Avalue Technology PPC-1501 User manual
Part No. E2017PPC0A3R
PPC 15”~22”W Series
15”/17”/18”W/21”W/22”W Plastic Touch Panel PC
Quick Reference Guide
4th– 03 March, 2011
Copyright Notice
Copyright © 2011 Avalue Technology Inc., ALL RIGHTS RESERVED.
PPC 15”~22”W Series
2 PPC 15”~22”W Series Quick Reference Guide
Contents
1.1 Safety Precautions ................................................................................................3
1.2 Packing List...........................................................................................................3
1.3 System Specifications ...........................................................................................4
1.4 System Overview.................................................................................................14
1.4.1 Front View.................................................................................................................................. 14
1.4.1.1 Front View for PPC-21W05.............................................................................................................................14
1.4.2 Rear View................................................................................................................................... 15
1.5 System Dimensions.............................................................................................16
1.5.1 PPC 15” Series.......................................................................................................................... 16
1.5.2 PPC 17” Series.......................................................................................................................... 17
1.5.3 PPC 18” Widescreen Series...................................................................................................... 18
1.5.4 PPC 21” Widescreen Series...................................................................................................... 19
1.5.5 PPC 22” Widescreen Series...................................................................................................... 20
2.1 Jumper and Connector Setting, Driver and BIOS Installing.................................21
2.2 Installing Hard Disk & Memory ............................................................................22
2.2.1 Install 2.5” HDD.......................................................................................................................... 22
2.3 Installing Panel PC Stand....................................................................................25
2.4 Installing Optional MSR Module ..........................................................................26
Quick Reference Guide
PPC 15”~22”W Series Quick Reference Guide 3
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 Packing List
z1 x PPC 15”/17”/18”W/21”W/22”W Series Panel PC
z1 x CD/DVD-ROM contains the followings:
—Quick Reference Guide (this manual in PDF file)
—Ethernet driver and utilities
—VGA drivers and utilities
—Audio drivers and utilities
—WiFi drivers and utilities
—Touch controller drivers and utilities
z1 x Power Adapter
z1 x Stand for Panel PC (with 6 screws & 5 rubber-foot)
z1 x MSR set with bracket (for optional MSR)
PPC 15”~22”W Series
4 PPC 15”~22”W Series Quick Reference Guide
1.3 System Specifications
Panel
Specifications PPC-1501 PPC-1701 PPC-22W01
LCD size 15", 4:3 17", 4:3 22", 16:10
Display type XGA TFT SXGA TFT WSXGA TFT
Resolution 1024 x 768 1280 x 1024 1680 x 1050
Color 16.7M 16.7M 16.7M
Pixel pitch 0.297mm(H) x
0.297mm(V)
0.264mm(H) x
0.264mm(V)
0.282mm(H) x
0.282mm(V)
Luminance 300 cd/m² 380 cd/m² 300 cd/m²
Contrast ratio 700 1000 700
Viewing angle 70(U), 70(D), 75(L),
75(R) 80(U), 80(D), 85(L), 85(R) 80(U), 80(D), 85(L),
85(R)
Response time 8 ms 5 ms 5 ms
Backlight 2 x CCFL 4 x CCFL 4 x CCFL
Touch Type 5 Wires resistive 5 Wires resistive 5 Wires resistive
Touch Light Transmission 80% 80% 80%
Touch Interface USB USB USB
System
Board EBM-CX700
CPU Onboard VIA Eden V4 ULV 1G (3.5W)
System Chipset VIA CX700M
I/O Chip VIA VT1211
Memory One 200-pin DDR2 SODIMM socket, supports up to 1GB DDR2 400/533
SDRAM
SSD One CF socket by IDE secondary slave channel supports Type I / II Compact
Flash Card
HDD Drive Bay One 2.5" SATA HDD or optional 44-pin enhanced IDE HDD
WiFi Optional USB WiFi 802.11b/g
Watchdog Timer Reset: 1 sec.~255 min. and 1 sec. or 1 min./step
H/W Status Monitor Monitoring system temperature and voltage.
