Advantech EmbCore ROM-7421 User manual

ROM-7421 Evaluation Board

Quick Start Guide

Contents

1. Copyright Notice

2. Introduction

3. Quick installation of ROM-7421 evaluation board

3.1 Evaluation Boards Specification

3.2 Proper Handling Method

4. ROM-7421 quick start

4.1 Debug Port handling

4.2 Power on evaluation board

4.3 Jumper setting

5. I/O Specification

5.1 ROM-7421 evaluation board overview

5.2 Connectors and Headers

6. Test Scripts

1. Copyright Notice

This document is copyrighted, 2016 by Advantech Co., Ltd. All rights are reserved.

Advantech Co., Ltd. reserves the right to make improvements to the products described in this

document at any time. Specifications are thus subject to change without notice.

No part of this document may be reproduced, copied, translated, or transmitted in any form or by

any means without the prior written permission of Advantech Co., Ltd. Information provided in

this manual is intended to be accurate and reliable. However, Advantech Co., Ltd. assumes no

responsibility for its use, or for any infringements upon the rights of third parties which may result

from its use.

All the trademarks of products and companies mentioned in this document belong to their

respective owners.

2. Introduction

This document is to introduce ROM-7421 evaluation boards and let the end users start module

evaluation easily and smoothly. It includes 2 parts of concepts: Start-up process and the detail

input/output connector and pin header specifications.

ROM-7421 evaluation boards are ROM-7421 RISC Qseven 2.0 module based on NXP i.MX6

Dual/Quad Plus 1GHz SoC and its corresponding carrier board ROM-DB7501 Advantech RISC

Qseven 2.0 Evaluation Carrier Board. It is highly recommended to completely read this document

before starting ROM-7421 board evaluation since it includes critical information as pin define,

handling process and connector information. In the meanwhile, you should also comply with all

warming notices and regulations you read in this document, it can prevent damaging ROM-7421

evaluation boards and spoiling those devices being connected.

Inappropriate installation may cause physical damage to ROM-7421 and its carrier board

ROM-DB7501, result in function loss or abnormal behaviors as kernel panic or unstable electric

currents in the evaluation kit. In this case, we would identify this inappropriate use of evaluation

kit as human negligence and it is excluded from our quality assurance policy.

For more information about Advantech’s product, please go visiting: www.advantech.com

For RISC product offering, please go visiting: risc.advantech.com

3. Quick installation of ROM-7421 evaluation kit

3.1 Evaluation Boards Specification

Item

Description

Kernel

CPU

Freescale i.MX6 Dual/Quad Plus 1GHz (ARM Cortex-A9)

2D/3D Accelerators

Support OpenGL ES 2.0 and OpenVG™ 1.1 hardware accelerators

System RAM

1GB/2GB

Onboard Flash

4GB

RTC

Yes

Watchdog Timer

Yes

Reset

H/W reset & S/W reset

I/O

COM

-Console, RS-232, 2–wire(TX/RX), Reserved

-COM 1, RS-232, 4–wire(TX/RX/RTS/CTS), Connector

-COM 2, RS-232, 4–wire(TX/RX/RTS/CTS), DB9

Ethernet LAN

1 x 10/100/1000 Gigabit Ethernet(RJ-45)

USB Port

2 x USB 2.0 Type A, 1x USB 2.0 Pin Header (2 USB 2.0)

USB OTG

1 x USB 2.0 OTG

SD/MMC

1 x SD/MMC card slot

PCI-E

1 x PCIe Gen2 LAN1

SATA

1 x

I2C Interface

1 x

I2S Interface

1 for audio codec adapter board

SPI Interface

1 x

CAN BUS

1 x 5V level

GPIO

8 x 3.3V level GPIOs

Battery

1 x

Multimedia

Graphic Chip

CPU internal LCD controller

LCD Resolution

Default: 800 x 480 7” WVGA

Optional: 320 x 240 ~ 1920 x 1080

LVDS

2 x

HDMI

1 x

VGA

1 x

Brightness/

Backlight Control

Yes

Audio

Line-out&Mic-in (with Codec adapter board support)

Camera

1 x MIPI CSI

Power

Power-on Type

AT/ATX

DC-input

12V

Power Consumption

Normal Run: 2.5W

Full Run: 5W

Power Control

1 x Power button

1 x Reset button

1 x Sleep mode button

Power

Management

-Standard mode

-Sleep mode

Mechanical and Environmental

Board size

ROM-7420: 70x70x5mm (PCB thickness 1.2mm; 10 layers)

ROM-DB7500: 170 x 170 x 30 mm (PCB thickness 1.2mm; 8

layer)

Weight

225g

Operation

Temperature

-40 ~ 85°C (32 ~ 140°F)

Operating

Humidity

5% ~ 95% Relative Humidity, non condensing

Vibration

3.5G, 1000 times

Others

RoHS

Yes

Certification

CE/FCC Class B

O.S

Yocto Linux

3.2 Proper Handling Method

①Please insert ROM-7421 module to carrier board ROM-DB7501 properly.

②Please fix the screws properly.

4. ROM-7421 quick start

4.1 Debug Port handling

①Connect debug port cable to debug port adapter board, make sure the jumpers

are set as below:

②Connect debug port to ROM-7421

③Connect debug adapter board to a COM port cable then connect to PC

④Set hyper terminal in your PC as below

4.2 Power on evaluation board

①Insert power adapter cable to DC-in jack, make sure it is a +12V power adapter

②Press the power button on ROM-DB7501

4.3 Jumper setting

①LVDS Jumper

LVDS_VDD1

Panel Power Setting

Description

Panel Power for LVDS1

(1-2)

(2-3)

LVDS_VDD3

Panel Power Setting

Description

Panel Power for LVDS2

(1-2)

(2-3)

LVDS_VDD4

Panel Power Setting

Description

Panel Power for LVDS2

(1-2)

12V

②LVDS Backlight Inverter

LVDS_BL1

Panel Power Setting

Description

Panel Inverter for LVDS1

(1-2)

(2-3)

12V

LVDS_BL2

Panel Power Setting

Description

Panel Inverter for LVDS1

(1-2)

(2-3)

12V
