Alinx AX7A200 User manual

ARTIX-7 FPGA

Development Board

AX7A200

User Manual

ARTIX-7 FPGA Development Board AX7A200 User Manual

2 / 59

Amazon Store: https://www.amazon.com/alinx

Sales Email: rachel.zho[email protected]

Version Record

Version

Date

Release By

Description

Rev 1.0

2019-07-10

Rachel Zhou

First Release

The English version was translated by Shanghai Tianhui Trading

Company. They has not been officially Review by ALINX and are for

reference only. If there are any errors, please send email to

rachel.zhou@aithtech.com for correction.

Amazon Store: https://www.amazon.com/alinx

Aliexpress Store:

https://alinxfpga.aliexpress.com/store/911112202?spm=a2g0o.detail.1000007.1.704e2bedqLBW90

Ebay Store: https://www.ebay.com/str/alinxfpga

Customer Service Information

Wechat/Skype: 15026866269

Technical Email:[email protected]om

Sales Email: rachel.zhou@aithtech.com

ARTIX-7 FPGA Development Board AX7A200 User Manual

3 / 59

Amazon Store: https://www.amazon.com/alinx

Sales Email: rachel.zho[email protected]

Table of Contents

Version Record .............................................................................................2

Part 1: FPGA Development Board Introduction .......................................... 6

Part 2: AC7A200 Core Board .................................................................... 10

Part 2.1: AC7A200 Core Board Introduction ......................................10

Part 2.2: FPGA Chip ........................................................................... 12

Part 2.3: Active Differential Crystal .....................................................13

Part 2.4: DDR3 DRAM ........................................................................16

Part 2.5: QSPI Flash ...........................................................................19

Part 2.6: LED Light on Core Board .................................................... 21

Part 2.7: JTAG Interface .....................................................................22

Part 2.8: Power Interface on the Core Board .....................................23

Part 2.9: Board to Board Connectors pin assignment ....................... 24

Part 2.10: Power Supply .....................................................................31

Part 2.11: Core Board Form Factors ..................................................34

Part 3: Carrier Board ..................................................................................35

Part 3.1: Carrier Board Introduction ................................................... 35

Part 3.2: Gigabit Ethernet Interface ................................................... 36

Part 3.3: SFP Interface ....................................................................... 38

Part 3.4: PCIe x2 Interface ................................................................. 40

Part 3.5: HDMI output interface ..........................................................41

Part 3.6: HDMI Input interface ............................................................43

Part 3.7: SD Card Slot ........................................................................45

Part 3.8: USB-to-Uart Bridge Connector ............................................46

Part 3.9: EEPROM 24LC04 ................................................................48

Part 3.10: Temperature Sensor .......................................................... 49

Part 3.11: Expansion Header ............................................................. 50

Part 3.12: JTAG Interface ...................................................................53

ARTIX-7 FPGA Development Board AX7A200 User Manual

4 / 59

Amazon Store: https://www.amazon.com/alinx

Sales Email: rachel.zho[email protected]

Part 3.13: Buttons ...............................................................................54

Part 3.14: LED Light ........................................................................... 55

Part 3.15: Power Supply .....................................................................57

Part 3.16: Fan ..................................................................................... 58

Part 3.17: Carrier Board Form Factors .............................................. 59

ARTIX-7 FPGA Development Board AX7A200 User Manual

5 / 59

Amazon Store: https://www.amazon.com/alinx

Sales Email: rachel.zho[email protected]

This ARTIX-7 FPGA development platform adopts the core board + carrier

board mode, which is convenient for users to use the core board for secondary

development.

In the design of carrier board, we have extended a wealth of interfaces for

users, such as 1 PCIex2 interface, 2 SFP cage, 1 HDMI Output interface, 1

HDMI Input interface, 1 Gigabit Ethernet interfaces, Uart Interface, SD card slot

etc. It meets user's requirements for PCIe high-speed data exchange, video

transmission processing and industrial control. It is a "Versatile" ARTIX-7 FPGA

development platform. It provides the possibility for high-speed video

transmission, pre-validation and post-application of network, fiber and PCIe

communication and data processing. This product is very suitable for students,

engineers and other groups engaged in ARTIX-7 FPGA development.

ARTIX-7 FPGA Development Board AX7A200 User Manual

6 / 59

Amazon Store: https://www.amazon.com/alinx

Sales Email: rachel.zho[email protected]

Part 1: FPGA Development Board Introduction

The entire structure of the AX7A200 FPGA development board is inherited

from our consistent core board + carrier board model. A high-speed inter-board

connector is used between the core board and the carrier board.

The core board is mainly composed of FPGA + 2 DDR3 + QSPI FLASH,

which undertakes the functions of high-speed data processing and storage of

FPGA, high-speed data reading and writing between FPGA and two DDR3s,

data bit width is 32 bits, and the bandwidth of the whole system is up to 25Gb.

