White Knight Eco 86A User manual

ELECTRONIC SENSING GAS DRYER

INSTRUCTIONS FOR USE

FOR USE IN THE UNITED KINGDOM AND IRELAND WITH NATURAL GAS ONLY

IMPORTANT

PLEASE READ THESE INSTRUCTIONS THOROUGHLY BEFORE USING THIS APPLIANCE.

KEEP THEM IN A SAFE PLACE FOR FUTURE REFERENCE.

SECTION 1: BEFORE USE

SECTION 2: INSTALLATION

* Safety Warnings

* User Information

* Venting

* Prior to Installation

* Positioning and Air Supply

* Final Installation

SECTION 3: TECHNICAL SPECIFICATIONS

SECTION 4: CONTROL PANEL

SECTION 5: DRYING YOUR LAUNDRY

* Before Drying

* Drying

* After Removing the Dried Clothes

SECTION 6: ADDITIONAL INFORMATION

* Any Problems?

* Optional Extras

SECTION 7: DOOR REVERSAL

SECTION 1: BEFORE USE

* Safety warnings

These notes are provided in the interest of safety. You must read them before installing or using the

appliance.

- This tumble dryer is intended for NORMAL DOMESTIC USE ONLY.

- The dryer must be installed by a Registered Installer.

- Any electrical work required to install the appliance should be carried out by a qualified person.

- The tumble dryer should be serviced by an appointed service organisation and only genuine parts used.

- It is recommended that the dryer be serviced annually by a person competent to service gas fired tumble

dryers.

Under no circumstances should you attempt to repair the appliance yourself. Repairs carried out by

inexperienced persons may cause serious injury. Consult your local appointed service engineer and insist

on genuine spare parts.

- The special mains cable and plug assembly must only be replaced with a genuine part available from the

manufacturer or service agent.

- Keep the packing materials from your machine away from children to avoid hazards.

- Keep pets away from your machine.

- Your machine is designed for use in a domestic environment. The warranty will be invalid if you use it for

commercial purposes.

DO NOT - use a two-way adaptor, or extension lead. The dryer must be connected to its own socket.

DO NOT - block the air inlets at the front and back of your dryer.

DO NOT - exceed the recommended maximum load.

DO NOT - place articles in the dryer if anything other than a water solution has been used in the cleaning

process.

DO NOT - dry unwashed items in the tumble dryer.

DO NOT - attempt to dry dripping wet articles.

DO NOT - use the tumble dryer if you suspect that it is damaged in any way.

SECTION 1: BEFORE USE

* User Information

- WARNING: Never stop a tumble dryer before the end of a drying cycle unless all items are quickly

removed and spread out so that heat is dissipated.

- Clean the lint filter after each drying cycle or the restrictions to airflow will extend drying times and

could cause the limit thermostat to stop the burner firing for the remaining part of the drying cycle. This

will require the appliance being restarted.

- Under no circumstances should anything other than the recommended articles be placed in the tumble

dryer.

- It is dangerous to alter or modify the product in any way other than fitting authorised accessories.

- The rear of the dryer gets quite hot during use. Position the dryer so that the back is not accessible while

in operation.

- DO NOT - allow fluff to accumulate around the tumble dryer. It is important to clean fluff from the

window of the dryer and around the door seal after each drying cycle. Failure to do so could result in

water leaking.

- This appliance is not intended for use by persons (including children) with reduced physical, sensory or

mental capabilities, or lack of experience and knowledge, unless they have been given supervision or

instruction concerning use of the appliance by a person responsible for their safety.

- Items that have been soiled with substances such as cooking oil, acetone, alcohol, petrol, kerosene, spot

removers, turpentine, waxes and wax removers should be washed in hot water with an extra amount of

detergent before being dried in the tumble dryer.

- Remove all objects from pockets such as lighters and matches.

- DO NOT – allow children to tamper with the controls and keep them away from the dryer when it is in

operation.

- DO NOT – attempt to dry items containing foam rubber or rubber-like material.