Auto throttling control when CPU overheats
Expansion Slot 1 x Mini PCI
Quick Reference Guide
PPC 15”~22”W Series Quick Reference Guide 5
Rear Panel I/O
Serial Port 1 x RS-232
Ethernet 2 x RJ-45
VGA 1 x DB-15
Audio port 1 x Line out
USB 2 x USB 2.0
Speaker 2W x 2
Mechanical & Evironmental
System Fan Passive Heat Sink
Color Front & Rear panel Black (Plastics)
Mounting Wall/Stand/VESA 100 mm X 100 mm
Power Input 100~250 Vdc/ 47~63 Hz
Power Output +12 Vdc / 5 A (60W)
Operating Temperature 0 to 40°C (32 to 140°F )
Storage Temperature -10°C to 50°C
Relative Humidity 0%~90% relative humidity, non-condensing
Dimensions 340 x 285 x 53 mm 372 x 324 x 53 mm 510 x 352 x 55 mm
Weight 2.79 Kgs 3.79 Kgs 4.79 Kgs
PPC 15”~22”W Series
6 PPC 15”~22”W Series Quick Reference Guide
Panel
Specifications PPC-1503 PPC-1703
LCD size 15", 4:3 17", 4:3
Display type XGA TFT SXGA TFT
Resolution 1024 x 768 1280 x 1024
Color 16.7M 16.7M
Pixel pitch 0.297mm(H) x 0.297mm(V) 0.264mm(H) x 0.264mm(V)
Luminance 300 cd/m² 380 cd/m²
Contrast ratio 700 1000
Viewing angle 70(U), 70(D), 75(L), 75(R) 80(U), 80(D), 85(L), 85(R)
Response time 8 ms 5 ms
Backlight 2 x CCFL 4 x CCFL
Touch Type 5 Wires resistive 5 Wires resistive
Touch Light Transmission 80% 80%
Touch Interface USB USB
System
Board EBM-945GSE
CPU Onboard Intel N270 Atom processor 1.6GHz, (2.5W)
System Chipset Intel 945GSE + ICH7-M
I/O Chip ITE IT8712F/KX
Memory One 200-pin DDR2 SODIMM socket, supports up to 1 GB DDR2 400/533
SDRAM
SSD One CF socket by IDE secondary slave channel supports Type I / II Compact
Flash Card
HDD Drive Bay One 2.5" SATA HDD or optional 44-pin enhanced IDE HDD
WiFi Optional USB WiFi 802.11b/g
Watchdog Timer Reset: 1~65535 sec./min. and 1 min./step
H/W Status Monitor Monitoring system temperature and voltage. Auto throttling control when
CPU overheats
Expansion Slot One Mini PCI slot
Quick Reference Guide
PPC 15”~22”W Series Quick Reference Guide 7
Rear Panel I/O
Serial Port 1 x RS-232
Ethernet 1 x RJ-45
VGA 1 x DB-15
Audio port 1 x Line out
USB 2 x USB 2.0
Speaker 2W x 2
Mechanical & Evironmental
System Fan Passive Heat Sink
Color Front & Rear panel Black (Plastics)
Mounting Wall/Stand/VESA 100 mm X 100 mm
Power Input 100~250 Vdc/ 47~63 Hz
Power Output +12 Vdc / 5 A (60W)
Operating Temperature 0 to 40°C (32 to 140°F )
Storage Temperature -10°C to 50°C
Relative Humidity 0%~90% relative humidity, non-condensing
Dimensions 340 x 285 x 53 mm 372 x 324 x 53 mm
Weight 2.79 Kgs 3.79 Kgs
PPC 15”~22”W Series
8 PPC 15”~22”W Series Quick Reference Guide
Panel
Specifications PPC-18W03 PPC-22W03
LCD size 18.5", 16 : 9 22", 16:10
Display type WSGA TFT WSXGA TFT
Resolution 1366 x 768 1680 x 1050
Color 16.7M 16.7M
