Zanussi ZDE 36150W User manual

ZDE 36150W

Instruction booklet

Tumble Dryer

The symbols you will see on some paragraphs of this booklet have the following meaning:

The warning triangle emphasize information that is particularly important for your safety or

correct functioning of the appliance.

The information marked with this symbol provides additional instructions and practical tips

on the use ofthe appliance.

Tips and information about economical and ecological use of the machine are marked with

this symbol.

Safety information . . . . . . . . . . . . . . . . . . 3

Description of the appliance . . . . . . . . . . 5

The control panel. . . . . . . . . . . . . . . . . . . 6

Drying programmes. . . . . . . . . . . . . . . . . 7

Before the first use . . . . . . . . . . . . . . . . . 8

Drying hints . . . . . . . . . . . . . . . . . . . . . . . 8

Daily Use. . . . . . . . . . . . . . . . . . . . . . . . 10

Care and cleaning . . . . . . . . . . . . . . . . . 12

Something not working . . . . . . . . . . . . . 14

Technical data . . . . . . . . . . . . . . . . . . . . 16

Consumption values . . . . . . . . . . . . . . . 17

Disposal. . . . . . . . . . . . . . . . . . . . . . . . . 18

Installation . . . . . . . . . . . . . . . . . . . . . . . 19

European guarantee . . . . . . . . . . . . . . . 21

Contents

Thank you for selecting our appliance

We wish you lots of enjoyment with your new appliance and we hope that you will consider our

brand again when purchasing household appliances.

Please read this user manual carefully and keep it throughout the product life cycle as a refer-

ence document. The user manual should be passed on to any future owner of the appliance.

Safety Information

In the interest of your safety and to ensure the correct use, before installing and first using

the appliance, read this user manual carefully, including its hints and warnings. To avoid

unnecessary mistakes and accidents, it is important to ensure that all people using the

appliance are thoroughly familiar with its operation and safety features. Save these

instructions and make sure that they remain with the appliance if it is moved or sold, so

that everyone using it through its life will be properly informed on appliance use and safety.

General safety

• It is dangerous to alter the specifica-

tions or attempt to modify this product

in any way.

• This appliance is not intended for use by

persons (including children) with reduced

physical, sensory or lack of experience

and knowledge, unless they have

been given supervision or instruction

concerning use of the appliance by a

person responsible for their safety.

• Make sure that small pets do not climb

into the drum. To avoid this, please

check into the drum before using.

• Any objects such as coins, safety

pins, nails, screws, stones or any other

hard, sharp material can cause exten-

sive damage and must not be placed

into the machine.

• In order to avoid danger of fires

caused by excessive drying, do not

use appliance to dry the following

items: Cushions, quilts and the like

(these items accumulate heat).

• Items such as foam rubber (latex foam),

shower caps, waterproof textiles, rubber

backed articles and clothes or pillows fit-

ted with foam rubber pads should not

be dried in the tumble dryer.

• Always unplug the appliance after

use, clean and maintenance. See sec-

tion "Care and Cleaning".

• Under no circumstances should you

attempt to repair the machine yourself.

Repairs carried out by inexperienced

persons may cause injury or serious

malfunctioning. Contact your local

Service Centre. Always insist on gen-

uine spare parts.

• Items that have been soiled with sub-

stances such as cooking oil, acetone,

petrol, kerosene, spot removers, tur-

pentine, waxes and wax removers

should be washed in hot water with an

extra amount of detergent before being

dried in the tumble dryer.

• Danger of explosion: Never tumble

dry items that have been in contact

with inflammable solvents (petrol, methy-

lated spirits, dry cleaning fluid and the

like). As these substance are volatile,

they could cause an explosion. Only

tumble dry items washed with water.

• Risk of fire: items that have been

spotted or soaked with vegetable or

cooking oil constitute a fire hazard and

should not be placed in the tumble

dryer.

