 414-6500

Fax : (732) 414-6501

Information : sales@avalue-usa.com

Service : support@avalue-usa.com

BCM Advanced Research

Avalue Europe

BCM Advanced Research

an Avalue Company

7 Marconi, Irvine, CA92618

Tel: +1-949-470-1888

Fax: +1-949-470-0971

Information: BCMSales@bcmcom.com

Web: www.bcmcom.com

Avalue Europe A/S

Moelledalen 22C, 3140

Aalsgaarde, Denmark

Tel: +45-7025-0310

Fax:+45-4975-5026

Information: sales.e[email protected]

Service: service.europ[email protected]

Avalue China

Avalue Japan

Avalue Technology Inc.

Room 805, Building 9,No.99 Tianzhou Rd.,

Caohejing Development Area,

Xuhui District, Shanghai

Tel: +86-21-5169-3609

Fax:+86-21-5445-3266

Information: sales.chi[email protected]

Service: ser[email protected].tw

Avalue Technology Inc.

2F keduka-Bldg, 2-27-3 Taito,

Taito-Ku, Tokyo 110-0016 Japan

Tel : +81-3-5807-2321

Fax : +81-3-5807-2322

Information : sales.j[email protected].tw

Service : service@avalue.com.tw

User’s Manual

Product Warranty

Avalue warrants to you, the original purchaser, that each of its products will be free from

defects in materials and workmanship for two years from the date of purchase.

This warranty does not apply to any products which have been repaired or altered by

persons other than repair personnel authorized by Avalue, or which have been subject to

misuse, abuse, accident or improper installation. Avalue assumes no liability under the

terms of this warranty as a consequence of such events. Because of Avalue’s high

quality-control standards and rigorous testing, most of our customers never need to use our

repair service. If any of Avalue’s products is defective, it will be repaired or replaced at no

charge during the warranty period. For out-of-warranty repairs, you will be billed according

to the cost of replacement materials, service time, and freight. Please consult your dealer

for more details. If you think you have a defective product, follow these steps:

1. Collect all the information about the problem encountered. (For example, CPU type and

speed, Avalue’s products model name, hardware & BIOS revision number, other

hardware and software used, etc.) Note anything abnormal and list any on-screen

messages you get when the problem occurs.

2. Call your dealer and describe the problem. Please have your manual, product, and any

helpful information available.

3. If your product is diagnosed as defective, obtain an RMA (return material authorization)

number from your dealer. This allows us to process your good return more quickly.

4. Carefully pack the defective product, a complete Repair and Replacement Order Card

and a photocopy proof of purchase date (such as your sales receipt) in a shippable

container. A product returned without proof of the purchase date is not eligible for

warranty service.

5. Write the RMA number visibly on the outside of the package and ship it prepaid to your

dealer.

ERX-G41

ERX-G41 User’s Manual

Contents

1. Getting Started .............................................................................................................7

1.1 Safety Precautions.............................................................................................7

1.2 Packing List........................................................................................................7

1.3 Document Amendment History..........................................................................8

1.4 Manual Objectives .............................................................................................9

1.5 System Specifications......................................................................................10

1.6 Architecture Overview –Block Diagram...........................................................11

2. Hardware Configuration..............................................................................................12

2.1 Product Overview.............................................................................................13

2.2 Installation Procedure......................................................................................14

2.2.1 Main Memory ........................................................................................15

2.3 Jumper and Connector List..............................................................................17

2.4 Setting Jumpers & Connectors ........................................................................19

3. Mechanical Drawing.......................................................................................................22

User’s Manual

1. Getting Started

1.1 Safety Precautions

Warning!

Always completely disconnect the power cord from your

chassis whenever you work with the hardware. Do not

make connections while the power is on. Sensitive

electronic components can be damaged by sudden power

surges. Only experienced electronics personnel should

open the PC chassis.

Caution!

Always ground yourself to remove any static charge before

touching the CPU card. Modern electronic devices are very

sensitive to static electric charges. As a safety precaution,

use a grounding wrist strap at all times. Place all electronic

components in a static-dissipative surface or static-shielded

bag when they are not in the chassis.

1.2 Packing List

Before you begin installing your single board, please make sure that the

following parts have been shipped.

1 x Intel G41 Micro ATX Main board

1 x CD-ROM containing the following:

User’s Manual in PDF file

Drivers

1 x COM1 Cable (9P/260mm)

1 x ATA66 IDE Cable (40P)

2 x SATA Cable Kit (SATA/Power)

1 x I/O Shield

1 x Printer cable d-sub 25P F/2*13P-2.0 35CM

ERX-G41

ERX-G41 User’s Manual

1.3 Document Amendment History

Revision

Date

Comment

1st

January

2011

Initial Release

2nd

November

2011

Packing list update

Company information update

User’s Manual

1.4 Manual Objectives

This manual describes in detail the Avalue Technology ERX-G41 motherboard.

We have tried to include as much information as possible but we have not duplicated

information that is provided in the standard IBM Technical References, unless it proved to

be necessary to aid in the understanding of this board.

