Ameriwood HOME 5683215PCOM User manual

B345683215PCOM00GO

- Unit can tip over causing severe injury or death.

- Anchor unit to stud in wall (if instructed to).

- Do Not allow children to climb on unit.

- Put heavy items on lower shelves or drawers.

WARNING

THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.

Do Not Return This Product!

Contact our customer service team for help first.

Call: 1-800-489-3351 (toll free)

Monday-Friday 9am - 5pm CST

Visit: www.ameriwoodhome.com

Follow Ameriwood Home

Date of Purchase ___ / ___ / ___

Lot Number:

5683215PCOM

Farmington Nightstand

Tube

You

Assembly Difficulty Meter

Easy Tough

Do NOT return this product!

Contact our friendly customer service team first for help.

Call us!

1-800-489-3351

Monday-Friday

9am - 5pm CST

Visit ameriwoodhome.com

Assembly Tips

- Open your item in the area you plan to keep it to avoid excessive heavy lifting.

- Identify, sort and count the parts before attempting assembly.

- Compression dowels are lightly tapped in with a hammer.

- Slides are labeled with a R (right) and L (left) for proper placement.

- Make sure to always face the point on the top of the Cam Lock towards the

outer edge.

- Use all the nails provided for the back panel and spread them out equally.

- Back panel must be used to make sure your unit is sturdy.

- Do NOT use harsh chemicals or abrasive cleaners on this item.

- Never push, pull, or drag your furniture.

ameriwoodhome.com

Tube

You

PEOPLE NEEDED FOR ASSEMBLY: 1-2

ESTIMATED ASSEMBLY TIME: 0.5-1 HOUR

Helpful Hints

Tube

You

Quick

Tip

Assembly

ameriwoodhome.com

Read through each step carefully and follow the proper order

Separate and count all your parts and hardware

Give yourself enough room for the assembly process

Have the following tools: Flat Head Screwdriver, #2 Phillips Head

Screwdriver and Hammer

Caution: If using a power drill or power screwdriver for screwing,

please be aware to slow down and stop when screw is tight.

Failure to do so may result in stripping the screw.

Before You Start

Tube

You

Cam Lock Fastening System

This Cam Lock Fastening System will be used throughout the assembly process.

Board Identification

Not actual size

ameriwoodhome.com

BOTTOM

T5683215020GO

QTY: 1 PC

STRINGER

T5683215030GO

QTY: 1 PC

TOP

T5683215010GO

QTY: 1 PC

CENTER MOLDING

T5683215040GO

QTY: 1 PC

Tube

You

UPPER FRONT MOLDING

T5683215050GO

QTY: 1 PC

LEFT PANEL

T5683215060GO

QTY: 1 PCS

RIGHT PANEL

T5683215070GO

QTY: 1 PC

UPPER SIDE MOLDING

T5683215080GO

QTY: 2 PCS

RAIL

T5683215090GO

QTY: 2 PCS

LEFT PANEL RAIL

T5683215100GO

QTY: 1 PC

Board Identification

Not actual size

ameriwoodhome.com

LEFT FRONT LEG

T5683215120GO

QTY: 1 PC

LEFT BACK LEG

T5683215140GO

QTY: 1 PC

Tube

You

RIGHT BACK LEG

T5683215150GO

QTY: 1PC

BACK PANEL

T5683215160GO

QTY: 1PC

LEFT DRAWER SIDE

T5683215180GO

QTY: 1PC

RIGHT FRONT LEG

T5683215130GO

QTY: 1 PC

RIGHT PANEL RAIL

T5683215110GO

QTY: 1 PC

DRAWER FRONT

T5683215170GO

QTY: 1PC

RIGHT DRAWER SIDE

T5683215190GO

QTY: 1PC

DRAWER BOTTOM

T5683215200GO

QTY: 1PC

DRAWER BACK

T5683215210GO

QTY: 1PC

Board Identification

Not actual size

ameriwoodhome.com

Tube

You

Part List

ameriwoodhome.com

Hardware Bag Reference number:

25683215PCOM0GO

Actual Size

M4 x 19mm

×30 ×30 ×17 ×2

Tube

You

×4

CAM LOCK

TGO2100 CAM BOLT

TGO2000 WOOD DOWEL

TGO2900 BOLT

TGO1608

SCREW

TGO1008

Ø4 x 20mm

×14

SCREW

TGO1318

×12

Ø3 x 12mm

SCREW

TGO1301

×14

Ø3.5 x 12mm

SCREW

TGO1007

No Actual Size

×1

KNOB

TGO5510

Ø4.2 x 45mm

M8 x 30mm

Ø8 x 20mm

Ø15 x 10mm

1234

5678

×1 set

METAL SLIDE

TGO4514

11 14"

11-1 11-2

left cabinet memberleft cabinet runner

12 ×1 set

12-1 12-2

right cabinet memberright cabinet runner

×16

COVER

TGO2219

Ø 20mm

14"

ameriwoodhome.com

STEP

1.1 Attach cam bolt (2) into (L), (M), (N) and (O) as illustrated.

Tube

You

×16

ameriwoodhome.com

STEP

2.1 Insert (3) into (G) and (F) as illustrated.

Tube

You

×8

ameriwoodhome.com

STEP

Tube

You

×12

3.1 Attach (M), (O) into (G) with (1) as illustrated.

3.2 Attach (L), (N) into (F) with (1) as illustrated.

Proper orientation of CAM LOCK

Tip

Quick

Assembly

UNLOCK

LOCK

1Small holes in rear surface
