Xerox WORKCENTRE C2424 User manual

WorkCentre® C2424 Copier-Printer

5-1

This chapter includes:

■"Basic Printing" on page 5-2

■"Print Fonts" on page 5-3

■"Adjusting Printing Options" on page 5-6

■"Automatic 2-Sided Printing" on page 5-12

■"Transparencies" on page 5-14

■"Envelopes" on page 5-18

■"Labels, Business Cards, and Index Cards" on page 5-23

■"Specialty Paper" on page 5-28

■"Custom Size Paper" on page 5-49

■"Advanced Options" on page 5-52

Printing

Basic Printing

WorkCentre® C2424 Copier-Printer

5-2

Basic Printing

This section includes:

■"Overview of Basic Steps" on page 5-2

■"Factors Affecting Printing Performance" on page 5-2

Overview of Basic Steps

Follow these steps to print jobs:

1. Load paper in the tray. For information about loading trays, see the Loading Media chapter

of this guide, or go to Getting Started/Loading Media on the User Documentation CD-

ROM.

2. If prompted by the control panel, either confirm the paper type and size or change it as

required.

3. From the application, access the Print dialog box.

4. If desired, select printing options in the printer driver.

■For information about accessing and using the driver, see "Obtaining the Printer

Driver" on page 5-6.

■For information about specifying print options, see "Adjusting Printing Options" on

page 5-6.

5. Send the job to the printer from the application’s Print dialog box.

Factors Affecting Printing Performance

Many factors affect a print job. They include the print speed (stated in number of pages per

minute), the media used, download time, and system processing time.

The computer download time and system processing time are affected by several factors

including:

■System memory

■Connection type (network or USB)

■Network operating system

■System configuration

■File size and type of graphics

■Computer speed

Note

Additional system memory (RAM) may improve overall printer functions, but will not

increase the pages per minute (ppm) ability of the system.

Print Fonts

WorkCentre® C2424 Copier-Printer

5-3

Print Fonts

This section includes:

■"Types of Fonts" on page 5-3

■"Viewing a List of System Fonts Available for Printing" on page 5-3

■"Printing a List of System Fonts" on page 5-4

■"Downloading Fonts" on page 5-5

Types of Fonts

Your system uses the following types of fonts for printing:

■Printer-resident PostScript and PCL fonts, which are always available for printing

■Fonts downloaded into system memory

■Fonts downloaded with your print job from the application

Adobe Type Manager (ATM) software enables your computer to display these fonts on your

computer screen as they will appear in your prints.

If you do not have ATM on your computer:

1. Install ATM from the WorkCentre C2424 Software CD-ROM.

2. Install the system’s screen fonts for your computer from the ATM folder.

Viewing a List of System Fonts Available for Printing

To view a list of available PCL or PostScript fonts, use CentreWare IS:

1. Launch your web browser.

2. Enter your system’s IP address in the browser’s Address field (http://xxx.xxx.xxx.xxx).

3. Click the Properties button.

4. Click the Web Server folder on the left sidebar, then click Font Files.

Print Fonts

WorkCentre® C2424 Copier-Printer

5-4

Printing a List of System Fonts

To print a list of available PostScript or PCL fonts, use:

■The control panel

■CentreWare IS

■The printer driver

Using the Control Panel

To print either a PCL font list or a PostScript font list and samples from the control panel:

1. Press the System Setup button.

2. In the menu, select Information, then press the Enter button.

3. Select Information Pages, then press the Enter button.

4. Select either PCL Font List or PostScript Font List, then press the Enter button to

print.

Using CentreWare IS

To print either a PostScript or PCL font list from CentreWare IS:

1. Launch your web browser.

2. Enter your system’s IP address in the browser’s Address field (http://xxx.xxx.xxx.xxx).

3. Click the Print button.

4. Select the appropriate Font List.

5. Click the Print button.

Using a Windows Printer Driver

To print either a PostScript or PCL font list from your printer driver:

1. Select Start, select Settings, then select Printers.

2. Right-click the WorkCentre C2424 system, then select Properties.

3. Select the Troubleshooting tab.

4. In the Printer Information Pages drop-down list, select PostScript Font List or PCL

Font List.

5. Click the Print button.

Print Fonts

WorkCentre® C2424 Copier-Printer

5-5

Downloading Fonts

To supplement the resident fonts (which are always available for printing), downloadable fonts

can be sent from your computer and stored in the system’s memory or on the system’s hard

drive.

Note

If you turn the system off, the fonts you download to memory are deleted. You must

download them again when you turn the system on.

Before printing, verify that the fonts specified in your document are installed in the system or

are set up to download correctly. If your document has a font not currently in your system, or

downloaded with your print job, a different font will be used.

The system accepts the following downloadable fonts for printing:

■PCL

■Type 1

■Type 3

■TrueType (scalable to any point size; looks the same on-screen and printed).

