TR7386T4B

EN User Manual | Tumble Dryer

aeg.com\register

FOR PERFECT RESULTS

Thank you for choosing this AEG product. We have created it to give you impeccable

performance for many years, with innovative technologies that help make life simpler –

features you might not find on ordinary appliances. Please spend a few minutes reading

to get the very best from it.

Visit our website to:

Get usage advice, brochures, trouble shooter, service and repair information:

www.aeg.com/support

www.registeraeg.com

Buy Accessories, Consumables and Original spare parts for your appliance:

www.aeg.com/shop

CUSTOMER CARE AND SERVICE

Always use original spare parts.

When contacting our Authorised Service Centre, ensure that you have the following data

available: Model, PNC, Serial Number.

The information can be found on the rating plate.

Warning / Caution-Safety information

General information and tips

Environmental information

Subject to change without notice.

CONTENTS

1. SAFETY INFORMATION................................................................................ 3

2. SAFETY INSTRUCTIONS.............................................................................. 6

3. PRODUCT DESCRIPTION............................................................................. 8

4. CONTROL PANEL.......................................................................................... 9

5. PROGRAMMA'S .......................................................................................... 10

6. OPTIONS...................................................................................................... 13

7. BEFORE FIRST USE....................................................................................14

8. DAILY USE....................................................................................................15

9. HINTS AND TIPS.......................................................................................... 17

10. CARE AND CLEANING.............................................................................. 18

11. TROUBLESHOOTING................................................................................ 21

12. TECHNICAL DATA..................................................................................... 23

13. PRODUCT INFORMATION SHEET IN REFERENCE TO E.U.

REGULATION 1369/2017................................................................................. 25

14. ENVIRONMENTAL CONCERNS................................................................26

2 ENGLISH

1. SAFETY INFORMATION

Before beginning the installation and use of this

appliance, carefully read the supplied instructions.

The manufacturer is not responsible for any injuries or

damage that are the result of incorrect installation or usage.

Always keep the instructions in a safe and accessible location

for future reference.

Warning: Risk of fire / Flammable materials.

The appliance contains flammable gas, propane (R290), a

gas with a high level of environmental compatibility. Keep fire

and ignition sources away from the appliance. Be careful not

to cause damage to the refrigerant circuit containing propane.

1.1 Children and vulnerable people safety

WARNING!

Risk of suffocation, injury or permanent disability.

• This appliance can be used by children aged from 8 years

and above and persons with reduced physical, sensory or

mental capabilities or lack of experience and knowledge if

they have been given supervision or instruction concerning

the use of the appliance in a safe way and understand the

hazards involved.

• Children between 3 and 8 years of age and persons with

very extensive and complex disabilities shall be kept away

from the appliance unless continuously supervised.

• Children of less than 3 years of age should be kept away

from the appliance unless continuously supervised.

• Do not let children play with the appliance.

• Keep all packaging away from children and dispose of it

appropriately.

• Keep detergents away from children.

ENGLISH 3

• Keep children and pets away from the appliance when the

door is open.

• If the appliance has a child safety device, it should be

activated.

• Children shall not carry out cleaning and user maintenance

of the appliance without supervision.

1.2 General Safety

• This appliance is for drying domestic-type, machine-dryable

laundry only.

• Do not use the dryer function if laundry has been soiled with

industrial chemicals.

• This appliance is designed for single household domestic

use in an indoor environment.

• This appliance may be used in, offices, hotel guest rooms,

bed & breakfast guest rooms, farm guest houses and other

similar accommodation where such use does not exceed

(average) domestic usage levels.

• Do not change the specification of this appliance.

• If the tumble dryer is put on top of a washing machine, use

the stacking kit. The stacking kit, available from your

authorized vendor, can be used only with the appliance

specified in the instructions supplied with the accessory.

Read it carefully before installation (refer to the Installation

leaflet).

• The appliance can be installed as freestanding or below a

kitchen counter with correct space (refer to the Installation

leaflet).

• Do not install the appliance behind a lockable door, a sliding

door or a door with a hinge on the opposite side, that would

prevent the appliance door from being fully open.

• The ventilation opening in the base must not be covered by

a carpet, mat, or any floor covering.

• WARNING: The appliance must not be supplied through an

external switching device, such as a timer, or connected to

a circuit that is regularly switched on and off by a utility.

4 ENGLISH

• Connect the mains plug to the mains socket only at the end

of the installation process. Make sure that the mains plug is

accessible after installation.

• Ensure good air ventilation in the room where the appliance

is installed to avoid the backflow of unwanted gases into the

room from appliances burning gas or other fuels, including

open fires.

