ABB ControlMaster CM10 User manual

User Guide – Standard Functionality IM/CM/S–EN Rev. R

ControlMaster CM10, CM30 and CM50

Universal process controllers, 1/8, 1/4and 1/2DIN

The Company

We are an established world force in the design and manufacture of instrumentation for industrial process control,

flow measurement, gas and liquid analysis and environmental applications.

As a part of ABB, a world leader in process automation technology, we offer customers application expertise, service

and support worldwide.

We are committed to teamwork, high quality manufacturing, advanced technology and unrivalled service and

support.

The quality, accuracy and performance of the Company’s products result from over 100 years experience, combined

with a continuous program of innovative design and development to incorporate the latest technology.

Language

Operator Templates

Page 1 (4) Template

Operator Functions

Autoscroll

Soft Key Function

Auto Manual Enable

Local Remote Enable

Alarm Ack. Enable

SP Adjust Enable

Settings

Brightness

Contrast*

Date & Time

Date Format

Time & Date

Daylight Saving

SP Adjust Enable

Analog Inputs

Anlg Input 1 (4)

Analog Outputs

Analog Output 1 (2)

Digital I/O

Digital IO 1 (6)

Relays

Relay 1 (4)

Loop 1 Setpoints

Low Limit

High Limit

No. of Local SP’s

Local Setpoint 1

Track Mode

RSP Ratio

RSP Bias

RSP Fault Action

Default Setpoint

Ramp Mode

Ramp Rate

Select Sources

Loop 1 Control

Control Type

Control Action

On/Off Hysteresis

Autotune

PID

Loop 1 Output

Limits

Failure Actions

A/M Select Sources

Slew Rate

Tracking

Loop 1 Split O/P

Min Input 1

Min OP 1

Max Input 1

Max OP 1

Min Input 2

Min OP 2

Max Input 2

Max OP 2

Loop 1 Time Prop

Cycle Time 1

Cycle Time 2

Basic Device Setup Display Input/Output Control

Menu Menu Menu

Exit Select Exit Select Exit Select Exit Select Exit Select

Initial Setup

App. Template

Loop 1 Output Type

Loop 1 Split O/P

Instrument Tag

Mains Freq.

Config Action

Custom Template

Reset to Defaults

Security Setup

Basic Password

Advanced Password

Reset Passwords

Custom Config

Note. When in Advanced Level (configuration) mode, press and hold the key to return to the standard Operator page – see Fig. 3.1, page 5

*Enabled for CM30 and CM50 only

Refer to Section 7.2, page 39 Refer to Section 7.3, page 43 Refer to Section 7.4, page 51Refer to Section 6, page 27 Refer to Section 7.1, page 36

Menu Menu

See

Back

Cover

Loop 1 Setpoints

Local Setpoint 1 (4)

RSP Ratio

RSP Bias

Ramp Mode

Ramp Rate

Loop 1 Control

On/Off Hysteresis

Mode

Autotune

PID

Loop 1 Mot Valve

Ratio

Bias

Deadband

Travel Time

Loop 1 Time Prop

Cycle Time 1

Cycle Time 2

Alarm 1 (8)

