Audio Pro Ego 414 Instruction manual
Tekniska data:
Typ:......................................Basreflex
Bestyckning:
Diskant:...................1” Soft Dome
Bas:.................................6 1/2”
Delningsfrekvens:.......................4.000Hz
Frekvensomfång:...............38-21.000Hz
Känslighet: (1W / 1M)....................90dB
Impedans:.................................8 ohm
Rek. förstärkareffekt:............10 - 125 W
Dimensioner:(BxHxDmm)....196x330x270
Technical data:
Enclosure:..........................Bass reflex
Drive units:
Tweeter:..................1” Soft Dome
Woofer:............................6 1/2”
Crossover:.................................4.000Hz
Frequency range:..............38-21.000Hz
Sensitivity: (1W / 1M)....................90dB
Impedance:..................................8 ohm
Amp. requirement:...............10 - 125 W
Dimensions:(WxHxD mm)...196x330x270
Placering:
See the enclosed Audio Pro instruction
manual for further information.
Se medföljande Audio Pro instruktions-
bok för ytterligare information.
Placement:
Audio Pro AB, Helsingborg, Sweden
Swedish/English
HiFi monitor
EGO 414
EGO 414 technical data.pmd 2002-12-13, 03:111
Charactéristiques:
Type:...................................Bass-reflex
Haut-parleurs:
Tweeter:................1” Soft Dôme
Woofer:............................6 1/2”
Fréquence de séparation:.........4.000Hz
Réponse en fréquence:......38-21.000Hz
Sensibilité: (1W / 1M).....................90dB
Impédance:.................................8 ohm
Puissance d’entrée:..............10 - 125 W
Dimensions:(LxHxP mm).....196x330x270
Ôå÷íéêÜ óôïé÷åßá:Ôå÷íéêÜ óôïé÷åßá:
Ôå÷íéêÜ óôïé÷åßá:Ôå÷íéêÜ óôïé÷åßá:
Ôå÷íéêÜ óôïé÷åßá:
Ôýðïò:......................ÁíÜêëáóç ìðÜóùí
ÌåãÜöùíá:
Ôïõßôåñ:.........................Èüëïò 1"
Ãïýöåñ:............................6 1/2"
Crossover:................................4.000Hz
Aðüêñéóç óõ÷íïôÞôùí:.....38-21.000Hz
Åõáéóèçóßá: (1W / 1M)...................90dB
Áíôßóôáóç...................................8 ïhm
Åíßó÷õóç:................................10-125W
ÄéáóôÜóåéò:(ÐxYxB)...196x330x270mm
Emplacement:
Ãéá ðåñéóóüôåñåò ëåðôïìÝñåéåò
áíáöåñèåßôå óôï åã÷åéñßäéï ïäçãéþí.
Se référer au mode d’emploi ci-joint.
ÔïðïèÝôçóç
Audio Pro AB, Helsingborg, Sweden
Français/Åëëçíéêá
EGO 414
EGO 414 technical data.pmd 2002-12-13, 03:112
Technische gegevens:
Soort:.............................................Basreflex
Speaker soort:
Tweeter:.......................1” Soft Dome
Woofer:....................................6 1/2”
Crossover:.......................................4.000Hz
Freq. Bereik:...........................38-21.000Hz
Gevoeligheid: (1W / 1M).....................90dB
Impedancy:.........................................8 ohm
Aanbevolen versterker vermogen: 10 - 125 W
Maten:(BxHxDmm):............196x330x270
Plaatsing:
Weitere Informationen erhalten sie
aus der beiliegenden Audio Pro
Bedienungsanleitung.
Lees hiervoor de Audio Pro ge-
bruiksaanwijzing.
Aufstellung:
Audio Pro AB, Helsingborg, Sweden
Nederlands/Deutsch
Technische Daten:
Typ:...............................................Bassreflex
Bestückung:
Hochtöner:.................1” Soft Dome
Baß:..........................................6 1/2”
Übergangsfrequenz:.....................4.000Hz
Frequenzgang:......................38-21.000Hz
Schalldruck: (1W / 1M).......................90dB
Impedance:.........................................8 ohm
Empf. Verstärkerleistung:........10 - 125 W
Abmessungen:(WxHxDmm)..196x330x270
EGO 414
EGO 414 technical data.pmd 2002-12-13, 03:113
Tekniset tiedot:
Kotelotyyppi:.......................Bassorefleksi
Elementit:
Diskantti:...................1"Soft Dome
Basso:.....................................6 1/2"
Jakotaajuus:.................................4.000Hz
Toistoalue:.............................38-21.000Hz
Herkkyys: (1W / 1M).........................90dB
Impedanssi:.....................................8 ohm
Vahvistin suositus:.................10 - 125 W
Mitat:(L x K x S mm)..........196x330x270
Sijoitus:
Katso mukana oleva ohje. Per ulteriori informazioni vedere
l’accluso manuale d’instruzione
Audio Pro.
Collocazione:
Audio Pro AB, Helsingborg, Sweden
Suomi/Italiano
Dati tecnici:
Tipo:...............................................Bass reflex
Elementi:
Tweeter:.......................1” Soft Dome
Woofer:......................................6 1/2”
Crossover:........................................4.000Hz
Gamma di frequenze:.............38-21.000Hz
Sensibilita`: (1W / 1M).........................90dB
Impedenza:..........................................8 ohm
Potenza richiesta:......................10 - 125 W
Dimensioni: mm 196x330x270 (L x A x P)
EGO 414
EGO 414 technical data.pmd 2002-12-13, 03:114
Ubicación:
Vea el manual de instrucciones Audio
Pro adjunto para obtener más
información.
Audio Pro AB, Helsingborg, Sweden
Español
Tipo:...........................................Bass reflex
Altavoces:
Tweeter:......Cúpula blanda de 1 ”
Woofer:......................................6,5 ”
Frecuencia de cruce:..................4.000Hz
Banda de frecuencias:.....38 – 21.000Hz
Sensibilidad: (1W / 1m).....................90dB
Impedancia:.................................8 ohmios
Requisitos de amplificador:..10 – 125 W
Dimensiones:(AxAxP mm) 196x330x270
Datos técnicos:
EGO 414
EGO 414 technical data.pmd 2002-12-13, 03:115