• WARNING: Do not install the appliance in an environment

with no air exchange.

The appliance contains flammable gas, propane (R290), a

gas with a high level of environmental compatibility. Keep

fire and ignition sources away from the appliance. Be

careful not to cause damage to the refrigerant circuit

containing propane.

• WARNING: In the appliance enclosure or in the built -in

structure, keep ventilation opening clear of obstruction.

• WARNING: Do not damage the refrigerant circuit.

• If the mains power supply cable is damaged, it must be

replaced by the manufacturer, its Authorised Service Centre

or similarly qualified persons to avoid an electrical hazard.

• Do not exceed the maximum load of 8,0 kg (refer to the

"Programme chart" chapter).

• Wipe away lint or packaging debris that has accumulated

around the appliance.

• Do not run the appliance without a filter. Clean the lint filter

before or after each use.

• Do not dry unwashed items in the tumble dryer.

• Items that have been soiled with substances such as

cooking oil, acetone, alcohol, petrol, kerosene, spot

removers, turpentine, waxes and wax removers should be

washed in hot water with an extra amount of detergent

before being dried in the tumble dryer.

• Items such as foam rubber (latex foam), shower caps,

waterproof textiles, rubber backed articles and clothes or

pillows fitted with foam rubber pads should not be dried in

the tumble dryer.

ENGLISH 5

• Fabric softeners, or similar products, should only be used

as specified by the product manufacturer’s instructions.

• Remove all objects from items that could be a source of fire

ignition such as lighters or matches.

• WARNING: Never stop a tumble dryer before the end of the

drying cycle unless all items are quickly removed and

spread out so that the heat is dissipated.

• Before any maintenance operation, deactivate the

appliance and disconnect the mains plug from the socket.

2. SAFETY INSTRUCTIONS

2.1 Installation

Warning: Risk of fire / Flammable

materials.

• Remove all the packaging.

• Do not install or use a damaged

appliance.

• Follow the installation instructions supplied

with the appliance.

• Do not install the appliance in an

environment with no air exchange

The appliance contains flammable gas,

propane (R290), a gas with a high level of

environmental compatibility. Keep fire and

ignition sources away from the appliance.

Be careful not to cause damage to the

refrigerant circuit containing propane.

• Always take care when moving the

appliance as it is heavy. Always use safety

gloves and enclosed footwear.

• Do not install or use the appliance where

the temperature can be lower than 5°C or

higher than 35°C.

• The floor area on which the appliance is to

be installed must be flat, stable, heat

resistant and clean.

• Make sure that there is air circulation

between the appliance and the floor.

• Always keep the appliance vertical when it

is being moved.

• The rear surface of the appliance must be

put against a wall.

• When the appliance is in its permanent

position, check if it is levelled correctly

with the aid of a spirit level. If it is not,

adjust the feet accordingly.

2.2 Electrical connection

WARNING!

Risk of fire and electric shock.

• Connect the mains plug to the mains

socket only at the end of the installation.

Make sure that there is access to the

mains plug after the installation.

• WARNING: This appliance is designed to

be installed / connected to a grounding

connection in the building.

• Make sure that the parameters on the

rating plate are compatible with the

electrical ratings of the mains power

supply.

• Always use a correctly installed

shockproof socket.

• Do not use multi-plug adapters and

extension cables.

• Do not pull the mains cable to disconnect

the appliance. Always pull the mains plug.

• Do not touch the mains cable or the mains

plug with wet hands.

2.3 Use

WARNING!

Risk of injury, electric shock, fire, burns

or damage to the appliance.

6 ENGLISH

Warning: Risk of fire / Flammable

materials. The appliance contains flammable

gas, propane (R290), a gas with a high level

of environmental compatibility. Keep fire and

ignition sources away from the appliance. Be

careful not to cause damage to the refrigerant

circuit containing propane.

• This appliance is for household (indoors)

use only.

• Do not dry damaged (torn, frayed) items

that contain padding or fillings.

• If laundry has been washed with a stain

remover, carry out an additional rinse

cycle before starting a drying cycle.

• Dry only fabrics that are suitable to dry in

the appliance. Follow the cleaning

instruction on the item label.

• Do not drink or prepare food with the

condensed water/distilled water. It can

cause health problems to people and pets.

• Do not sit or stand on the open door of the

appliance.

• Do not dry dripping wet clothes in the

appliance.

2.4 Care and cleaning

WARNING!

Risk of injury or damage to the appliance.

Warning: Risk of fire / Flammable

materials. The appliance contains flammable

gas, propane (R290), a gas with a high level

of environmental compatibility. Keep fire and

ignition sources away from the appliance. Be

careful not to cause damage to the refrigerant

circuit containing propane.

