Williams Sound R801 Troubleshooting guide

Williams Sound

Helping People Hear

For use with Transmitter Models:

PPA T4, PPA T17, PPA T20, PPA T16,

PFM T30, PFM T31

Installation

Guide &

User

Manual

PERSONAL PA® FM Monitor Receiver

Model R801

MAN 098B

Phones

R801 Professional FM Auditory Assistance Receiver

Williams Sound

Power Carrier

Frequency

Squelch

Frequency Synthesized, Channel-Selectable

75.7

75.9

72.1

72.3 72.5 72.7 72.9

74.7

75.3

75.5

Williams Sound

Helping People Hear

PERSONAL PA®FM MONITOR RECEIVER

MODEL R801

INSTALLATION AND USER MANUAL

Contents Page

System Overview 3

System Components 3

Quick Start Instructions 4

R801 Receiver Features 5

Optional Antennas 6

Setting the Squelch Control 7

Changing Frequencies 7

Using Multiple Systems 8

In Case Of Difficulty 8

Optional Rack Mounting Kits 9

Warranty 9

Receiver Specifications 10

Williams Sound

Helping People Hear

SYSTEM OVERVIEW

Thank you for purchasing the PERSONAL PA®FM Monitor Receiver from Williams Sound

Corp. This monitor receiver is intended to be used for hearing assistance with a Williams

Sound PERSONAL PA Transmitter operating on one of 10 wideband channels from 72 - 76

MHz. The Monitor Receiver provides a convenient way to receive the PPA Transmitter

broadcast in a remote location. Depending the antennas being used, the receiver will operate

up to 500 feet from the transmitter

To avoid difficulties, please read through these instructions as you begin to use the system.

Then save them for questions that arise as you continue to use your Williams Sound Monitor

Receiver.

If you have problems with the system, don’t hesitate to call us toll-free at 1-800-843-3544.

SYSTEM COMPONENTS (R801)

• FM Receiver (R801)

• Power Supply (TFP 016)

• “Rubber Duck” Antenna (ANT 021)

• 1m RCA to RCA Audio Cable with RCA to 1/4” Adapter (WCA 013/CNA 007)

• Instruction Manual (MAN 098)

FIG. 1: OVERALL SYSTEM DIAGRAM

Phones

PPA T4 Professional FM Auditory Assistance Transmitter

Power

-12dB -6dB 0dB +6dB

Audio Level

Increase

Decrease Too Hi

Audio Adjust RF Carrier

Ok Ok

Frequency Synthesized, Channel-Selectable

SpeakersAmplifier

PPA Transmitter R801 Receiver

Phones

R801 Professional FM Auditory Assistance Receiver

Williams Sound

Power Carrier

Frequency

Squelch

Frequency Synthesized, Channel-Selectable

75.7

75.9

72.1

72.3 72.5 72.7 72.9

74.7

75.3

75.5

HOW ITWORKS:

The PPA Transmitter produces the FM radio signal. The R801 picks up the transmitterd

signal and feeds it into a sound system.

Williams Sound

Helping People Hear

QUICK START INSTRUCTIONS

1. Make sure the R801 Receiver is set to the same operating frequency as your transmitter.

See the transmitter instructions for frequency identification. Alternately, see step 6 below.

2. Choose a location for the R801 Receiver. Take into account proximity to the sound

system, availability ofAC power, rack mounting,and antenna installation requirements.

3. Install the Antenna. The rubber duck antenna threads into the hole on top of the receiver.

Remote antennas connect to the “F” type connector on the rear of the R801. See page 6

for remote antenna installation details.

4. Plug the Power Supply connector into the R801. The locking tab on the connector should

point UP as shown on the R801 rear panel. Plug the power supply into anAC outlet.

5. Connect the R801 Receiver to the audio input of your sound system, using the audio

cable provided. The cable provided is for an unbalanced connection. If you wish to use a

balanced connection, you will need to supply your own TRS cable.

6. Turn the R801 Power switch ON. Change the R801 Channel Selector until the Carrier

light turns on and you hear the transmitter signal in the headphone jack.

7. Adjust the squelch control. See page 7 for details.

8. Set the volume on your sound system.

Williams Sound

Helping People Hear

R801 MONITOR RECEIVER FEATURES

R801 FRONT PANEL FEATURES

POWER ON/OFF SWITCH

Turns R801 power on or off.

POWER LED INDICATOR

Glows when the R801 power is on.

FM FREQUENCY SWITCH

The selected receiver channel must match the transmitter channel. The system is pre-set to

72.9 MHz. Change the receiver channel only if the transmitter channel has been changed. See

your Transmitter instructions to change the transmitter channel.

FM CARRIER LED INDICATOR

Glows when a carrier frequency is present.