Downloading Fonts from the CentreWare Font Management Utility

The CentreWare Font Management Utility (FMU) is a Windows and Macintosh application

that helps manage fonts, macros and forms on a printer’s hard drive. Downloading fonts to a

printer can improve printing performance and reduce network traffic. You can list, print,

delete, and download PostScript and PCL fonts using the Font Management Utility.

To download the Font Management Utility, go to www.xerox.com/office/drivers and use the

Key word search FMU.

Adjusting Printing Options

WorkCentre® C2424 Copier-Printer

5-6

Adjusting Printing Options

This section includes:

■"Obtaining the Printer Driver" on page 5-6

■"Setting the Print Default Tray" on page 5-7

■"Selecting Printing Preferences (Windows)" on page 5-8

■"Selecting Printing Options for an Individual Job (Windows)" on page 5-8

■"Selecting Printing Options for an Individual Job (Macintosh)" on page 5-10

For information about special printing options, see "Advanced Options" on page 5-52.

Obtaining the Printer Driver

To access special printing options, use a Xerox printer driver.

Xerox provides drivers for a variety of page description languages and operating systems. The

following printer drivers are available:

Find certain drivers on the WorkCentre C2424 Software CD-ROM that came with your system.

All of these printer drivers can be found on the web at www.xerox.com/office/drivers.

Printer Driver Source* Description

Windows PostScript Driver CD-ROM and

Web

The PostScript driver is recommended to take

full advantage of your system's custom

features and genuine Adobe® PostScript®.

(Default printer driver)

PCL Driver Web only The Printer Command Language driver can

be used for applications requiring PCL.

NoteNoteNote

For Windows 2000 and Windows XP only.

Xerox Walk-Up Printing Driver

(Windows)

Web only This driver enables printing from a PC to any

Xerox PostScript-enabled printer. This is

especially helpful for mobile professionals

who travel to multiple locations and need to

print to different printers.

Macintosh OS Driver CD-ROM and

Web

This driver enables printing from a Macintosh

OS 9.x or OS X (version 10.1 and higher).

UNIX Driver (Linux, Solaris) Web only This driver enables printing from a UNIX

operating system.

Adjusting Printing Options

WorkCentre® C2424 Copier-Printer

5-7

Setting the Print Default Tray

To select the default tray for printing, use either:

■The control panel

■CentreWare IS

Note

The printer driver overrides the control panel and CentreWare IS settings.

Using the Control Panel

To select the default tray for printing:

1. On the control panel, press the System Setup button.

2. In the menu, select Job Defaults Setup, then press the Enter button.

3. Select Print Defaults Setup, then press the Enter button.

4. Select Paper Handling Setup, then press the Enter button.

5. Select Paper Source, then press the Enter button.

6. Scroll to the desired tray or Auto Select.

7. Press the Enter button to save the changes.

Using CentreWare IS

To select the default tray for printing:

1. Launch your web browser.

2. Enter your system’s IP address in the browser’s Address field (http://xxx.xxx.xxx.xxx).

3. Click Properties.

4. Click the General folder on the left sidebar, then click Printer Defaults.

5. Scroll to Print Mode Settings, then select the tray from the Paper Source drop-down list.

6. Click Save Changes at the bottom of the screen.

Adjusting Printing Options

WorkCentre® C2424 Copier-Printer

5-8

Selecting Printing Preferences (Windows)

Printer preferences control all of your jobs, unless you overwrite them specifically for your

job. For example, if you want to use automatic 2-sided printing for most jobs, set this option in

printer settings.

1. Click Start, select Settings, then click Printers.

2. In the Printers folder, right-click the icon for your printer.

3. From the popup menu, select Printer Preferences or Properties.

4. Make selections from the driver tabs. See the “Printing Options for Windows Operating

Systems” table for specific printing options.

5. Click the OK button to save your selections.

Note

For more information about Windows printer driver options, click the Help button on the

printer driver tab to view the online help.

Selecting Printing Options for an Individual Job (Windows)

If you want to use special printing options for a particular job, change the driver settings before

sending the job to the printer. For example, if you want to use High-Resolution/Photo print-

quality mode for a particular graphic, select this setting in the driver before printing that job.

1. With the desired document or graphic open in your application, access the Print dialog

box.

2. Select the WorkCentre C2424 Copier-Printer for use and click its Properties button to

open the printer driver.

3. Make selections from the driver tabs. See the following table for specific printing options.

4. Click the OK button to save your selections.

5. Print the job.

Note

For more information about Windows printer driver options, click the Help button on the

printer driver tab to view the online help.