• Do not use water spray and steam to

clean the appliance.

• Clean the appliance with a moist soft

cloth. Use only neutral detergents. Do not

use abrasive products, abrasive cleaning

pads, solvents or metal objects.

• Be careful when you clean the appliance

to prevent damage to the cooling system.

2.5 Compressor

WARNING!

Risk of damage to the appliance.

• The compressor and its system in the

tumble dryer is filled with a special agent

which is free from fluoro-chloro-

hydrocarbons. This system must stay

tight. The damage of the system can

cause a leakage.

2.6 Service

• To repair the appliance contact the

Authorised Service Centre.

• Use original spare parts only.

• Concerning the lamp(s) inside this product

and spare part lamps sold separately:

These lamps are intended to withstand

extreme physical conditions in household

appliances, such as temperature,

vibration, humidity, or are intended to

signal information about the operational

status of the appliance. They are not

intended to be used in other applications

and are not suitable for household room

illumination.

2.7 Disposal

WARNING!

Risk of injury or suffocation.

Warning: Risk of fire / Risk of material

damage and damage to the appliance.

• Disconnect the appliance from the mains

electrical and water supplies.

• Cut off the mains electrical cable close to

the appliance and dispose of it.

• The appliance contains flammable gas

(R290). Contact your municipal authority

for information on how to discard the

appliance correctly.

• Remove the door catch to prevent children

or pets from becoming trapped in the

drum.

• Dispose of the appliance in accordance

with local requirements for the disposal of

Waste Electrical and Electronic Equipment

(WEEE).

ENGLISH 7

3. PRODUCT DESCRIPTION

1 2

1Water container

2Control panel

3Appliance door

4Filter

5Rating plate

6Airflow slots

7Condenser lid

8Condenser cover

9Adjustable feet

For ease of loading laundry or ease of

installation the door is reversible (see the

separate leaflet).

00000000

00A

Mod. xxxxxxxxx

000V ~ 00Hz 0000 W

910000000 00

Prod.No.

A B C D

The rating plate reports:

A. model name

B. product number

C. electrical ratings

D. serial number

8 ENGLISH

4. CONTROL PANEL

1Program dial

2Display

3Start/Pauze button

4Options

5Aan/Uit button with

Auto Off

function

6Programs

4.1 Display

Symbol on the display Symbol description

cycle time indication

maximum load

-delay start selection (30min-20h)

ENGLISH 9

Symbol on the display Symbol description

+ Anti-kreuk option on

Stil option on

buzzer off

child lock on

, , laundry dryness: iron dry, cupboard dry, extra dry

Droogtijd option on

indicator:

drain the water container

indicator:

clean the filter

indicator:

check the condenser

indicator:

drying phase

indicator:

cooling phase

indicator:

crease guard phase

Startuitstel option on

5. PROGRAMMA'S

Programma's Load 1) Properties / Fabric mark 2)

MixDry 5,0 kg

Designed for routine drying of what you

wash without sorting. Dries evenly clothes

made of cotton, cotton-synthetic blends and

synthetic.

/ , ,

Katoen Eco 8,0 kg Cotton fabrics programme designed for

maximum energy saving. / ,

Katoen 8,0 kg

White and coloured cotton fabrics pro‐

gramme. Default setting is for ready to store

dryness level. / ,

Synthetica 4,0 kg Blended garments containing mostly syn‐

thetic fibres like polyester, polyamide, etc. / , ,

Fijne Was 2,0 kg

Recommended for generic delicate fabrics

such as viscose, rayon, acrylic and their

blends. / , ,

Wol 1,0 kg Woollen fabrics. Gentle drying of washable woollens. Re‐

move items immediately when the programme is completed.

10 ENGLISH

Table of contents

Popular Dryer manuals by other brands

Bosch

Bosch WTA79200GB Installation and operating instructions

Amana

Amana W10233410A Use and care guide

Miele

Miele TWH 780 WP operating instructions

Asko

Asko T760 user guide

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Original instructions

Bosch

Bosch Logixx 10 WTB76556GB Instruction manual and installation instructions

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Operation and installation

Electrolux

Electrolux EW2H328R2 user manual

Beko

Beko DS8433RX1M user manual

Dawlance

Dawlance Spinner DS 6000 C owner's manual

Electrolux

Electrolux TP5080TW user manual

Indesit

Indesit IDV 75 instruction manual

Infiniton

Infiniton SD-DG85C manual

BOMANN

BOMANN WT 5019 instruction manual

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Installation

Asko

Asko T793C operating instructions

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer installation instructions

Frigidaire

Frigidaire CAQE7077KW0 use & care