PHONES JACK

Allows monitoring the audio signal with mono or stereo headphones. (1/4” TRS)

SQUELCH ADJUST

Sets Receiver incoming signal mute level.

R801 REAR PANEL FEATURES

LINEOUTPUT

This 1/4” TRS jack provides a balanced or unbalanced line-level audio output. Connect the

Tip or Ring to the Sleeve for an unbalanced signal. Connect to Tip (+) Ring (-) and Sleeve

(Com) for a balanced signal.

REMOTE ANTENNA CONNECTOR

“F–type” connector for 75ΩRemote Antennas (ANT 005, ANT 024)

AC POWER SUPPLY

Molex-type connector for TFP 016 Power Supply.

FLEXIBLE “RUBBER DUCKIE” ANTENNA

Threads onto the mounting stud on top of the receiver. ANT 025 may also be used.

Professional FM Auditory Assistance Receiver

Antenna

75 Ohms

Williams Sound Corp., Minneapolis, MN USA

Balanced

or Unbalanced

Line Out

Power In

24 VAC

50-60 Hz

Plug

Phones

R801 Professional FM Auditory Assistance Receiver Williams Sound

Power Carrier

Frequency

Squelch

Frequency Synthesized, Channel-Selectable

75.7

75.9

72.1

72.3 72.5 72.7 72.9

74.7

75.3

75.5

Williams Sound

Helping People Hear

USING ANALTERNATE ANTENNA

The operating range of the system is dependent on which antenna is used on the Receiver

AND which antenna is used on the base-station Transmitter. The standard ANT 016 Rubber

Duckie Antenna on both Receiver and Transmitter will provide sufficient operating range

(up to 300 ft) for most applications. Three optional antennas are also available which will

extend the operating range and offer some installation alternatives:

ANT 005 Coaxial Antenna

When used on the Transmitter and the Receiver, this optional 80” dipole wall mount antenna

provides the greatest range (up to 500 ft.).

ANT 024 Dipole Antenna

This optional antenna provides nearly the operating range of the ANT 005 Coax Antenna,

but is easier to install and is shorter.

ANT 025 Whip

This 40” whip antenna threads onto the mounting stud on top of the receiver or Transmitter.

It provides improved range (350 - 400 ft.) compared to the standard ANT 016 antenna.

REMOTE ANTENNA LOCATION TIPS

þInstall the ANT 005 or ANT 024 with its elements vertical. The antenna is best installed

on a wall 10 to 15 feet above the floor. It may be located in the next room from the lis-

tening area if the separating wall does not contain metal lath, steel studs, foil-backed

insulation, or significant ductwork. Do not install the antenna in an organ chamber. The

numerous pipes of an organ significantly deflect and absorb the radio signal.

þThe ANT 005 and ANT 024 feedline is classified under the National Electrical Code as

Class II wiring and may be installed in conduit with other Class II wiring. It SHOULD

NOT be installed with Class I (power) wiring.

þDo not connect the coaxial cable to the building or electrical ground in any way.

AVOIDING UNDESIRABLE ANTENNA INSTALLATIONS

Transmission (range, directional properties) can be severely impaired by improper installa-

tion of the antenna.

þDO NOT install the antenna within any metal enclosure.

þDO NOT install the antenna where it is separated from the listening area by any sub-

stantial metal object, such as heating ducts, structural steel, foil backed insulation, steel

studs or metal lath.

ANT 005 ANT 024

Williams Sound

Helping People Hear

SETTING THE SQUELCH CONTROL

The squelch control sets the incoming signal level required to un-mute the R801. If the

receiver is not locked onto a signal, it can produce noise. The function of the squelch circuit

is prevent this noise when no signal is present., When the squelch is properly adjusted, turn-

ing off the Transmitter will cause the R801 to mute. The radio noise in each area is different,

so you must adjust the squelch when the R801 is installed.

1. Make sure the R801 is plugged in, turned on, and has an antenna attached.

2. Make sure the Transmitter is OFF.

3. Use headphones to listen to the R801 Phones Jack.

4. Set the R801 Frequency Selector to the desired channel.

5. While listening to the headphones with the Transmitter still OFF, turn the Squelch control

counter-clockwise until noise is heard in the headphones.

6. Slowly turn the Squelch control clockwise just until the noise disappears.

7. Turn the Transmitter ON. The signal in the headphones should be clear and free from

noise and interference, unless you are out of range of the Transmitter.

8. Turn the Transmitter OFF. The R801 should immediately go silent. Re-adjust the squelch

control if necessary.

CHANGING FREQUENCIES/IFYOU EXPERIENCE INTERFERENCE

If you experience FM signal interference, you can easily adjust your transmitter and receiver

to a use different frequencies. The Transmitter and Receiver Frequencies must always

match.

