Adam Equipment NETS Product information sheet

1 | P a g e © Adam Equipment Company 2010

Adam Equipment

NETS Price

Computing Scale

RevA, May 2011

Specifications are subject to change without notice to improve

2 | P a g e © Adam Equipment Company 2010

Thank you for the choosing our label printing scale NETS, we are always trying

to serve you with better quality as a reliable weighing instrument and enhanced

features supporting various kinds of applications

1. SPECIFICATIONS ------------------------------------------------------------------------------- 2

2. OPTIONS --------------------------------------------------------------------------------------------

3. PRECAUTIONS ---------------------------------------------------------------------------------

4. OVERVIEWS --------------------------------------------------------------------------------------

5. INSTALLATION ---------------------------------------------------------------------------------

6. KEYBOARDS AND FUNCTION -------------------------------------------------------------- 5

7. THE DESIGNATORS -------------------------------------------------------------------------

8. THE SELLING MODE ------------------------------------------------------------------------

9. THE SET MODE -------------------------------------------------------------------------------

10. THE OTHERS ----------------------------------------------------------------------------------

11. SAMPLE LABEL FORMAT ----------------------------------------------------------------- 44

Model NETS

Maximum capacity 6 kg / 15 kg

Minimum graduation 2g / 5g

Maximum Tare Full Tare

Internal resolution 1 / 60,000

Widths(mm)

Paper / Label / printing

60 / 58 / 56

Available Labels(mm) 35, 40, 60, 80, 100

Label roll size(mm) Max. φ120(1,200 labels at 40mm length)

Printing Speed(mm) 80 ~ 100

Speed PLU keys 60

PLU memory Standard Memory(0.5MB) : 1000 labels at 500 characters

Extended Memory (1MB)

Numeric Displays(digit)

Message Display LED Price(8) , Weight (5) , Unit price(7)

LCD Graphic 256 x 32 pixels

Platter size mm(inch) 415(16.3) x 260(10.2)

Product size mm(inch) W460(18.1) x D440(17.3) x H470(18.5)

Power source AC 100 ~ 240 / 50 , 60 Hz (Free Voltage)

Power consumption Printing : Approx. 100W max.

Stand by : Approx. 40W

1. Network Board 2. Extended PLU memory 3. Weight conversion

TCP/IP protocol kg ↔lb conversion

3 | P a g e © Adam Equipment Company 2010

1. Place the scale on a flat and rigid desk that is free of vibrations

2. Place the scale out of direct sunlight

3. Do not use radio devices which emits strong electromagnetic fields near by

4. Do not apply sudden impact to the platter

5. Always level the scale

6. Do not spill the water to the scale

7. Do not use cleaners which includes solvent or sinner

8. Scale should be calibrated by authorized person prior to being to used

9. Turn on the scale 10 minutes before using

Cartridge

4 | P a g e © Adam Equipment Company 2010

Displays

Key Board

I/O Connections

RS-232C Network Option

AC Connect Fuse- Holder

External Keyboard

Option

Cash Drawer

Option

Power Switch

| P a g e © Adam Equipment Company 2010

1. Place the scale on a flat and rigid desk

2. Insert two display wire connectors between displays and scale

3. Erect the display pole into display bracket

4. Arrange the display wire and block the bottom of bracket with plate

5. Fasten display bracket and plate with 4 x M3 screws

6. Level the scale

7. Turn on the scale

Name of Key Functions

Numeric keys,

used to enter unit price and programming data

Clear key,

used to clear unit price and programming data

Zero key,

used to correct weight display to zero( 0.000) when scale has been

drifted

Tare key, used to set or remove tare(container) weight,

after tare set scale displays net weight and the designator “NET” is

turned on

Auto key, used to set scale to automatic printing mode,

scale prints automatically after weight stable, the designator “AUTO”

is turned on while this function is activated, key works by toggle

Save key, used to save current PLU, the designator “SAVE” is turned on

while this function is activated,

key works by toggle

Set key, used to enter to set mode, toggle key

Function key,

Escape key, used to cancel of previous transaction(s),

escape from each menu of the set mode

Add up key,

used to add up of commodities

PLU key,

used to call indirect PLU

0 9

ZERO

TARE

AUTO

SAVE

SET

FUNC

ESC

ADD

PLU

6 | P a g e © Adam Equipment Company 2010

Name of Key Functions

Multiple key,

used to printing of same labels

For key,

used to selling by number

Feed key,

Used to feeding a label or ticket

Print key,

Used to printing label or ticket

Designators Functions

ZERO It indicates scale is on centre of zero

STABLE It indicates scale is stable

NET It indicates tare has been set

SHIFT It indicates shift function in PLU programming

CAPS LOCK It indicates function of entering capital letter

INS It indicates function of insertion

COM It indicates scale is under communication

AUTO It indicates automatic printing mode

SAVE It indicates PLU saving mode

SALE It indicates sale mode

FUNC It indicates scale is under function mode

FOR

FEED

7 | P a g e © Adam Equipment Company 2010

Selling mode consists of 4 subsidiary mode, refer to the listed page for the details

Note : Scale dose not print out any label or ticket unless PLU has been programmed,

)

See Page 8

)

See Page 9

)

See Page 10

)

See Page 11

8 | P a g e © Adam Equipment Company 2010

refer to the EDIT PLU of the SET MODE

Weighing(normal) mode

Enter PLU by pressing one of SPEED

key(direct) or by enter PLU number

and press PLU key(indirect)

Put commodity(Fillet) on the platter

and press PRINT key

While the designator AUTO is turned

on, scale prints automatically

Remove commodity on the platter

While the designator SAVE is turned

on, scale saves current PLU

0.000 0.00 0.00

Enter PLU

1.200 5.90 7.08

FILLET

0.000 0.00 0.00

0.000 5.90 0.00

FILLET

)

Enter PLU

9 | P a g e © Adam Equipment Company 2010

Weighing(normal) mode

Enter PLU by pressing one of SPEED

key(direct) or by enter PLU number

and press PLU key(indirect)

Press FOR key

Enter number of commodity(Candy)

and PRINT key

Weighing mode

0.000 0.00 0.00

Enter PLU

1 0.25 0.25

SWEET CANDY

50 0.25 12.50

SWEET CANDY

0.000 0.25 0.00

SWEET CANDY

0.000 0.00 0.00

Enter PLU

10 | P a g e © Adam Equipment Company 2010

Weighing(normal) mode

Enter PLU by pressing one of SPEED

key(direct) or by enter PLU number

and press PLU key(indirect)

Put commodity(Tenderloin) on the

platter and press ADD key

Remove the commodity(Tenderloin)

and enter another PLU

Put the commodity(Fillet) on the platter

0.000 0.00 0.00

Enter PLU

1.000 7.99 7.99

ADD UP

0.000 5.90 0.00

FILLET

0.000 7.99 0.00

TENDERLOIN

1.200 5.90 7.08

FILLET

)
