Amana Automatic Dryer User manual

DC68-02033C

W10161760

AUTOMATIC DRYER INSTALLATION INSTRUCTIONS

MISE EN SERVICE SÉCHEUSE AUTOMATIQUE

INSTRUCCIONES DE INSTALACIÓN DE LA SECADORA

AUTOMÁTICA

The installation, including a proper exhaust system,

is the responsibility of the owner.

La responsabilité de la mise en service, y compris le système

d'évacuation qui convient, revient au propriétaire.

Es responsabilidad del propietario la instalación correcta,

incluso la del sistema de escape.

LEAVE THESE INSTRUCTIONS WITH THE OWNER

REMETTRE CES INSTRUCTIONS AU PROPRIÉTAIRE

DEJE ESTAS INSTRUCCIONES CON EL PROPIETARIO

NED7200TW-02033C 2007.9.6 10:22 AM Page 1

Note:

The height of the dryer from top to floor is 38" with the leveling leg screwed all the way in. The customer can

unscrew the leg out an additional 7\8" for a total overall height of 38 7/8".

• Teflon tape or pipe

joint compound (gas only)

• Cutting knife

• Pipe wrench (gas only)

• Nut drivers

• Level

• Screw driver (standard)

• Duct tape

• Crescent wrench

ITEMS PROVIDED

Electric Dryer

Only

Gas Dryer

Only

Tools needed for installation

CABINET DIMENSIONS

Proper installation is the responsibility of the owner.

HOWEVER, SERVICE CALLS PERFORMED AS A RESULT OF POOR SET-UP, ADJUSTMENT AND

CONNECTION ARE THE RESPONSIBILITY OF THE INSTALLER.

Make sure you have everything necessary for proper installation.

1. GROUNDED ELECTRICAL OUTLET is required. See Electric Requirements.

2. POWER CORD for electric dryers (except Canada).

3. GAS LINES (if a gas dryer) must meet National and Local Codes.

4. EXHAUST SYSTEM – must be rigid metal or flexible stiff walled metal exhaust ducting. See Exhaust Requirements.

7200 series

A. Height-overall

B. Width

C. Depth-With Dryer Door Open 90°

D. Depth

E. Bottom Vent Hole Location - From Back

To Center of Hole

Side Vent Hole - From Back To Center Of

Hole

INCH (CM)

38” (96.5)

27” (68.6)

46-7/16” (123.0)

28” (71.0)

7-1/2” (19)

8-1/2” (21.6)

NED7200TW-02033C 2007.9.6 10:22 AM Page 2

IMPORTANT TO INSTALLER

Please Read The Following Instructions Carefully Before Starting To Install The Dryer. These Instructions

Should Be Retained For Future Reference.

REMOVE THE DOOR FROM ALL DISCARDED APPLIANCES SUCH AS

DRYERS TO AVOID THE DANGER OF A CHILD SUFFOCATING.

LOCATION CONSIDERATIONS

The dryer should be located to permit adequate room in front for loading the dryer, and sufficient room

behind the dryer for the exhaust system.

This dryer is factory-ready for rear exhaust. To exhaust out the bottom or left side, use the accessory

exhaust kit (see Accessories). Instructions are included with the kit.

It is important to make sure the room has adequate make-up air. The area where the dryer is located must

not obstruct the flow of combustion or ventilating air.

On gas dryers, adequate clearance as noted on the data plate must be maintained to insure adequate air

for combustion and proper operation of the dryer.

THE DRYER MUST NOT BE INSTALLED OR STORED IN AN AREA WHERE IT WILL BE

EXPOSED TO WATER AND/OR WEATHER. THE DRYER AREA IS TO BE KEPT CLEAR AND

FREE FROM COMBUSTIBLE MATERIALS, GASOLINE AND OTHER FLAMMABLE VAPORS AND

LIQUIDS. A DRYER PRODUCES COMBUSTIBLE LINT. THE AREA AROUND THE DRYER

SHOULD BE KEPT FREE OF LINT.

ALCOVE OR CLOSET INSTALLATION

• An appliance installed in a closet shall have no other fuel-

burning appliance installed in the same closet.

•WARNING: To reduce the risk of fire, this

dryer MUST BE EXHAUSTED TO THE

OUTDOORS. See EXHAUST INFORMATION

section.

• Minimum clearances between dryer cabinet and adjacent walls or other surfaces are:

2" front, 0" top, 0" either side and 2-3/8" rear.

• Closet front must have two unobstructed air openings combined total area 72 in2min., located 3 in

min. from top and bottom.

Louvered door with equivalent air opening is acceptable.