Adjusting Printing Options

WorkCentre® C2424 Copier-Printer

5-9

Printing Options for Windows Operating Systems

Operating

System Driver Tab Printing Options

Windows 2000,

Windows XP, or

Windows Server

2003

Layout tab ■Orientation

■2-sided printing

■Pages per sheet

Paper/Quality tab ■Paper type, size, and tray selection

■Cover pages

■Print quality

Output Options tab ■Separation pages

■Secure prints, proof prints, and saved prints

■End of job notification

TekColor tab ■Color corrections

■Black & white conversion

Windows NT Page Setup tab ■Orientation

■2-sided printing

Paper/Quality tab ■Paper type, size, and tray selection

■Cover pages

■Print quality

Output Options tab ■Separation pages

■Secure prints, proof prints, and saved prints

TekColor tab ■Color corrections

■Black & white conversion

Windows 98 or

Windows Me

Setup tab ■Paper type, size, and tray selection

■Orientation

■2-sided printing

■Print quality

■End of job notification

Output Options tab ■Separation pages

■Cover pages

■Secure prints, proof prints, and saved prints

TekColor tab ■Color corrections

■Black & white conversion

Adjusting Printing Options

WorkCentre® C2424 Copier-Printer

5-10

Selecting Printing Options for an Individual Job (Macintosh)

To select print settings for a particular job, change the driver settings before sending the job to

the printer.

1. With the document open in your application, click File, then click Print.

2. Select the desired printing options from the menus and drop-down lists that are displayed.

Note

In Macintosh OS X, click Save Preset on the Print menu screen to save the current

printer settings. You can create multiple presets and save each with its own distinctive

name and printer settings. To print jobs using specific printer settings, click the

applicable saved preset in the Presets list.

3. Click Print to print the job.

See the following table for specific printing options. For more information, see "Advanced

Options" on page 5-52.

Macintosh PostScript Driver Settings

Operating System Driver Drop-Down Title Printing Options

Mac OS X, version

10.1 and higher

Copies & Pages ■Copies

■Pages

Layout ■Pages Per Sheet

■Layout Direction

■Border

Output Options ■Save as File

■Format

Printer Features ■Separation Page Source

■Separation Page (On/Off)

■Feature Sets

Image Quality ■Print Quality

Error Handling ■PostScript Errors

■Tray Switching

Paper Feed ■All pages from

■First page from

■Remaining from

Summary Summary of all printer driver settings

Other manuals for WORKCENTRE C2424

Table of contents

Other Xerox All In One Printer manuals

Xerox

Xerox WorkCentre 4260S User manual

Xerox

Xerox VersaLink C70 Series User manual

Xerox

Xerox Xerox Phaser 6600 User manual

Xerox

Xerox 4150S - WorkCentre B/W Laser User manual

Xerox

Xerox WorkCentre 5325 Operating manual

Xerox

Xerox WorkCentre 5325 User manual

Xerox

Xerox Phaser 3250 User manual

Xerox

Xerox WorkCentre 5845 User manual

Xerox

Xerox PHASER 3125 User manual

Xerox

Xerox WorkCentre 7655 User manual

Xerox

Xerox WORKCENTRE 7120 Operating manual

Xerox

Xerox WORKCENTRE 7755 Technical manual

Xerox

Xerox VersaLink B70 Series User manual

Xerox

Xerox DocuColor 5750 User manual

Xerox

Xerox DocuColor 5750 User manual

Xerox

Xerox VersaLink B605 User manual

Xerox

Xerox 3300MFP - Phaser B/W Laser Operating and maintenance manual

Xerox

Xerox CopyCentre 118 User manual

Xerox

Xerox 3210 - workcentre b/w laser User manual

Xerox

Xerox B205 User manual

Xerox

Xerox DocuPrint 65 User manual

Xerox

Xerox Document Centre 240 DC User manual

Xerox

Xerox CopyCentre 118 User manual

Xerox

Xerox WorkCentre 7328 User manual

Popular All In One Printer manuals by other brands

Triumph Adler

Triumph Adler DC 2016 Instruction handbook

Epson

Epson WorkForce WF-2510 Basic guide

Epson

Epson Stylus Scan 2000 Product information guide

Epson

Epson PictureMate Snap PM 240 Start here

Konica Minolta

Konica Minolta bizhub C35 user guide

Brother

Brother MFC-J430w user guide

Konica Minolta

Konica Minolta BIZHUB 558 Quick reference guide

Lexmark

Lexmark MX710 Series setup sheet

Brother

Brother MFC-9760 owner's manual

Lexmark

Lexmark XC8155 user guide

Lexmark

Lexmark X642E Service manual

Sharp

Sharp MX-2310U Start guide

Aficio

Aficio 200 manual

Canon

Canon ImageCLASS 2300 setup sheet

Ricoh

Ricoh Pro C900 Brochure & specs

Lexmark

Lexmark X925 Installation

Brother

Brother Business Smart MFC-J4510dw manual

Epson

Epson Stylus CX8400 Series Brochure & specs
