Ameriwood HOME 6429407COM User manual

6429407COM

Coffee Table-Black/Walnut

- Unit can tip over causing severe injury or death.

- Anchor unit to stud in wall (if instructed to).

- Do Not allow children to climb on unit.

- Put heavy items on lower shelves or drawers.

B34 6429407 COM00SF

THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.

WARNING

Follow Ameriwood Home

Date of Purchase ___ / ___ / ___

Lot Number:

Do Not Return This Product!

Contact our customer service team for help first.

Call: 1-800-489-3351 (toll free)

Monday-Friday 9am - 5pm CST

Visit: www.ameriwoodhome.com

Assembly Difficulty Meter

Easy Tough

Follow Ameriwood Home

Helpful Hints

Do NOT return this product!

Contact our friendly customer service team first for help.

Call us!

1-800-489-3351

Monday-Friday

9am - 5pm CST

Visit ameriwoodhome.com

Assembly Tips

- Open your item in the area you plan to keep it to avoid excessive heavy lifting.

- Identify, sort and count the parts before attempting assembly.

- Compression dowels are lightly tapped in with a hammer.

- Slides are labeled with a R (right) and L (left) for proper placement.

- Make sure to always face the point on the top of the Cam Lock towards the

outer edge.

- Use all the nails provided for the back panel and spread them out equally.

- Back panel must be used to make sure your unit is sturdy.

- Do NOT use harsh chemicals or abrasive cleaners on this item.

- Never push, pull, or drag your furniture.

PEOPLE NEEDED FOR ASSEMBLY: 2

ESTIMATED ASSEMBLY TIME: 1 HOUR

ameriwoodhome.com

Before You Start

Quick

Tip

Assembly

Cam Lock Fastening System

This Cam Lock Fastening System will be used throughout the assembly process.

Read through each step carefully and follow the proper order

Separate and count all your parts and hardware

Give yourself enough room for the assembly process

Have the following tools: Flat Head Screwdriver, #2 Phillips Head

Screwdriver and Hammer

Caution: If using a power drill or power screwdriver for screwing,

please be aware to slow down and stop when screw is tight.

Failure to do so may result in stripping the screw.

ameriwoodhome.com

Board Identification

Not Actual Size

Top panel

T6429407010SF

Bottom panel

T6429407020SF

Side panel

T6429407030SF

QTY: 2 PCS

Side panel rail

T6429407060SF

QTY: 4 PCS

Bottom support

T6429407050SF

Kick

T6429407040SF

QTY: 2 PCS

Board Identification

Not Actual Size

Fixed shelf

T6429407070SF

QTY: 2 PCS

Front support tube

T6429407090SF

QTY: 4 PCS

Support tube

T6429407080SF

QTY: 2 PCS

ameriwoodhome.com

Board Identification

Not Actual Size

Actual Size

ameriwoodhome.com

Part List

Hardware Bag Reference Number:

26429407COM0SF

Ø5/32X10mm

Screw bolt

TSF1803

2x 4

Ø5/32X12mm

Bolt

TSF0952

3x 16

x 32

Ø8X30mm

Wood dowel

TSF0501

Not Actual Size

Cam bolt

TSF0354

5x 38

Cam lock

TSF0307

4x 38 x 1

Glue

TSF0015

Ø15x12mm Ø7x34mm

ameriwoodhome.com

STEP

x 24

Ø8X30mm

5x 30

Ø7x34mm

x 2

lue

Wooden

Dowel

Hole for

wooden dowel

Use one drop of glue

in dowel hole.

ameriwoodhome.com

STEP

x 4

x 8

Ø8X30mm

5x 8

Ø7x34mm

lue

Wooden

Dowel

Hole for

wooden dowel

Use one drop of glue

in dowel hole.

ameriwoodhome.com

STEP

4x 10

Ø15x12mm

Proper orientation of CAM LOCK

Tip

Quick

Assembly

UNLOCK

LOCK

x 2

lue

Wooden

Dowel

Hole for

wooden dowel

Use one drop of glue

in dowel hole.