MOBILE HOME INSTALLATION

The installation of the dryer in mobile homes must conform to the Manufactured Home

Construction and Safety Standard Title 24 CFR, Part 32-80 {formerly the Federal standard for Mobile Home

Construction and Safety, Title 24, HUD (Part 280), 1975} for the United States,) or CSA Standards Z240

(for Canada). When installing a dryer in a mobile home, provisions for anchoring the dryer to the floor must

be made. An anchor bracket kit is available with instructions (see Accessories). Locate in an area that has

adequate make up air. A minimum of 72 in2(183 cm2) of unobstructed opening is required. All mobile home

installations must be exhausted to the outside with the exhaust duct termination securely fastened to the

mobile home structure, using materials that will not support combustion. The exhaust duct may not

terminate beneath the mobile home. See the section on exhausting for more information.

WARNING –

The dryer must

be exhausted to

the outside to

reduce the risk

of fire when

installed in an alcove or closet.

WARNING

NED7200TW-02033C 2007.9.6 10:22 AM Page 3

EXHAUSTING

Exhausting the dryer to the outside will prevent large amounts of lint and moisture from being blown

into the room.

In the United States:

• All dryers must be exhausted to the outside.

• Only rigid or flexible metal duct should be used for exhausting.

In Canada:

• All dryers must be exhausted to the outside.

Outside the U.S. and Canada:

• Refer to local codes.

DUCTING REQUIREMENTS

• Use A Minimum Of 4-inch (10.2 Cm) Diameter Rigid Aluminum Or Rigid Galvanized Steel Duct.

• Do not use smaller duct.

• Ducts larger than 4 inches (10.2 cm) in diameter can result in increased lint accumulation. Lint

accumulation should be cleaned regularly.

• If flexible metal duct must be used, use the type with a stiff sheet metal wall. Do not use flexible

duct with a thin foil wall. Serious blockage can result if flexible metal duct is bent too sharp.

• Never install any type of flexible duct in walls, ceilings or other concealed spaces.

• Keep exhaust duct as straight and short as possible.

• Secure joints with duct tape. Do not use screws.

• DO NOT EXHAUST DRYER INTO ANY WALL, CEILING, CRAWL SPACE OR A

CONCEALED SPACE OF A BUILDING, GAS VENT, ANY OTHER COMMON DUCT OR

CHIMNEY. THIS COULD CREATE A FIRE HAZARD FROM LINT EXPELLED BY THE DRYER.

• Plastic flexible duct can kink, sag, be punctured, reduce airflow, extend drying times and affect

dryer operation.

WARNING – plastic or nonmetal flexible duct presents a potential fire hazard.

NEVER USE PLASTIC OR NONMETAL FLEXIBLE DUCT.

If your existing ductwork is plastic, nonmetal or combustible, replace it with metal. Use only metal

exhaust duct that will not support combustion to insure the containment of exhaust air, heat and lint.

WARNING

NED7200TW-02033C 2007.9.6 10:22 AM Page 4

• Exhaust systems longer than recommended can extend drying times, affect machine operation

and may collect lint.

• The exhaust duct should end with an exhaust hood with a swing out damper to prevent back

drafts and entry of wildlife. Never use an exhaust hood with a magnetic damper.

• The hood should have at least 12 inches (30.5 cm) of clearance between the bottom of the

hood and the ground or other obstruction. The hood opening should point down.

Never install a screen over the exhaust outlet.

• When possible, do not exhaust the dryer directly into a window well in order to avoid lint build-

up. Do not exhaust under a house or porch.

• If exhaust ductwork must run through an unheated area, the duct should be insulated and slope

slightly down towards the exhaust hood to reduce condensation and lint build-up.

• Inspect and clean the interior or the exhaust system at least once a year. Disconnect electrical

service prior to cleaning.

• Frequently check to be sure the exhaust hood damper opens and closes freely.

If new dryer is installed into an existing exhaust system you must be sure:

• The exhaust system meets all local, state and national codes.

• That plastic flexible duct is not used.

• Inspect and clean all lint accumulation from the interior of the existing duct.

• The duct is not kinked or crushed.

• The exhaust hood damper opens and closes freely.

The static pressure in any exhaust system must not exceed 0.83

inches of water column, or be less than 0.

This can be measured with the dryer running with a manometer at the point where

the exhaust duct connects to the dryer. A no heat setting should be used.

The dryer tumbler should be empty and the lint filter clean.

10.1 m (33 ft.)

8.8 m (29 ft.)

7.6 m (25 ft.)

6.5 m (21 ft.)

