Alliance Laundry Systems FLW63H User manual

Preventative Maintenance

www.alliancelaundry.com

Frontload

Washer

FLW63H

Part No. 11-15-413

November 2015

the expressed written consent of the publisher.

Table of Contents

11-15-413 1

Daily............................................................................................................................................................................2

Monthly ......................................................................................................................................................................4

Quarterly....................................................................................................................................................................7

Bi-Annually................................................................................................................................................................9

Daily Preventative Maintenance Checklist...........................................................................................................11

Monthly Preventative Maintenance Checklist .....................................................................................................11

Quarterly Preventative Maintenance Checklist ...................................................................................................12

Bi-Annually Preventative Maintenance Checklist ...............................................................................................12

IMPORTANT: Replace all panels that are removed to perform maintenance procedures. Do not operate the

washer with missing guards or with broken or missing parts. Do not bypass any safety devices.

211-15-413

Daily

IMPORTANT: Check that all safety and instruction labels are on the machine. Any missing or illegible safety

and/or instruction labels should be replaced immediately.

1. Check the door lock before starting operation:

a. Attempt to start the machine with the door open. The machine

should not start with the door open.

b. Close the door and start a cycle. The DOOR light on the control

panel will be lit. If the door lock is not functioning properly,

call a service technician.

FLW64H

2. Wipe the machine’s top, front and side panels clean as needed. If

detergent, bleach or other washing products are spilled on the

cabinet, wipe immediately. Some products will cause permanent

damage if spilled on cabinet. Thoroughly rinse and dry all

surfaces after cleaning them.

IMPORTANT: Use only a damp or sudsy cloth for cleaning the

control panel. Some cleaning products may harm the finish on

the control panel.

3. Clean the wash drum as necessary. It may need rinsing or wiping

after an unusual load has been washed.

4. Clean outside of window with household window cleaner as

necessary.

5. Inspect wash drum for water leaking into drum while the washer

is off. Replace the mixing valve if required.

FLW65H

11-15-413 3

Daily

6. Leave the loading door open at the end of each day to allow

moisture to evaporate.

NOTE: Unload the machine promptly after each completed

cycle to prevent moisture buildup. Leave the loading door open

after each completed cycle to allow moisture to evaporate.

FLW64H

7. Check coin slide, if applicable, for ease of operation. Replace if

needed.

FLW49H

411-15-413

Monthly

1. Inspect the water fill hose connections on the back of the

machine for leaks.

IMPORTANT: Immediately replace any hose showing signs of

deterioration. All hoses should be replaced every five years.

FLW66H

2. Clean the dispenser drawer. Pour hot water into the drawer,

making sure it flushes through each compartment. Use a small

brush to thoroughly clean out any residue.

FLW67H

3. Check the machine for leaks:

a. Start an unloaded cycle to fill the machine.

FLW68H

11-15-413 5

Monthly

b. Verify that the drain pump or drain valve is operating and that

the drain receptacle is free from obstruction.

FLW51H

NOTE: Disconnect power to the machine before performing

the following procedures.

4. Make sure hose clamps are tight.

a. Remove the front panel and check the pump hose connections

for leaks.

FLW69H

b. Check drain hose connection for leaks.

FLW70H

611-15-413

Monthly

c. Lift cabinet top and check inlet hose connections for leaks.

FLW71H

5. Pump Models – Check the foreign object trap in the pump. Clean

debris from trap if necessary.

Gravity Drain Models – Remove hose and clean drain valve if

necessary.

NOTE: Wipe dry any excess water on the base that may have

come out during this procedure.

FLW69H

6. Check the belt for uneven wear, frayed edges and proper belt

tension. Refer to the service manual for adjusting belt tension.

Call a qualified service person if belt needs replacing. Use only

authorized replacement parts.

7. Inspect door seal for damage.

8. Clean and remove foreign objects that have accumulated

between door seal and clothes guard.

FLW65H

9. Clean the lint from the motor with compressed air.

FLW72H

Hose

Connections

Foreign Object Trap

(Pump Models)

11-15-413 7

Quarterly

NOTE: Disconnect power to the machine before performing the following procedures.

1. Check hardware for any loose nuts, bolts or screws.

FLW46H

2. Check all painted surfaces for bare metal. If bare metal is

showing, paint it with porcelain touch-up paint (available from

the manufacturer).

FLW63H

3. Clean the coin drop/slide, if applicable.

a. Coin Drop – Remove the coin drop from the washer and refer

to the service manual for cleaning instructions.

811-15-413

Quarterly

FLW53H

b. Coin Slide – Check coin slide for ease of operation. If needed,

clean, dry and lubricate slide according to slide manufacturer’s

instructions.

FLW49H