• If you have washed your laundry with

stain remover you must execute an extra

rinse cycle before loading your tumble

dryer.

• Please make sure that no gas lighters

or matches have accidentally been left in

pockets of garments to be loaded into

appliance

WARNING:

Never stop a tumble dry before

the end of the drying cycle unless all

items are quickly removed and spread

out so that the heat is dissipated. Risk

of fire.

Installation

• This appliance is heavy. Care should

be taken when moving it.

• When unpacking the appliance, check

that it is not damaged. If in doubt, do not

use it and contact the Service Centre.

• All packing and transit bolts must be

removed before use. Serious damage

can occur to the product and to property

if this is not adhered to. See relevant

section in the user manual.

• The final part of a tumble dryer cycle

occurs without heat ( cool down cycle )

to ensure that the items are left at a

temperature that ensures that items will

not be damaged.

• Any electrical work required to install

this appliance should be carried out by

a qualified electrician or competent

person.

• Care must be taken to ensure that

the appliance does not stand on the

electrical supply cable.

• If the machine is situated on a carpet-

ed floor, please adjust the feet in order

to allow air to circulate freely.

• After having installed the appliance,

check that it is not pressing or standing

on its electrical supply cable.

• If the tumble dryer is placed on top of a

washing machine, it is compulsory to

use the stacking kit (optional accessory).

Use

• This appliance is designed for domestic

use. It must not be used for purposes other

than those for which it was designed.

• Only wash fabrics which are designed

to be machine dried. Follow the instruc-

tions on each garment label.

• Do not dry unwashed items in the tum-

ble dryer.

• Do not overload the appliance. See

the relevant section in the user manual.

• Clothes which are dripping wet

should not be placed in the dryer.

• Garments which have been in contact

with volatile petroleum products should

not be machine dried. If volatile clean-

ing fluids are used, care should be

taken to ensure that the fluid is

removed from the garment before plac-

ing in the machine.

• Never pull the power supply cable to

remove the plug from the socket;

always take hold of the plug itself.

• Never use the tumble dryer if the

power supply cable, the control panel,

the working surface or the base are

damaged so that the inside of the tum-

ble dryer is accessible.

Child safety

• This machine is not intended for use

by young children or infirm persons

without supervision.

• Children should be supervised to ensure

that they do not play with the appliance.

• The packaging components (e.g.

plastic film, polystyrene) can be dan-

gerous to children - danger of suffoca-

tion! Keep them out of children’s reach

• Keep all detergents in a safe place

out of children’s reach.

• Make sure that children or pets do

not climb into the drum.

Description of the appliance

1. Control panel

2. Fluff filters

3. Rating Plate

4.Adjustable feet

5. Side vent outlets

6. Ring nut

7. Rear vent outlet

The control panel

Programme chart This will help you to select the correct programme for drying.

Start button This button is used to switch the dryer on.At the end of the pro-

gramme, release this button by pressing it again to switch the

dryer off.

Drying Time Selector Dial The selector dial incorporates two drying cycles, one of up to

150 minutes at a high temperature for cotton and linen, and one

of up to 100 minutes at a low temperature for synthetic fabrics.

Time

selector dial

Half power

button Start

button Mains-ON light

Half power button Pressing this button allows drying to be performed at a lower

temperature, for delicate items.

Mains-ON light Comes on when the appliance is switched on and goes out

when appliance is switched off.

Programme

chart

Degree of drying required Degree of

spin given

rpm

Quantity

kg Drying times mins

Cupboard

800/1000 6105 - 135

360 - 85

1200/1400 695 - 120

350 - 7 0

Iron dry

800/1000 690 - 115

345 - 70

1200/1400 680 - 100

335 - 55

Drying programs

Cotton Selector dial: up to 150 minutes

Degree of drying required Degree of

spin given

rpm

Quantity

kg Drying times mins

Cupboard 1200 325 - 35

115 - 20

Synthetics Selector dial: up to 100 minutes

Never overfill the drum (do not load large quilts, for example).