24.4 m (80 ft.)

20.7 m (68 ft.)

17.4 m (57 ft.)

14.3m (47 ft.)

22.6 m (74 ft.)

18.9 m (62 ft.)

15.5 m (51 ft.)

12.5 m (41 ft.)

12.4 m (41 ft.)

11.2 m (37 ft.)

10.1 m (33 ft.)

9.0 m (29 ft.)

ELECTRIC AND GAS DRYER

Weather Hood Type

Recommended

Metallic Flexible* Metallic Flexible*

Rigid

* Do not use non metallic flexible duct.

No. of 90°

elbows

4”(10,16 cm)

Use only for short run installation

2 1/2”(6,35 cm)

NED7200TW-02033C 2007.9.6 10:22 AM Page 5

GAS REQUIREMENTS

Use only Natural or LP (liquid propane) gases.

THE INSTALLATION MUST CONFORM WITH LOCAL CODES, OR IN THE ABSENCE OF LOCAL

CODES, WITH THE NATIONAL FUEL GAS CODE ANSI/Z223.1, LATEST REVISION (FOR THE

UNITED STATES), OR WITH THE CAN/CGA-B149 INSTALLATION CODES (FOR CANADA).

Gas dryers are equipped with a burner orifice for operation on NATURAL gas. If the dryer is to be

operated on LP (liquid propane) gas, it must be converted for safe and proper performance and

must be converted by a qualified service technician. Conversion kits from NATURAL to LP, or LP to

NATURAL are available through your local Amana dealer (see Accessories). If other conversions are

required, check with the local gas utility for specific information concerning conversion requirements.

A 1/2” (1.27 cm) gas supply line is recommended and must be reduced to connect to the 3/8” (1.0 cm)

gas line on the dryer.

The National Fuel Gas Code requires that an accessible, approved manual gas shut off valve be

installed within 6 feet of the dryer.

Gas Dryers installed in residential garages must be elevated 18 inches (46 cm) above the floor.

Additionally, a 1/8” (.3 cm) N.P.T. (National Pipe Thread) plugged tapping, accessible for test gauge

connection, must be installed immediately upstream of the gas supply connection to the dryer.

The dryer must be disconnected from the gas supply piping system during any pressure testing of the system.

DO NOT re-use old flexible metal gas line. Flexible gas line must be design certified by American Gas

Association (CGA in Canada). NOTE: Any pipe joint compound used must be resistant to the action of

any liquefied petroleum gas.

NOTE: As a courtesy, most local gas utilities will inspect a gas appliance installation.

GAS IGNITION –

This dryer uses an automatic ignition system to ignite the burner. There is no constant burning pilot.

COMMONWEALTH OF MASSACHUSETTS

INSTALLATION INSTRUCTIONS

This gas dryer must be installed by a licensed

plumber or gas fitter

A “T” handle manual gas valve must be installed in

the gas supply line to this gas dryer.

If a flexible gas connector is used to install this gas

dryer, the connector must have a maximum length

of 3 feet. (36 inches)

WARNING

Gas leaks may occur in your system and result in

a dangerous situation. Gas leaks may not be

detected by smell alone. Gas suppliers

recommend you purchase and install a UL

approved gas detector. Install and use in

accordance with the manufacturer’s instructions.

NED7200TW-02033C 2007.9.6 10:22 AM Page 6

GROUNDING

This dryer must be grounded. In the event of malfunction or breakdown, the ground will reduce the

risk of electrical shock by providing a path of least resistance for electrical current.

GAS MODELS

This appliance is equipped with a cord having an equipment-grounding conductor and a grounding

plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in

accordance with all local codes and ordinances.

Do not modify the plug provided with the appliance – if it will not fit the outlet, have a proper outlet

installed by a qualified electrician.

If a separate ground is required by local codes, a grounding kit (Part No. 12001875) is available. It

contains ground wire, clamp, ground screw and washer. Connect ground wire to back of unit with the

cabinet ground screw and washer. Secure other end of ground wire to a suitable external ground

connection. The wire may be secured with the clamp to a grounded COLD metal water pipe.

NEVER CONNECT GROUND WIRE TO PLASTIC PLUMBING LINES, GAS LINES OR HOT WATER

PIPES.

ELECTRIC MODELS

This appliance is equipped with a cord having an equipment-grounding conductor and a grounding plug.

The plug must be plugged into an appropriate outlet that is properly installed and grounded in

accordance with all local codes and ordinances.

If a power cord is not used and the electric dryer is to be permanently wired, the dryer must be

connected to a grounded metal, permanent wiring system; or an equipment grounding conductor must

be run with the circuit conductors and connected to the equipment grounding terminal.