Trip

ControlMaster CM10, CM30 and CM50

Universal process controllers, 1/8, 1/4and 1/2DIN Contents

IM/CM/S–EN Rev. R 1

Contents

1 Safety .......................................................................... 3

1.1 Electrical Safety ..................................................... 3

1.2 Symbols ................................................................ 3

1.3 Health & Safety ..................................................... 4

2 Introduction ................................................................ 4

2.1 EC Directive 89 / 336 / EEC .................................. 4

2.2 End of Life Disposal ............................................... 4

3 Displays, Icons and Keys .......................................... 5

3.1 CM10 Operator Page, Icons and Keys .................. 5

3.2 CM30 and CM50 Operator Page, Icons & Keys .... 6

4 Installation ................................................................... 8

4.1 Siting and Environmental Requirements ................. 8

4.2 Dimensions ............................................................ 9

4.3 Mounting ............................................................. 11

4.4 Jumper Links for Relay Outputs ........................... 12

4.4.1 Removing the Controller from its Case ...... 12

4.4.2 Resetting Jumper Links ............................. 13

4.5 Electrical Connections ......................................... 14

4.5.1 CM10 Electrical Connections ..................... 15

4.5.2 CM30 Electrical Connections ..................... 16

4.5.3 CM50 Electrical Connections ..................... 17

4.5.4 Analog Inputs ........................................... 18

4.5.5 Frequency / Pulse Input ............................. 20

4.5.6 Digital Input / Output ................................. 20

5 Operator Level Menus .............................................. 22

5.1 Diagnostic Status Bar .......................................... 24

5.2 Diagnostic View ................................................... 25

5.3 Security Options .................................................. 25

5.4 Access Level ....................................................... 26

6 Basic Level ................................................................ 27

ControlMaster CM10, CM30 and CM50

Universal process controllers, 1/8, 1/4and 1/2DIN Contents

2IM/CM/S–EN Rev. R

7 Advanced Level ........................................................ 36

7.1 Device Setup ....................................................... 36

7.2 Display ................................................................ 39

7.3 Input/Output ........................................................ 43

7.4 Control ................................................................ 51

7.5 Process Alarm ..................................................... 63

7.6 Profile .................................................................. 66

7.6.1 Ramp Types .............................................. 67

7.6.2 Guaranteed Ramp / Soak .......................... 68

7.6.3 Set Point Start Condition – Current PV ...... 70

7.6.4 Profile Parameters ..................................... 71

7.7 Functions ............................................................ 80

7.8 Communication ................................................... 93

7.9 Diagnostics .......................................................... 94

7.9.1 Diagnostic Messages ................................ 96

7.10 Device Info ....................................................... 100

8 Templates and Functionality .................................. 101

8.1 Basic Templates ............................................... 101

8.1.1 Single Loop / Single Loop with

Remote Setpoint ..................................... 101

8.2 Standard Templates ......................................... 103

8.2.1 Auto / Manual Station (Low Signal

Selection / Digital Signal Selection) .......... 103

8.2.2 Analog Backup Station (Low Signal

Selection / Digital Signal Selection) .......... 104

8.2.3 Single Indicator ....................................... 106

8.2.4 Dual Indicator ......................................... 106

9 PC Configuration .....................................................107

10 Specification ..........................................................108

Appendix A – Digital and Analog Sources .................116

A.1 Digital Sources ...................................................116

A.2 Analog Sources .................................................117

Appendix B – Error Codes ..........................................118

B.1 Configuration Error Codes .................................118

B.2 Profile Error Codes .............................................121

Appendix C – Analog Input (Engineering) Units ........122

Appendix D – Output Type Assignments ..................124

ControlMaster CM10, CM30 and CM50

Universal process controllers, 1/8, 1/4and 1/2DIN 1 Safety

IM/CM/S–EN Rev. R 3

1Safety

Information in this manual is intended only to assist our

customers in the efficient operation of our equipment. Use of

this manual for any other purpose is specifically prohibited

and its contents are not to be reproduced in full or part

without prior approval of the Technical Publications

Department.

1.1 Electrical Safety

This equipment complies with the requirements of CEI / IEC

61010-1:2010 3rd edition 'Safety Requirements for Electrical

Equipment for Measurement, Control and Laboratory Use'

and complies with US NEC 500, NIST and OSHA.

If the equipment is used in a manner NOT specified by the

Company, the protection provided by the equipment may be

impaired.

1.2 Symbols

One or more of the following symbols may appear on the

equipment labelling:

Warning – Refer to the manual for instructions

Caution – Risk of electric shock

Functional earth (ground) terminal

Protective earth (ground) terminal

Direct current supply only

Alternating current supply only

Both direct and alternating current supply

The equipment is protected

through double insulation

ControlMaster CM10, CM30 and CM50

Universal process controllers, 1/8, 1/4and 1/2DIN 2 Introduction

4IM/CM/S–EN Rev. R

1.3 Health & Safety 2Introduction

This manual provides details for the ControlMaster

CM10 (1/8DIN), CM30 (1/4DIN) and CM50 (1/4DIN)

controllers with Standard functionality.

2.1 EC Directive 89 / 336 / EEC

In order to meet the requirements of the EC Directive 89/336/

EEC for EMC regulations, this product must not be used in a

non-industrial environment.

2.2 End of Life Disposal

Controllers with Standard functionality contain a small lithium

battery that must be removed and disposed of responsibly in

accordance with local environmental regulations.

Health and Safety

To ensure that our products are safe and without risk to health,

the following points must be noted:

The relevant sections of these instructions must be read

carefully before proceeding.

Warning labels on containers and packages must be

observed.

Installation, operation, maintenance and servicing must

be carried out only by suitably trained personnel and in

accordance with the information given.

Normal safety precautions must be taken to avoid the

possibility of an accident occurring when operating in

conditions of high pressure and / or temperature.

Safety advice concerning the use of the equipment described in

this manual or any relevant hazard data sheets (where applicable)

may be obtained from the Company, together with servicing and

spares information.

Note.

Read all relevant sections of this guide before configuring the

system or modifying system parameters.

Install and use associated equipment in accordance with the

relevant national and local standards.

System configuration must be carried out only by users or

personnel with approved access rights (user privileges).

