Audio Pro Bravo CX-02 User manual
Tekniska data:
Typ:........................................Slavbas
Bestyckning:( Skärmade)
Diskant:.............1” Super Tweeter
Bas:.............................2 x 5 1/4”
Delningsfrekvens:.......................2.400Hz
Frekvensomfång:...............45-50.000Hz
45-42.000Hz (-3dB)
Känslighet: (1W / 1M)....................88dB
Impedans:...................................4 ohm
Rek. förstärkareffekt:............25 - 125 W
Dimensioner:(BxHxD mm)....460x190x260
Technical data:
Enclosure:...................Passive radiator
Drive units: (Shielded)
Tweeter:............1” Super Tweeter
Woofer:.......................2 x 5 1/4”
Crossover:.................................2.400Hz
Frequency range:..............45-50.000Hz
45-42.000Hz (-3dB)
Sensitivity: (1W / 1M)....................88dB
Impedance:..................................4 ohm
Amp. requirement:...............25 - 125 W
Dimensions:(WxHxD mm)....460x190x260
Placering:
See the enclosed Audio Pro instruction
manual for further information.
Se medföljande Audio Pro instruktions-
bok för ytterligare information.
Placement:
Audio Pro AB, Helsingborg, Sweden
Swedish/English
BRAVO CX-02
CX-02 Tech data.pmd 2005-01-03, 11:121
Charactéristiques:
Type:.........Radiateur Acoustique passif
Haut-parleurs:(Avec blindage)
Tweeter:...............1” Super Dôme
Woofer:.......................2 x 5 1/4”
Fréquence de séparation:.........2.400Hz
Réponse en fréquence:......45-50.000Hz
45-42.000Hz (-3dB)
Sensibilité: (1W / 1M).....................88dB
Impédance:..................................4 ohm
Puissance d’entrée:..............25 - 125 W
Dimensions:(LxHxP mm).....460x190x260
Ôå÷íéêÜ óôïé÷åßá:Ôå÷íéêÜ óôïé÷åßá:
Ôå÷íéêÜ óôïé÷åßá:Ôå÷íéêÜ óôïé÷åßá:
Ôå÷íéêÜ óôïé÷åßá:
Ôýðïò:...................ÁíÜêëáóç ìðÜóùí
ÌåãÜöùíá:(ÈùñáêéóìÝíá))
))
)
Ôïõßôåñ:.........................Èüëïò 1"
Ãïýöåñ:.......................2 x 5 1/4"
Crossover:................................2.400Hz
Aðüêñéóç óõ÷íïôÞôùí:.....45-50.000Hz
45-42.000Hz (-3dB)
Åõáéóèçóßá: (1W / 1M)...................88dB
Áíôßóôáóç...................................4 ïhm
Åíßó÷õóç:................................25-125W
ÄéáóôÜóåéò:(ÐxYxB)...460x190x260mm
Emplacement:
Ãéá ðåñéóóüôåñåò ëåðôïìÝñåéåò
áíáöåñèåßôå óôï åã÷åéñßäéï ïäçãéþí.
Se référer au mode d’emploi ci-joint.
ÔïðïèÝôçóç:
Audio Pro AB, Helsingborg, Sweden
Français/Åëëçíéêá
BRAVO CX-02
CX-02 Tech data.pmd 2005-01-03, 11:122
Technische gegevens:
Soort:.......Passieve Akoestische Radiator
Speaker soort: (afgeschermd)
Tweeter:...............1” Super Tweeter
Woofer:..............................2 x 5 1/4”
Crossover:.......................................2.400Hz
Freq. Bereik:...........................45-50.000Hz
45-42.000Hz (-3dB)
Gevoeligheid: (1W / 1M)....................88dB
Impedancy:.........................................4 ohm
Aanbevolen versterker vermogen:
......................................................25 - 125 W
Maten:(BxHxDmm)..............460x190x260
Technische Daten:
Typ:..........................................Passivradiator
Bestückung:(Magnetisch abgeschirmt)
Hochtöner:..........1” Super Tweeter
Baß:....................................2 x 5 1/4”
Übergangsfrequenz:.....................2.400Hz
Frequenzgang:......................45-50.000Hz
45-42.000Hz (-3dB)
Schalldruck: (1W / 1M)......................88dB
Impedance:........................................4 ohm
Empf. Verstärkerleistung:........25 - 125 W
Abmessungen:(WxHxDmm)..460x190x260
Plaatsing:
Weitere Informationen erhalten sie
aus der beiliegenden Audio Pro
Bedienungsanleitung.
Lees hiervoor de Audio Pro
gebruiksaanwijzing.
Aufstellung:
Audio Pro AB, Helsingborg, Sweden
Nederlands/Deutsch
BRAVO CX-02
CX-02 Tech data.pmd 2005-01-03, 11:123
Audio Pro AB, Helsingborg, Sweden
Suomi/Italiano
BRAVO CX-02
Tekniset tiedot:
Kotelotyyppi:...................Passiivisäteilijä
Elementit: (Magneettisuojattu)
Diskantti:...........1"Super Diskantti
Basso:..............................2 x 5 1/4"
Jakotaajuus:.................................2.400Hz
Toistoalue:.............................45-50.000Hz
45-42.000Hz (-3dB)
Herkkyys: (1W / 1M)..........................88dB
Impedanssi:.....................................4 ohm
Vahvistin suositus:.................25 - 125 W
Mitat:(L x K x S mm)..........460x190x260
Sijoitus:
Katso mukana oleva ohje. Per ulteriori informazioni vedere
l’accluso manuale d’instruzione
Audio Pro.
Collocazione:
Dati tecnici:
Tipo:.................................Diffusore passivo
Elementi: (schermati)
Tweeter:...............1” Super Tweeter
Woofer:...............................2 x 5 1/4”
Crossover:........................................2.400Hz
Gamma di frequenze:.............45-50.000Hz
45-42.000Hz (-3dB)
Sensibilita`: (1W / 1M).........................88dB
Impedenza:..........................................4 ohm
Potenza richiesta:......................25 - 125 W
Dimensioni: mm 460x190x260 (L x A x P)
CX-02 Tech data.pmd 2005-01-03, 11:124
Ubicación:
Vea el manual de instrucciones Audio
Pro adjunto para obtener más
información.
Tipo:................................Radiador pasivo
Altavoces: (con protección)
Tweeter:......Cúpula blanda de 1 ”
Woofer:.............................2x 5 1/4”
Frecuencia de cruce:..................2.400Hz
Banda de frecuencias:....45– 50.000Hz
45-42.000Hz (-3dB)
Sensibilidad: (1W / 1m).....................88dB
Impedancia:.................................4 ohmios
Requisitos de amplificador:..25 – 125 W
Dimensiones:(AxAxP mm) 460x190x260
Datos técnicos:
BRAVO CX-02
Español
CX-02 Tech data.pmd 2005-01-03, 11:125