CHECKING FOR A CLEAR CHANNEL:

The R801 can be used to “scan” for a clear channel in your area. With the Transmitter

turned OFF, Move the Frequency Selector switch on the front panel of the R801 and observe

the Carrier indicator light, while listening with headphones plugged into the PHONES jack.

If it comes on, that indicates another transmitter is operating on that channel in your area.

You should select another channel to use.

CHANGING THE R801 RECEIVER FREQUENCY:

1. Simply select an alternate channel with the Frequency Selector switch on the front panel.

The selector knob shows which frequency you have selected.

2. Make sure the Transmitter matches the Receiver channel. See your Transmitter

intructions.

Williams Sound

Helping People Hear

USING MULTIPLE CHANNELS:

1. Multi-channel systems require a Transmitter and a Receiver for each channel.

2. Make sure each Transmitter matches each Receiver channel. See your Transmitter

intructions.

3. You may be able to use adjacent channels in multi-channel systems if the R801 is the

only receiver used. Other PPA Receivers cannot use adjacent channels.

4. You may use more than one receiver with each Transmitter.

5. To avoid interference, DO NOT operate two transmitters on the same channel in the same

room.

INCASE OFDIFFICULTY

IFNOSOUND ISPRODUCED

1. Make sure the Transmitter and Receiver are ON and operating on the same channel. If

the Transmitter has a Phones jack, listen to make sure the Transmitter has a signal.

2. Make sure the receiver carrier light is ON. If it is not, there is either no transmitter signal,

the receiver is set to the wrong channel, the receiver is out of range for the transmitter, or

there is a fault with the receiver.

3. Make sure the antenna is installed properly. If the receiver is out of range, theANT 005

or ANT 026 remote antenna may be needed. Try moving the transmitter and receiver

closer together.

4. The squelch control may not be set properly. Try turning the control counter-clockwise to

see if the Carrier light comes on and the signal comes through.

5. Listen to the signal at the headphone jack on the R801. If there is no signal, there is

either no Transmitter signal or there is a fault with the R801. If there is a good signal at

the headphone jack, but not through your sound system, check the cable and audio

connection between the R801 and the sound system.

IFINTERFERENCE OCCURS

1. Do not try to use more than one transmitter on the same channel in close proximity to

each other. Use separate channels for each Transmitter used.

2. If you are still hearing interference on the receiver, turn the transmitter off and listen with

a receiver. If you hear the interference with the transmitter off, you need to change to a

clear channel. See the frequency change instructions on page 7.

IFPROBLEMS REMAIN

If none of the remedies above provides the solution, call Williams Sound’s Customer

Service Department at 1-800-843-3544 (8:00 AM– 4:30 PM Central Time).

Williams Sound

Helping People Hear

OPTIONAL MOUNTING KITS

Williams Sound offers two optional rack mounting kits for use with the R801 FM Monitor

Receiver. Use the RPK 005 Kit to mount one R801 in a single rack space. Use The RPK 006

Kit to mount two R801’s in a single rack space. NOTE: If you are rack mounting the R801,

you will likely need a remote antenna. The antenna cannot be inside a metal enclosure. To

order these optional components, contact your dealer or Williams Sound Corp.

WARRANTY

The Williams Sound R801 FM Monitor Receiver is engineered and designed to provide you

with many years of reliable service. Williams Sound warrants it against defects in materials

and workmanship for FIVE (5) years EXCEPT FOR cables, antennas, and all other accesso-

ry products. Accessory products carry a 90 day warranty.

If the product fails within the specified warranty period, Williams Sound will determine

whether to repair or replace the defective equipment. This warranty does not apply to physi-

cal damage, abuse, mis-use, or products that have been modified.

If you experience difficulty with your system, call for Customer Assistance:

1-800-328-6190.

If it is necessary to return the system for service, a Williams Sound representative will give

you a Return Authorization Number (RA) and shipping instructions. Pack the system care-

fully and send it to:

Williams Sound Corp.

10399 West 70th Street

Eden Prairie, MN 55344-3459 USA

Phone: 800-843-3544 / 612-943-2252

Fax: 952-943-2174

TTY: 952-943-9675

e-mail: [email protected]

Your warranty becomes effective the date you purchase your system. Your returned warranty

card is our way of knowing when your warranty begins. It also gives us important informa-

tion about your system including the serial number. This information will help us serve you

better in the future. Please take a moment to complete and mail the attached card. Thank

you.

RPK 005 RPK 006

Williams Sound

Helping People Hear

PERSONAL PA®FM MONITOR RECEIVER SPECIFICATIONS

MODEL R801

Dimensions, Weight: 1.75" H x 8.45" W x 8.25" D, 3lbs.

Color: Black epoxy paint with white legends

Rack Mount: One EIA rack space high, 1/2 space wide, 1-2 units can be mounted in a single rack space

with optional RPK 005 (single) or RPK 006 (double) Rack Mount kits.