We strongly recommend that you study this manual carefully before attempting to interface

with ERX-G41 series or change the standard configurations. Whilst all the necessary

information is available in this manual we would recommend that unless you are confident,

you contact your supplier for guidance.

Please be aware that it is possible to create configurations within the CMOS RAM that

make booting impossible. If this should happen, clear the CMOS settings, (see the

description of the Jumper Settings for details).

If you have any suggestions or find any errors concerning this manual and want to inform

us of these, please contact our Customer Service department with the relevant details.

ERX-G41

ERX-G41 User’s Manual

1.5 System Specifications

System

CPU

Intel® LGA775 socket for Intel® Core™2 Quad / Core™2 Duo Processors

Compatible with Intel® 06 processors Support Intel® next generation 45nm

Multi-Core CPU

FSB

1333 / 1066 / 800 MHz

BIOS

AMI 32 Mb SPI

System Chipset

Intel G41/ICH7R

I/O Chipset

Winbond W83627DHG-A

Memory

2 x 240 pin DDR DIMM sockets supports DDRII memories 667/800 MHz up to 4GB

Watchdog Timer

Reset: 1 sec.~255 min. and 1 sec. or 1 min./step

H/W Status Monitor

Monitoring temperatures, voltages, and cooling fan status. Auto throttling control

when CPU overheats

Expansion Slots

1 x PCI-E x16 slot, 1x PCIe x4 slot

2 x PCI Slots (PCI 2.3 compliant)

DIO

16Bit

S3 / S4

Yes

TPM

TPM1.2 (InfineonR TPM chip 9635 TT 1.2 on board, optional)

System

Wake up on LAN or

Ring

WOL

Smart Fan Control

Yes, CPU FAN

Display

Chipset

IntelR Graphics Media Accelerator X4500 integrated

Display Memory

Intel DVMT 4.0 supports up to 352 MB memory

Max. Resolution

2048 x 1536 bpp(@ 75Hz)

VGA

On board

LVDS

On board

DVI / HDMI

Support by ADD2 card

Secondary VGA

LVDS+VGA, ADD2+VGA/LVDS

Audio

Audio Codec

RealtekR ALC888, 5.1 +2 with two independent Streaming

Audio Interface

Line-out, Line-in, Mic-in, SPDIF header

Ethernet

LAN1

RealtekR RTL8111D GbE LAN

LAN2

RealtekR RTL8111D GbE LAN

Other manuals for ERX-G41

Table of contents

Other Avalue Technology Motherboard manuals

Avalue Technology

Avalue Technology EMX-H61 User manual

Avalue Technology

Avalue Technology BC680R User manual

Avalue Technology

Avalue Technology EAX-C236KP-B1 User manual

Avalue Technology

Avalue Technology ECM-WHL User manual

Avalue Technology

Avalue Technology EMX-CDD User manual

Avalue Technology

Avalue Technology EMX-BYT3 User manual

Avalue Technology

Avalue Technology HPM-SRSUA User manual

Avalue Technology

Avalue Technology EMX-ZXEDP User manual

Avalue Technology

Avalue Technology ENX-LX800 User manual

Avalue Technology

Avalue Technology ENX-US15WP User manual

Avalue Technology

Avalue Technology ECM-BSW User manual

Avalue Technology

Avalue Technology REV-SA01 User manual

Avalue Technology

Avalue Technology ECM-BSWA User manual

Avalue Technology

Avalue Technology ERX-H110KP User manual

Avalue Technology

Avalue Technology HPM-246UA User manual

Avalue Technology

Avalue Technology EMX-QM77 User manual

Avalue Technology

Avalue Technology EMX-B75 User manual

Avalue Technology

Avalue Technology EMX-QM57 User manual

Avalue Technology

Avalue Technology EMX-KBLU2P User manual

Avalue Technology

Avalue Technology EMX-945GSE-A1-DVIR User manual

Avalue Technology

Avalue Technology EMX-Q87 User manual

Avalue Technology

Avalue Technology EAX-Q77 User manual

Avalue Technology

Avalue Technology EAX-Q87 User manual

Avalue Technology

Avalue Technology EMX-KBLUP User manual

Popular Motherboard manuals by other brands

DFI

DFI SD170 user manual

ASROCK

ASROCK ROMED8-2T user manual

Asus

Asus P2L97A user manual

Winmate

Winmate IC70 user manual

Asus

Asus MES-B user manual

Grantech

Grantech SYS8F377VGGA-3OMN user manual

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR user guide

Gigabyte

Gigabyte GA-9IVDT user manual

Texas Instruments

Texas Instruments ADS8372EVM user guide

Commell

Commell MS-C73 user manual

IBT Technologies

IBT Technologies MB860 user manual

Nvidia

Nvidia TEGRA DG-04927-001_V01 user guide

Biostar

Biostar M7VIT Bravo Description

Intel

Intel D33217CK specification

Asus

Asus F1A55-M LX PLUS R2.0 user manual

EPC

EPC EPC9147C quick start guide

Asus

Asus EX-B760M-V5 D4 quick start guide

EPOX

EPOX MU-8KHA0010 user manual