Pixel pitch 0.300mm(H) x 0.300mm(V) 0.282mm(H) x 0.282mm(V)
Luminance 300 cd/m² 300 cd/m²
Contrast ratio 300 700
Viewing angle 80(U), 80(D), 85(L), 85(R) 80(U), 80(D), 85(L), 85(R)
Response time 5 ms 5 ms
Backlight 2 x CCFL 4 x CCFL
Touch Type 5 Wires resistive 5 Wires resistive
Touch Light Transmission 80% 80%
Touch Interface USB USB
System
Board EBM-945GSE
CPU Onboard Intel N270 Atom processor 1.6GHz, (2.5W)
System Chipset Intel 945GSE + ICH7-M
I/O Chip ITE IT8712F/KX
Memory One 200-pin DDR2 SODIMM socket, supports up to 1 GB DDR2 400/533
SDRAM
SSD One CF socket by IDE secondary slave channel supports Type I / II Compact
Flash Card
HDD Drive Bay One 2.5" SATA HDD or optional 44-pin enhanced IDE HDD
WiFi Optional USB WiFi 802.11b/g
Watchdog Timer Reset: 1~65535 sec./min. and 1 min./step
H/W Status Monitor Monitoring system temperature and voltage. Auto throttling control when
CPU overheats
Expansion Slot One Mini PCI slot
Quick Reference Guide
PPC 15”~22”W Series Quick Reference Guide 9
Rear Panel I/O
Serial Port 1 x RS-232
Ethernet 1 x RJ-45
VGA 1 x DB-15
Audio port 1 x Line out
USB 2 x USB 2.0
Speaker 2W x 2
Mechanical & Evironmental
System Fan Passive Heat Sink
Color Front & Rear panel Black (Plastics)
Mounting Wall/Stand/VESA 100 mm X 100 mm
Power Input 100~250 Vdc/ 47~63 Hz
Power Output +12 Vdc / 5 A (60W)
Operating Temperature 0 to 40°C (32 to 140°F )
Storage Temperature -10°C to 50°C
Relative Humidity 0%~90% relative humidity, non-condensing
Dimensions 443 x 290 x 59.8 mm 510 x 352 x 55 mm
Weight 3.90 Kgs 4.79 Kgs
PPC 15”~22”W Series
10 PPC 15”~22”W Series Quick Reference Guide
Panel
Specifications PPC-1505 PPC-1705
LCD size 15", 4:3 17", 4:3
Display type XGA TFT SXGA TFT
Resolution 1024 x 768 1280 x 1024
Color 16.7M 16.7M
Pixel pitch 0.297mm(H) x 0.297mm(V) 0.264mm(H) x 0.264mm(V)
Luminance 300 cd/m² 380 cd/m²
Contrast ratio 700 1000
Viewing angle 70(U), 70(D), 75(L), 75(R) 80(U), 80(D), 85(L), 85(R)
Response time 8 ms 5 ms
Backlight 2 x CCFL 4 x CCFL
Touch Type 5 Wires resistive 5 Wires resistive
Touch Light Transmission 80% 80%
Touch Interface USB USB
System
Board EBM-PNV
CPU Onboard Intel® Atom™ D525 Dual-Core 1.8 GHz CPU
System Chipset Intel ICH8-M
I/O Chip Winbond W83627DHG
Memory Onboard 1 GB up to 2GB & one 204-pin SODIMM support up to 4 GB DDR3
800 SDRAM2
SSD One CF socket by IDE secondary slave channel supports Type I / II Compact
Flash Card
HDD Drive Bay One 2.5" SATA HDD
WiFi Optional USB or Mini PCIe WiFi module
Watchdog Timer Reset: 1 ~ 255min. and 1sec. or 1min./step
H/W Status Monitor Monitoring system temperature and voltage. Auto throttling control when
CPU overheats
Expansion Slot One Mini PCIe slot