Power: 24VAC, 50/60Hz, TFP 016 supplied, Molex connector

Power Indicator: Green LED, Front panel

Operating Freq.: 10 Channel Selectable (72.1, 72.3, 72.5, 72.7, 72.9, 74.7, 75.3, 75.5, 75.7, 75.9 MHz*)

Freq. Accuracy: 0.01%, Frequency Synthesized, Crystal Reference

FM Deviation: +/- 75kHz, 75µS de-emphasis

Sensitivity: 0.8µV at 12 dB Sinad with squelch at minimum

Carrier Indicator: Green LED, Front panel

Freq. Response: 50 to 18kHz, +1, -4 dB

Signal/Noise Ratio: 60 dB at 100µV.

Receiver Antenna: Flexible “rubber duckie” type or optional 75 Ohm remote antenna

Controls: Power On/Off, FM Channel, Squelch.

Distortion: less than 1.0% at rated power

Phones Output: 1/4” TRS, 10mVrms @ 50 Ohms impedance.

Line Output: 1/4” TRS, Balanced (Tip is positive, Ring is negative, Sleeve is common) or Unbalanced (Tip or

Ring can be connected to the Sleeve), nominal output: +4dBm @ 600 Ohms, 1.2Vrms

Additional Notice:

This device complies with the requirements of Industry Canada (IC), as specified in document RSS-210.The device is

permitted only on a no-interference no-protection basis, that is, it must cease operation when it is determined (such as

by turning the device on and off) that it causes harmful interference to services authorized by IC. Authorized services are

listed in the Canadian Table of Frequency Allocations or as determined by IC from time to time. Also, the operator must

accept any radio interference received, including interference that may cause undesired operation of the device.

Williams Sound Corp.

10399 West 70th St., Eden Prairie, MN 55344-3459

U.S.A. 800-328-6190 / 952-943-2252 / FAX: 952-943-2174

www.williamssound.com

Table of contents

Other Williams Sound Receiver manuals

Williams Sound

Williams Sound WIR RX14 Assembly instructions

Williams Sound

Williams Sound SoundPlus WIR TX300 Troubleshooting guide

Williams Sound

Williams Sound HEARING HELPER TGS PRO 720 Guide

Williams Sound

Williams Sound SoundPlus WIR RX22-4 Assembly instructions

Williams Sound

Williams Sound Whisper R863 User manual

Williams Sound

Williams Sound SoundPlus WIR 952 Guide

Williams Sound

Williams Sound PPA VP 37 Guide

Williams Sound

Williams Sound WIR 135 User manual

Williams Sound

Williams Sound MOD 112 Assembly instructions

Williams Sound

Williams Sound Personal P.A. T18 User manual

Williams Sound

Williams Sound WIR RX1 User manual

Williams Sound

Williams Sound T2 863 User manual

Williams Sound

Williams Sound SoundPlus WIR RX22-4 Assembly instructions

Williams Sound

Williams Sound SoundPlus Infrared Receiver WIR RX238 User manual

Williams Sound

Williams Sound SoundPlus WIR RX22-4 Assembly instructions

Williams Sound

Williams Sound SoundPlus WIR RX237 User manual

Williams Sound

Williams Sound PPA VP User manual

Williams Sound

Williams Sound Personal PA PPA R7 User manual

Williams Sound

Williams Sound R16 User manual

Williams Sound

Williams Sound SoundPlus WIR RX18 Assembly instructions

Williams Sound

Williams Sound Whisper R863 User manual

Williams Sound

Williams Sound Digi-Wave DLT 400 User manual

Williams Sound

Williams Sound PPA T46 User manual

Williams Sound

Williams Sound TGS 300 Guide

Popular Receiver manuals by other brands

Garmin

Garmin GA 23 Owner's manual and reference guide

Aiphone

Aiphone PS-12F instructions

IMES

IMES TCS-01CA-PMI Original Operating Instruction

BWI Eagle

BWI Eagle AIR-EAGLE SR Product information bulletin

AMIMON

AMIMON AMN12310 WHDI datasheet

Dual

Dual DMCPA79BT Installation & owner's manual

Sound Associates

Sound Associates SA652P Operation manual

Sherwood

Sherwood NewCastle R-772 Service manual

Audio

Audio A10-RX Series user guide

AllSee

AllSee PushShare PSRV1.1 user manual

DEMAG

DEMAG DRC-DR D2 operating instructions

Teleco

Teleco TVRCL868A02 manual

Bosch

Bosch RF3222E installation instructions

Kramer

Kramer 631R user manual

Xpress

Xpress xmc10 installation guide

JVC

JVC KD-MR1BTS instruction manual

Omega Engineering

Omega Engineering UWTC-REC3 user guide

e-survey

e-survey E300 Pro user manual