ControlMaster CM10, CM30 and CM50

Universal process controllers, 1/8, 1/4and 1/2DIN 3 Displays, Icons and Keys

IM/CM/S–EN Rev. R 5

3 Displays, Icons and Keys

3.1 CM10 Operator Page, Icons and Keys

Fig. 3.1 ControlMaster CM10 Display and Icons

CM10

47.46

35.00

47.6%

gal/h

ControlMaster

PV Value

Setpoint Value

Icons

Access

Level

Manual Control

Mode

Local Setpoint

Remote Setpoint

Output Value

Auto Control

Mode

Operator

Level

Icons

See Table 3.1

for key functions

Alarm

Status

ANavigation (left) / Operator Level access key – see

page 22.

BUp / Down keys – navigate up / down menus and

increase / decrease displayed values.

CNavigation key (right) / programmable Soft Key –

see page 40.

Table 3.1 CM10 Front Panel Key Functions

Note. When a Soft Key option is assigned to key C,

the Advanced Level (see page 36) must be accessed

using the Operator Level access key A.

ControlMaster CM10, CM30 and CM50

Universal process controllers, 1/8, 1/4and 1/2DIN 3 Displays, Icons and Keys

6IM/CM/S–EN Rev. R

3.2 CM30 and CM50 Operator Page, Icons & Keys

The ControlMaster CM30 and CM50 displays and icons are shown in Fig. 3.2.

Fig. 3.2 ControlMaster CM30 and CM50 Displays and Icons

CM50

1000.0

0.0

479.2

500.0

74.9

AUTO

LOCAL

PSI

ControlMaster

CM30

PSI

ControlMaster

479.2

500.0

74.9

PV Value

Bargraph

Setpoint

Value

Icons

Access

Level

Manual

Mode

Local Setpoint

Remote

Setpoint

Output

Value

Auto

Mode

Operator

Level

Icons

Adjust

– Indicates which value is adjusted

by the / keys

Process

Alarm

Autotune

ControlMaster CM10, CM30 and CM50

Universal process controllers, 1/8, 1/4and 1/2DIN 3 Displays, Icons and Keys

IM/CM/S–EN Rev. R 7

The ControlMaster CM30 and CM50 front panel keys are shown in Fig. 3.3.

Fig. 3.3 ControlMaster CM30 / CM50 Front Panel Keys

B D E

ANavigation (left) / Operator Level access key – see

page 22.

BLocal / Remote setpoint mode selection key.

CUp / Down keys – navigate up / down menus and

increase / decrease displayed values.

DAuto/Manual control mode selection key.

ENavigation key (right) / programmable Soft Key –

see page 40.

Table 3.2 CM30 / CM50 Front Panel Key Functions

Note. When a Soft Key option is assigned to key E, the

Advanced Level (see page 36) must be accessed using

the Operator Level access key A.

ControlMaster CM10, CM30 and CM50

Universal process controllers, 1/8, 1/4and 1/2DIN 4 Installation

8IM/CM/S–EN Rev. R

4 Installation

4.1 Siting and Environmental Requirements

Fig. 4.1 Siting and Environmental Requirements

CM30 CM30 CM30

CM30 CM30

At Eye Level Close to the Sensor Avoid Vibration

Sensor

Temperature Limits

55°C

(131°F)

Max.

0°C

(32°F)

Min.

Humidity Limits

0 to 95% RH

IP66/NEMA4X (front panel) IP20 (rear)

Use Screened Cable

Other manuals for ControlMaster CM10

This manual suits for next models

Table of contents

Popular Controllers manuals by other brands

Digiplex

Digiplex DGP-848 Programming guide

YASKAWA

YASKAWA SGM series user manual

Sinope

Sinope Calypso RM3500ZB installation guide

Isimet

Isimet DLA Series Style 2 Installation, Operations, Start-up and Maintenance Instructions

LSIS

LSIS sv-ip5a user manual

Rockwell Automation

Rockwell Automation 1769-L31 installation instructions

Airflow

Airflow Uno hab Installation and operating instructions

Panasonic

Panasonic GM1 Series Reference manual

Emerson

Emerson SW93 owner's manual

AutoAqua

AutoAqua Smart ATO micro SATO-120P manual

Panasonic

Panasonic FP? Positioning Unit RTEX Technical manual

Samson

Samson Type 5824 Mounting and operating instructions

Alpha IP

Alpha IP MIOB 21001 manual

Siemens

Siemens OpenAir GMA 1 Series Mounting instructions

Surecom

Surecom SR-629 user manual

Fishman

Fishman TriplePlay installation guide

Regulus

Regulus SRS1 T Installation and operation manual

3M MicroTouch EX113 reference guide