The laundry must be suitably spun in your washing machine before being placed in the tumble

dryer (500rpm minimum).

Drying times vary according to:

• The type of laundry

• The size of the load

• The degree of spinning prior to drying

Drying times are given as a guide only. Experience will soon enable you to estimate the drying

time needed for your usual laundry loads.

Do not start by selecting a long drying time. It is better to determine the required degree of dry-

ness by gradually increasing the drying time.

For a mixed load (cotton and resistant synthetics, for example) select the time for the most deli-

cate fibres and increase it by 10 mins.

Before loading the laundry

Never tumble dry the following: Particularly

delicate items such as net curtains, woollen,

silk, fabrics with metal trim, nylon tights,

bulky materials such as anoraks, blankets,

eiderdowns, sleeping bags, feather quilts

and any items containing rubber foam or

materials similar to rubber foam.

•Always follow the instructions on garment

labels:

may be tumble dried

normal drying (high temperature)

delicate drying (low temperature)

do not tumble dry

• Close pillowcases and covers with fasteners

to prevent small laundry items getting tan-

gled inside them. Close press studs, zips

and hooks and tie belts and apron strings.

• Sort laundry according to type and degree

on drying required.

• Do not over-dry laundry, this avoids creas-

ing and saves energy.

•Avoid drying dark clothes with light coloured

fluffy items such as towels as they could

attract the fluff.

• The laundry must be thoroughly spun

before tumble drying.

• Easy-care items, too, e.g. shirts, should be

briefly pre-spun before drying (depending

on crease resistance approx. 30 seconds or

using the special brief spin programme on

your washing machine).

• Knitted textiles (knitted underwear) may

shrink a little during drying. Please do not

overdry items of this type. It is advisable to

allow for shrinkage when choosing the size

of new purchases.

• You can also put starched items into your

dryer. However, to achieve the desired

starched effect, choose the programme

“iron dry”. To remove any starch residues,

wipe out the internal drum after drying with

a moist cloth and then rub it dry.

• To avoid a static charge when drying is

completed, use either a fabric softener

when you are washing the laundry or a fab-

ric conditioner specifically for tumble dryers.

• Remove the laundry when the dryer has fin-

ished drying.

• If individual items are still damp after drying,

set a brief post-drying time, but at least 30

minutes. This will be necessary particularly

for multilayered items (e.g. collars, pockets,

etc.).

Before the first use

• Ensure that the electrical connections comply with the installation instructions.

• Remove the polystryrene block and any material from the drum.

• Before using your tumble dryer for the first time, we recommend that you place a few damp

cloths inside the appliance and dry for 30 minutes.

There may be dust inside a brand new tumble dryer.

Drying hints

Make sure that no metal objects are left in

the laundry (e.g. hair clips, safety pins,

pins).

Button up pillowcases, close zip fasteners,

hooks and poppers. Tie any belts or long

tapes.

To avoid laundry becoming tangled: close

zips, button up duvet covers and tie loose

ties or ribbons (e.g. of aprons). Turn items

with double-layered fabrics inside out (e.g.

with cotton lined anoraks, the cotton layer

should be outermost). These fabrics will

then dry better.

Maximum loads

Recommended loads are indicated in the pro-

gramme charts.

General rules:

Cotton, linen: drum full but not too tightly

packed;

Synthetics: drum no more than half full;

Delicate fabrics and woollens: drum no

more than one third full.

Try to load to the maximum capacity of the

machine as small loads are uneconomical.

Laundry weights

The following weights are indicative:

bathrobe 1200 g

napkin 100 g

quilt cover 700 g

sheet 500 g

pillow case 200 g

tablecloth 250 g

towelling towel 200 g

tea cloth 100 g

night dress 200 g

ladies’briefs 100 g

man’s work shirt 600 g

man’s shirt 200 g

man’s pyjamas 500 g

blouse 100 g

men’s underpants 100 g

Load the laundry

Connect the appli-

ance. Open the door

(see picture).