ELECTRICAL REQUIREMENTS

NOTE: Wiring diagram is located below the Top Cover.

Export models (not U.S. or Canada): See Additional Instructions for Export Models on the other side of this sheet.

•Improper connection of the equipment grounding conductor can result in a risk of electric

shock. Check with a qualified electrician or serviceman if you are in doubt as to whether

the appliance is properly grounded. Do not modify the plug provided with the appliance – if

it will not fit the outlet, have a proper outlet installed by a qualified electrician.

• To prevent unnecessary risk of fire, electrical shock or personal injury, all wiring

and grounding must be done in accordance with local codes, or in the absence of local

codes, with the National Electrical Code, ANSI/NFPA No. 70-Latest Revision (for the US)

or the Canadian Electrical Code CSA C22.1 - Latest Revisions and local codes and ordinances. It is the

personal responsibility and obligation of the appliance owner to provide adequate electrical services for

this appliance

• All gas installations must be done in accordance with the national Fuel Code ANSI/Z2231 - Last revision

(for United States) or CAN/CGA - B149 Installation Codes - Latest Revision (for Canada) and local codes

and ordinances.

WARNING

NED7200TW-02033C 2007.9.6 10:22 AM Page 7

• If a power cord is used, the cord should be plugged into a 30-ampere receptacle.

• The power cord is NOT provided with U.S. electric model dryers.

IMPORTANT: When permitted by local codes, the dryer electrical supply may be connected by

means of a new power supply cord kit, marked for use with clothes dryer, that is U.L. listed, rated at

120/240 volts minimum, 30 amperes with three No. 10 copper wire conductors terminated with closed

loop terminals, open-end spade lugs with turned up ends or with tinned leads.

1. size of the conductors and the type of cord.

2. 3/4 in. (1.9 cm) UL-listed strain relief

• Do not reuse a power supply cord from an old dryer. The power cord electric supply wiring must be

retained at the dryer cabinet with a suitable UL listed strain relief.

• Where grounding through the neutral conductor is prohibited. Grounding through the neutral

conductor is prohibited for (1) new branch-circuit installations, (2) mobile homes, and (3)

recreational vehicles, and (4) areas where local codes prohibit grounding through the neutral

conductor.

(Use 4-prong plug for 4 wire receptacle, NEMA type 14-30R)

ELECTRIC MODELS - Canada Only

• A 120/240 volt, 60 Hz AC approved electrical service fused through a 30 ampere fuse or circuit

breaker on both sides of the line is required.

• All Canadian models are shipped with the power cord attached. The power cord should be plugged

into a 30 ampere receptacle.

NOTE: It is not permissible to convert a dryer in Canada to 208 volts.

REPLACEMENT PARTS AND ACCESSORIES

If your dryer requires replacement parts or accessories, contact the dealer from whom you

purchased your dryer or Amana Customer Service, 553 Benson Road Benton Harbor, MI 49022,

phone 877-232-6771, 866-587-2002 for Canada, for information on the nearest authorized Amana Parts

Distributor.

ELECTRICAL CONNECTIONS

BEFORE OPERATING OR TESTING, follow all grounding instructions in Grounding Section.

An individual branch (or separate) circuit serving only this appliance is recommended. DO NOT USE AN

EXTENSION CORD.

GAS MODELS – U.S. and Canada

A 120 volt, 60 Hz AC, approved electrical service, with a 15 ampere fuse or circuit breaker is required.

ELECTRIC MODELS – U.S. Only

Most U.S. dryers, as manufactured, require a 120/240 volt, 60 Hz AC approved electrical service. Some

require 120/208 volt, 60 Hz approved electrical service. The electric service requirements can be found on

the data label located on the front behind the door. A 30 ampere fuse or circuit breaker on both sides of the

line is required.

NED7200TW-02033C 2007.9.6 10:22 AM Page 8

INSTALLATION

Parts and literature are packaged inside of dryer drum.

To Install...

1. Move dryer to an appropriate location for installation. Consider installing the dryer before the

washer in side-by-side installations, to allow access to gas, electrical and exhaust connections.

Lay two of the carton corner posts on the floor. Tip the dryer on its side so it will lay across both

corner posts.

2. Set the dryer back in an upright position.

3. Review the Exhausting Section before installing the exhaust system. Install the ductwork from the

dryer to the exhaust hood. The crimped end of the duct sections must point away from the dryer.

DO NOT use sheet metal screws when assembling ducting. These joints should be taped. Never

use plastic flexible exhaust material.

