Ameriwood HOME 4294407COM User manual

4294407COM

TV Stand-Black/Walnut

- Unit can tip over causing severe injury or death.

- Anchor unit to stud in wall (if instructed to).

- Do Not allow children to climb on unit.

- Put heavy items on lower shelves or drawers.

B34 4294407 COM00SF

THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.

WARNING

Follow Ameriwood Home

Date of Purchase ___ / ___ / ___

Lot Number:

Do Not Return This Product!

Contact our customer service team for help first.

Call: 1-800-489-3351 (toll free)

Monday-Friday 9am - 5pm CST

Visit: www.ameriwoodhome.com

Assembly Difficulty Meter

Easy Tough

Follow Ameriwood Home

Helpful Hints

Do NOT return this product!

Contact our friendly customer service team first for help.

Call us!

1-800-489-3351

Monday-Friday

9am - 5pm CST

Visit ameriwoodhome.com

Assembly Tips

- Open your item in the area you plan to keep it to avoid excessive heavy lifting.

- Identify, sort and count the parts before attempting assembly.

- Compression dowels are lightly tapped in with a hammer.

- Slides are labeled with a R (right) and L (left) for proper placement.

- Make sure to always face the point on the top of the Cam Lock towards the

outer edge.

- Use all the nails provided for the back panel and spread them out equally.

- Back panel must be used to make sure your unit is sturdy.

- Do NOT use harsh chemicals or abrasive cleaners on this item.

- Never push, pull, or drag your furniture.

PEOPLE NEEDED FOR ASSEMBLY: 2

ESTIMATED ASSEMBLY TIME: 1 HOUR

ameriwoodhome.com

Before You Start

Quick

Tip

Assembly

Cam Lock Fastening System

This Cam Lock Fastening System will be used throughout the assembly process.

Read through each step carefully and follow the proper order

Separate and count all your parts and hardware

Give yourself enough room for the assembly process

Have the following tools: Flat Head Screwdriver, #2 Phillips Head

Screwdriver and Hammer

Caution: If using a power drill or power screwdriver for screwing,

please be aware to slow down and stop when screw is tight.

Failure to do so may result in stripping the screw.

ameriwoodhome.com

Board Identification

Not Actual Size

Top panel

T4294407010SF

Bottom panel

T4294407020SF

Left side panel

T4294407030SF

Right side panel

T4294407040SF

Side panel rail

T4294407060SF

QTY: 2 PCS

Bottom support

T4294407050SF

Board Identification

Not Actual Size

Upper back panel

T4294407070SF

Lower back panel

T4294407080SF

Fixed shelf

T4294407090SF

QTY: 2 PCS

Kick

T4294407100SF

Front support tube

T4294407120SF

QTY: 2 PCS

Support tube

T4294407110SF

QTY: 4 PCS

ameriwoodhome.com

Board Identification

Not Actual Size

Actual Size

ameriwoodhome.com

Part List

Hardware Bag Reference Number:

24294407COM0SF

Ø5/32X10mm

Screw bolt

TSF1803

2x 4

Ø5/32X12mm

Bolt

TSF0952

3x 8

x 32

Ø8X30mm

Wood dowel

TSF0501

Ø1/4X30mm

Bolt

TSF1403

4x 4

Screw

TSF1110

5x 4

Ø4X30mm

ameriwoodhome.com

Part List

Not Actual Size

Hardware Bag Reference Number:

24294407COM0SF

Cam bolt

TSF0354

7x 32

Cam lock

TSF0307

6x 32

Ø7 X10XT1.5mm

Spring washer

TSF2451

10 x 4

Ø7X16XT1.5mm

Washer

TSF2452

11 x 4

x 16

Ø14 x 11mm

Ø6 x 29mm

Cam bolt

TSF0002

x 1

Glue

TSF0015

Cam lock

TSF0305

WARNING

ADVERTENCIA

AVERTISSEMENT

Warning label

TSF2904

120 LBS

14 x 1

Ø15x12mm Ø7x34mm

Hex key

TSF2804

12 x 1

M4X70X70mm

ameriwoodhome.com

STEP

x 8

Ø8X30mm

x 8

Ø6X10(29)mm

7x 8

Ø7x34mm

lue

Wooden

Dowel

Hole for

wooden dowel

Use one drop of glue

in dowel hole.

ameriwoodhome.com

STEP

x 12

Ø8X30mm

x 8

Ø6X10(29)mm

7x 14

Ø7x34mm

lue

Wooden

Dowel

Hole for

wooden dowel

Use one drop of glue

in dowel hole.