Place the laundry in

the drum, one item at

a time, shaking them

out as much as possi-

ble. Close the door.

Please check the

laundry does not get

caught between the

door and filter.

Drying Time

Selector Dial

The selector dial

incorporates two dry-

ing cycles, one of up

to 150 minutes at a

high temperature for

cotton and linen, and

one of up to 100 min-

utes at a low tempera-

ture for synthetic fab-

rics.

To set the machine to

the selected time, turn

the dial clockwise until

the time you want

coincides exactly with

the pointer.

NEVER attempt to

turn the dial in an

anticlockwise direc-

tion.

When selecting the

drying time, you

should remember that

it includes a 10

minute cooling phase

(position on the

dial).

This phase should not

be shortened, stopped

or avoided, as this

could cause skin

burns or damages to

the laundry.

Additional drying

If at the end of the

programme, the laun-

dry is still too dump,

set the dial for a fur-

ther period of drying

(remembering to take

into account the cool-

ing period).

At the end of the

programme the

selector dial must

be turned to posi-

tion O, to switch the

machine off.

Half power button

Pressing this button

allows drying to be

performed at a lower

temperature, for deli-

cate items.

HALF POWER is only

suitable for use with

loads of up to 3kg!

Start

This button is used to

switch the dryer on.At

the end of the pro-

gramme, release this

button by pressing it

again to switch the

dryer off.

Mains-ON light

Comes on when the

appliance is switched

on (ON/OFF button

pressed down) and

goes out when this

button is released.

Daily Use

Table of contents

Other Zanussi Dryer manuals

Zanussi

Zanussi ZDH87A2PW User manual

Zanussi

Zanussi THE7050 User manual

Zanussi

Zanussi TC 60 User manual

Zanussi

Zanussi ZDC37100W User manual

Zanussi

Zanussi THE7201 User manual

Zanussi

Zanussi TDS 483 EW User manual

Zanussi

Zanussi TD62 User manual

Zanussi

Zanussi ZDP7203PZ User manual

Zanussi

Zanussi TD 4212 W User manual

Zanussi

Zanussi ZDC37202W User manual

Zanussi

Zanussi TD 4212 W User manual

Zanussi

Zanussi TE I 935 Operating and safety instructions

Zanussi

Zanussi TD 300 Assembly instructions

Zanussi

Zanussi TEi935 Operating and safety instructions

Zanussi

Zanussi TCE 7276 W User manual

Zanussi

Zanussi ZDC68560W User manual

Zanussi

Zanussi ZI 935 Operating and safety instructions

Zanussi

Zanussi TD245 User manual

Zanussi

Zanussi ZTE 225 User manual

Zanussi

Zanussi ZTE240 User manual

Zanussi

Zanussi TD60 Operating and safety instructions

Zanussi

Zanussi TD 4112 W User manual

Zanussi

Zanussi ZTE278 User manual

Zanussi

Zanussi ZI 930 Assembly instructions

Popular Dryer manuals by other brands

Bosch

Bosch WTA79200GB Installation and operating instructions

Amana

Amana W10233410A Use and care guide

Miele

Miele TWH 780 WP operating instructions

Asko

Asko T760 user guide

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Original instructions

Bosch

Bosch Logixx 10 WTB76556GB Instruction manual and installation instructions

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Operation and installation

Electrolux

Electrolux EW2H328R2 user manual

Beko

Beko DS8433RX1M user manual

Dawlance

Dawlance Spinner DS 6000 C owner's manual

Electrolux

Electrolux TP5080TW user manual

AEG

AEG TR838P4OB user manual

Indesit

Indesit IDV 75 instruction manual

Infiniton

Infiniton SD-DG85C manual

BOMANN

BOMANN WT 5019 instruction manual

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Installation

Asko

Asko T793C operating instructions

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer installation instructions