/s(800M*32bit); The two DDR3 capacities are up to 8Gbit, which meets the

need for high buffers during data processing. The selected FPGA is the

XC7A200T chip of XILINX's ARTIX-7 series, in BGA 484 package. The

communication frequency between the XC7A200T and DDR3 reaches 400Mhz

and the data rate is 800Mhz, which fully meets the needs of high-speed

multi-channel data processing. In addition, the XC7A200T FPGA features four

GTP high-speed transceivers with speeds up to 6.6Gb/s per channel, making it

ideal for fiber-optic communications and PCIe data communications.

The AX7A200 carrier board expands its rich peripheral interface, including

1 PCIex2 interface, 2 SFP Interface, 1 HDMI Output interface, 1 HDMI Input

interface, 1 Uart Interface, 1 Gigabit Ethernet interfaces,1 SD card slot, 2-way

40-pin expansion header, some buttons, LED and EEPROM circuit.

ARTIX-7 FPGA Development Board AX7A200 User Manual

7 / 59

Amazon Store: https://www.amazon.com/alinx

Sales Email: rachel.zho[email protected]

Figure 1-1-1: The Schematic Diagram of the AX7A200

Through this diagram, you can see the interfaces and functions that the

AX7102 FPGA Development Board contains:

Artix-7 FPGA core board

The core board consists of XC7A200T + 8Gb DDR3 + 128Mb QSPI

FLASH. There are two high-precision Sitime LVDS differential crystals,

one at 200MHz and the other at 125MHz, providing stable clock input

for FPGA systems and GTP modules.

1-channel PCIe x2 interface

Supports PCI Express 2.0 standard, provides PCIe x 2 high-speed data

transmission interface, single channel communication rate up to

5Gbaud

2-channel high-speed SFP Interface

The two high-speed transceivers of the GTP transceiver of ARTIX-7

FPGA are connected to the transmission and reception of two optical

modules to realize four high-speed optical fiber communication

ARTIX-7 FPGA Development Board AX7A200 User Manual

8 / 59

Amazon Store: https://www.amazon.com/alinx

Sales Email: rachel.zho[email protected]

interfaces. Each fiber optic data communication receives and transmits

at speeds up to 6.6 Gb/s.

1-channel Gigabit Ethernet Interface RJ-45 interface

The Gigabit Ethernet interface chip uses Micrel's KSZ9031RNX

Ethernet PHY chip to provide network communication services to users.

The KSZ9031RNX chip supports 10/100/1000 Mbps network

transmission rates; full duplex and adaptive.

1-channel HDMI Output interface

Silion Image's SIL9134 HDMI encoding chip is selected to support up to

1080P@60Hz output and support 3D output.

1-channel HDMI Input interface

Silion Image's SIL9011/ SIL9013 HDMI decoder chip is selected, which

supports up to 1080P@60Hz input and supports data output in different

formats.

1-channel USB-to-Uart interface

1-channel USB-to-Uart interface for communication with the computer

for user debugging. The serial port chip is the USB-UAR chip of Silicon

Labs CP2102GM, and the USB interface is the MINI USB interface.

Micro SD card holder

1-port Micro SD card slot, support SD mode and SPI mode

EEPROM

Onboard an IIC interface EEPROM 24LC04

2-way 40-pin expansion port

Reserve 2-way 40-pin 0.1inch pitch expansion port can be connected

to various AXSOC modules (binocular camera, TFT LCD screen,

high-speed AD module, etc.). The expansion port contains 1 channel

5V power supply, 2 channel 3.3V power supply, 3 way ground, 34 IOs

port.

JTAG Interface

ARTIX-7 FPGA Development Board AX7A200 User Manual

9 / 59

Amazon Store: https://www.amazon.com/alinx

Sales Email: rachel.zho[email protected]

A 10-pin 0.1 inch spacing standard JTAG ports for FPGA program

download and debugging.

Button

4 buttons; 1 reset button (on the core board)

LED Light

5 user LEDs (1 on the core board and 4 on the carrier board)

ARTIX-7 FPGA Development Board AX7A200 User Manual

10 / 59

Amazon Store: https://www.amazon.com/alinx

Sales Email: rachel.zho[email protected]

Part 2: AC7A200 Core Board

Part 2.1: AC7A200 Core Board Introduction

AC7A200 (core board model, the same below) FPGA core board, it is

based on XILINX's ARTIX-7 series 100T XC7A200T-2FBG484I. It is a

high-performance core board with high speed, high bandwidth and high

capacity. It is suitable for high-speed data communication, video image

processing, high-speed data acquisition etc.

This AC7A200 core board uses two pieces of MICRON's

MT41J256M16HA-125 DDR3 chip, each DDR has a capacity of 4Gbit; two

DDR chips are combined into a 32-bit data bus width, and the read/write data

bandwidth between FPGA and DDR3 is up to 25Gb; such a configuration can

meet the needs of high bandwidth data processing.

The AC7A200 core board expands 180 standard IO ports of 3.3V level, 15

standard IO ports of 1.5V level, and 4 pairs of GTP high speed RX/TX

differential signals. For users who need a lot of IO, this core board will be a

good choice. Moreover, the routing between the FPGA chip and the interface is

equal length and differential processing, and the core board size is only 2.36

inch *2.36 inch, which is very suitable for secondary development.
