Audio Pro Cinema C4 Instruction manual
Tekniska data:
Typ:.......................................Basreflex
Bestyckning: (Skärmade)
Diskant:...................1” Soft Dome
Bas:............................4 x 3 1/2”
Delningsfrekvens:.......................6.000Hz
Frekvensomfång:..............70-20.000Hz
Känslighet: (1W / 1M)....................90 dB
Impedans:...................................8 ohm
Rek. förstärkareffekt:............10 - 100 W
Dimensioner:(BxHxD mm)..600x115x160
Technical data:
Enclosure:............................Bass reflex
Drive units: (Shielded)
Tweeter:................ 1” Soft Dome
Woofer:.......................4 x 3 1/2”
Crossover:.................................6.000Hz
Frequency range:..............70-20.000Hz
Sensitivity: (1W / 1M)....................90 dB
Impedance:..................................8 ohm
Amp. requirement:...............10 - 100 W
Dimensions:(WxHxD mm)...600x115x160
Placering:
See the enclosed Audio Pro instruction
manual for further information.
Se medföljande Audio Pro instruktions-
bok för ytterligare information.
Placement:
Audio Pro AB, Helsingborg, Sweden
Swedish/English
CINEMA C4
Cinema C4 Technical data.pmd 2003-07-02, 16:521
Charactéristiques:
Type:..................................Bass-reflex
Haut-parleur: (Avec blindage)
Tweeter:.................1” Soft Dome
Woofer:.......................4 x 3 1/2”
Fréquence de séparation:.........6.000Hz
Réponse en fréquence:.....70-20.000Hz
Sensibilité: (1W / 1M).....................90dB
Impédance:..................................8 ohm
Puissance d’entrée:..............10 - 100 W
Dimensions:(LxHxP mm)....600x115x160
Ôå÷íéêÜ óôïé÷åßá:Ôå÷íéêÜ óôïé÷åßá:
Ôå÷íéêÜ óôïé÷åßá:Ôå÷íéêÜ óôïé÷åßá:
Ôå÷íéêÜ óôïé÷åßá:
Ôýðïò:.................ÁíÜêaëáóç ìðÜóùí
ÌåãÜöùíá:(ÈùñáêéóìÝíá)
Ôïõßôåñ:.................................1"
Ãïýöåñ:.......................4 x 3 1/2”
Crossover:................................6.000Hz
Aðüêñéóç óõ÷íïôÞôùí:.... .70-20.000Hz
Åõáéóèçóßá: (1W / 1M)...................90dB
Áíôßóôáóç...................................8 ïhm
Åíßó÷õóç:................................10-100W
ÄéáóôÜóåéò:(ÐxYxB).....600x115x160mm
Emplacement:
Ãéá ðåñéóóüôåñåò ëåðôïìÝñåéåò
áíáöåñèåßôå óôï åã÷åéñßäéï ïäçãéþí.
Se référer au mode d’emploi ci-joint.
ÔïðïèÝôçóç:
Audio Pro AB, Helsingborg, Sweden
Français/Åëëçíéêá
CINEMA C4
Cinema C4 Technical data.pmd 2003-07-02, 16:522
Technische gegevens:
Soort:...............................................Basreflex
Speaker soort: (afgeschermd)
Tweeter:......................1” Soft Dome
Woofer:...............................4 x 3 1/2”
Crossover:.......................................6.000Hz
Freq. Bereik:...........................70-20.000Hz
Gevoeligheid: (1W / 1M).....................90dB
Impedancy:.........................................8 ohm
Aanbevolen versterker vermogen:
......................................................10 - 100 W
Maten:(BxHxDmm)...............600x115x160
Technische Daten:
Typ:...............................................Bassreflex
Bestückung: (Magnetisch abgeschirmt)
Hochtöner:..................1” Soft Dome
Baß:..........................4 x 3 1/2”
Übergangsfrequenz:.....................6.000Hz
Frequenzgang:.....................70-20.000Hz
Schalldruck: (1W / 1M)......................90dB
Impedance:.........................................8 ohm
Empf. Verstärkerleistung:........10 - 100 W
Abmessungen:(WxHxDmm)..600x115x160
Plaatsing:
Weitere Informationen erhalten sie aus
der beiliegenden Audio Pro
Bedienungsanleitung.
Lees hiervoor de Audio Pro
gebruiksaanwijzing.
Aufstellung:
Audio Pro AB, Helsingborg, Sweden
Nederlands/Deutsch
CINEMA C4
Cinema C4 Technical data.pmd 2003-07-02, 16:523
Tekniset tiedot:
Kotelotyyppi:.......................Bassorefleksi
Elementit: (Magneettisuojattu)
Diskantti:...................1"Soft Dome
Basso:..............................4 x 3 1/2"
Jakotaajuus:.................................6.000Hz
Toistoalue:............................70-20.000Hz
Herkkyys: (1W / 1M)..........................90dB
Impedanssi:.....................................8 ohm
Vahvistin suositus:.................10 - 100 W
Mitat:(L x K x S mm)
.............................................600x115x160
Sijoitus:
Katso mukana oleva ohje. Per ulteriori informazioni vedere
l’accluso manuale d’instruzione
Audio Pro.
Collocazione:
Audio Pro AB, Helsingborg, Sweden
Suomi/Italiano
Dati tecnici:
Tipo:...............................................Bass reflex
Elementi: (schermati)
Tweeter:......................1” Soft Dome
Woofer:...............................4 x 3 1/2”
Crossover:........................................6.000Hz
Gamma di frequenze:...........70-20.000Hz
Sensibilita`: (1W / 1M).........................90dB
Impedenza:..........................................8 ohm
Potenza richiesta:......................10 - 100 W
Dimensioni:
.....................mm 600x115x160 (L x A x P)
CINEMA C4
Cinema C4 Technical data.pmd 2003-07-02, 16:524
Ubicación:
Vea el manual de instrucciones Audio
Pro adjunto para obtener más
información.
Audio Pro AB, Helsingborg, Sweden
Español
Tipo:...........................................Bass reflex
Altavoces: (con protección)
Tweeter:......Cúpula blanda de 1 ”
Woofer:...............................4 x 3,5 ”
Frecuencia de cruce:..................6.000Hz
Banda de frecuencias:....70 – 20.000Hz
Sensibilidad: (1W / 1m).....................90dB
Impedancia:.................................8 ohmios
Requisitos de amplificador:..10 – 100 W
Dimensiones:
......................(AxAxP mm) 600x115x160
Datos técnicos:
CINEMA C4
Cinema C4 Technical data.pmd 2003-07-02, 16:525
