Ameriwood HOME 1056849COM User manual

WARNING

Dateof Purchase___ /___ /___

LotNumber:

DoNotReturn This Product!

Contact ourcustomerserviceteamforhelp first.

Call: 1-800-489-3351 (toll free)

Monday-Friday9am-5pmCST

Visit: www.ameriwoodhome.com AssemblyDifficultyMeter

Easy Tough

Espresso/Black

Parkhilloverthebeddesk

1056849COM

ContactUs!

ameriwoodhome.com

PEOPLENEEDED FOR ASSEMBLY: 2

ESTIMATED ASSEMBLYTIME: 1HOUR

HelpfulHints

ameriwoodhome.com

Readthrougheachstepcarefully and followthe proper order

Separate and countall your partsand hardware

Give yourself enoughroom for the assembly process

Have the following tools: FlatHeadScrewdriver,#2PhillipsHead

Screwdriver andHammer

Caution:If using a power drill or power screwdriver for screwing,

please be aware to slowdownand stop whenscrewistight.

Failure to dosomay result instripping the screw.

BeforeYou Start

CamLockFasteningSystem

ameriwoodhome.com

Board Identification

NotActualSize

Top panel

T1056849010KX Leg frame

T1056849021KX

QTY:2PCS

Rightrail

T1056849060KX Adjustableleg

T1056849071KX

QTY:4PCS

Rearrail

T1056849040KX

Supporttube

T1056849031KX

QTY:2PCS

Leftrail

T1056849050KX

Anglecode

T1056849080KX

QTY:4PCS

ameriwoodhome.com

Board Identification

NotActualSize

PartList

ameriwoodhome.com

HardwareBag ReferenceNumber:

21056849COM1KX

ActualSize

Ø8X30 mm

Wooddowel

TKX1005 Bolt

TKX1342

Ø1/4"X35mm

Bolt

TKX1033

Screw

TKX1311

Ø4X25 mm

Cambolt

TKX1191

M8X20mm

Ø15X12 mm

Cam lock

TKX1010 Glue

TKX1014

Cam cover

TKX1344

Hexkey

TKX1004

Caster withlock

TKX1345

Caster

TKX1346

10 2 12 1

Wrench

TKX1347

NotActualSize

Ø1/4"X12mm

ameriwoodhome.com

STEP 1

Ø8X30 mm

M8X20mm

1.1Attach(5)to(E), (F)as illustrated.

1.2Attach(1)to(E), (D), (F) asillustrated.

ameriwoodhome.com

STEP 2

92 10 2 12

2.1Attach(9)to(G)as illustrated.

2.2Attach(10) to(G)asillustrated.

X2 X2

ameriwoodhome.com

STEP 3

Properorientation of CAM LOCK

Ø15X12 mm

2 2

3.1Attach(E), (F) to(D)with(6) asillustrated.

3.2Use(7)tocovercam lockhole.

ameriwoodhome.com

STEP 4

Ø4X25 mm

4.1Attach(A)to(D), (E)&(F) with(4)asillustrated.