Tip for tight installations: install a section of exhaust system to the dryer before moving the dryer in

place. Use duct tape to secure this section to the dryer but do not cover louvers in dryer cabinet.

4. Review Electrical Requirements Section.

BEFORE OPERATING OR TESTING, follow the grounding instructions in the Grounding Section.

U.S. MODELS:

IMPORTANT - All U.S. models are produced for a 3-WIRE SYSTEM CONNECTION. The dryer

frame is grounded to the neutral conductor at the terminal block.

A4-WIRE SYSTEM CONNECTION is required for new or remodeled construction, mobile homes,

or if local codes do not permit grounding through neutral. If the 4-wire system is used, the dryer

frame cannot be grounded to the neutral conductor at the terminal block. Refer to the following

instructions for 3- and 4-WIRE SYSTEM CONNECTIONS.

Remove the terminal block cover plate.

Insert the power cord with a U.L. listed strain relief

through the hole provided in the cabinet near the terminal block.

NOTE: a strain relief must be used.

Do not loosen the nuts already installed on the terminal block. Be sure they are tight. Use a 3/8" (1

cm) deep well socket.

5. Review Gas Requirements Section.

Remove the pipe thread protective cap.

Apply pipe joint compound or about 1 1/2 wraps of Teflon tape over all threaded connections.

NOTE: Pipe joint compound must be resistant to the action of any liquefied petroleum gas.

Connect the gas supply to the dryer. An additional fitting is required to connect the 3/4”

(1.9 cm) female thread end of a flexible connector to the 3/8” (1 cm) male threaded end

on the dryer. Securely tighten the gas line fitting over threads.

Turn on the gas supply. Check all gas connections for leaks using a soap solution. If bubbles

occur, tighten the connections and recheck. DO NOT use an open flame to check for gas

leaks.

NED7200TW-02033C 2007.9.6 10:22 AM Page 9

3-WIRE SYSTEM CONNECTIONS

1. Loosen or remove center terminal block screw.

2. Connect neutral wire (white or center wire) of power supply cord to the center, silver

colored terminal screw of the terminal block. Tighten screw.

3. Connect the other wires to outer terminal block screws. Tighten screws.

4. Tighten strain relief screws.

5. Insert tab of terminal block cover into slot of dryer rear panel. Secure cover with hold-

down screw.

1. External ground connector

2. Neutral grounding wire (green/yellow)

3. Center silver-colored terminal block screw

4. Neutral wire (white or center wire)

5. 3/4 in. (1.9 cm) UL-listed strain relief

WARNING: If converting from a 4-wire electrical system to a 3-wire, the ground strap

must be reconnected to the terminal block support to ground the dryer frame to the

neutral conductor.

4-WIRE SYSTEM CONNECTIONS

1. Remove center terminal block screw.

2. Connect ground wire (green or bare) of power supply cord to external ground conductor

screw.

3. Connect neutral wire (white or center wire) of power supply cord and appliance ground

wire (green with yellow stripes) under central screw of the terminal block.

4. Connect the other wires to outer terminal block screws. Tighten screws.

5. Tighten strain relief screws.

6. Insert tab of terminal block cover into slot of dryer rear panel. Secure cover with hold-down

screw.

1. External ground connector

2. Green or bare copper wire of power supply cord

3. 3/4 in. (1.9 cm) UL-listed strain relief

4.Center silver-colored terminal block screw

5 Grounding wire (green/yellow)

6. Neutral wire (white or center wire)

EXPORT MODELS

Refer to last page of installation instructions.

NED7200TW-02033C 2007.9.6 10:22 AM Page 10

This manual suits for next models

Table of contents

Languages:

Popular Dryer manuals by other brands

Bosch

Bosch WTA79200GB Installation and operating instructions

Miele

Miele TWH 780 WP operating instructions

Asko

Asko T760 user guide

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Original instructions

Bosch

Bosch Logixx 10 WTB76556GB Instruction manual and installation instructions

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Operation and installation

Electrolux

Electrolux EW2H328R2 user manual

Beko

Beko DS8433RX1M user manual

Dawlance

Dawlance Spinner DS 6000 C owner's manual

Electrolux

Electrolux TP5080TW user manual

AEG

AEG TR838P4OB user manual

Indesit

Indesit IDV 75 instruction manual

Infiniton

Infiniton SD-DG85C manual

BOMANN

BOMANN WT 5019 instruction manual

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Installation

Asko

Asko T793C operating instructions

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer installation instructions

Frigidaire

Frigidaire CAQE7077KW0 use & care