- DO NOT - place items contaminated with inflammable substances in the dryer, such as petrol, cleaning

solvents, cooking oil fat, or hair lacquer. This can cause fires. For the same reason, do not dry rubber,

foam rubber, plastic or paper

- We suggest a fabric conditioner to be used to reduce static electricity.

- Fabric softeners, or similar products, should be used as specified by the Fabric Softener instructions.

- Items such as foam rubber (latex foam), shower caps, waterproof textiles, rubber backed articles and

clothes or pillows fitted with foam rubber pads should not be dried in the tumble dryer.

- Do not tumble dry woollen or wool mixture articles unless the article is labelled to be. This should avoid

shrinkage.

- Place delicate articles e.g. tights, scarves, inside a pillowcase.

- To avoid the need to iron easycare polyester/cotton items it is better to only dry small loads (i.e. half fill

drum).

- It is better to dry small and large articles together.

- Do not overload the dryer or dry large bulky items such as duvets or sleeping bags as it is important that

the airflow through the dryer is not obstructed.

- We recommend that the appliance is unplugged each time after use. It should always be disconnected

from the electricity supply if it is to be left unattended for long periods (i.e. weekends, holidays etc).

SECTION 2: INSTALLATION

* Venting

For a safe and reliable installation please refer to the installation and service booklet.

Fixed Rear Venting.

The dryer vents through a hole at the bottom of the back panel. A vent hose must always be used to vent

the warm damp exhaust air to outside.

The best solution is to make a permanent connection through either a wall or a window. This is

particularly recommended for small, cool rooms and a kit for this purpose is available as an accessory.

*Venting

When using the vent hose, remember the following points:

- The vent hose must be at least 10cm (4ins) in diameter.

- No more than three right-angled bends should be allowed when positioning the vent hose.

- Do not distort or constrict the vent hose as this will reduce the airflow.

- The vent hose must not be shared with other appliances, for example, a cooker hood outlet.

- When drying, the vent hose must always be extended through an open door, window or purpose made

opening.

* Prior to Installation

Check that the local distribution conditions, nature of gas, pressure and adjustment of the dryer are

compatible.

* Positioning and Air Supply

The dryer must not be placed in a bedroom, bathroom, shower room, or locations where concentrations of

flammable vapours may accumulate, but may be positioned against walls, other appliances, kitchen

furniture and similar surfaces. A venting hose must be used. For safe operation, the room in which the

dryer is placed must have a good supply of fresh air. This must include an openable window or equivalent

which must always be open during the drying cycle.

The appliance must not be installed behind a lockable door, a sliding door or a door with a hinge on the

opposite side to that of the tumble dryer.

* Final Installation

If you wish to change the side on which your door opens, see Section7 - Door Reversal. Remove any

dust by wiping the drum and door with a damp cloth. Any initial smell of burning will be caused by dust

on the heater and will quickly disappear. Position the tumble dryer so that the plug remains accessible

after installation.

SECTION 3: TECHNICAL SPECIFICATIONS

Overall Dimensions:

Height: 85 cm Width: 59.5 cm Depth: 57 cm

Maximum Dry Weight Loads:

Cotton 7kg, 'Easycare' polyester/cotton 7kg (for minimum creasing 3kg) Delicates 3kg

For electrical and gas ratings see plate on back of dryer. For Model type see serial plate inside door,

(needed when requesting service). Room temperature range 5°C to 30°C, (drying performance decreases

as room temperature falls). Your washing machine should have a spin speed of not less than 1000rpm for

maximum drying efficiency.

SECTION 4: CONTROL PANEL

A. Heat push button, press to select appropriate heat setting (some programs have limited choice

of heat setting). High is used for drying cottons and linens; half heat is used for drying

synthetics and delicates; cool does not apply any heat.

Place the filter in its operating position as

shown in the diagram. For cleaning the filter

refer to Section 5: Drying your laundry.

B. “-” push button, changes program or time selected downwards

C. Display Window, indicates program number / drying time / delay time

D. “+” push button, changes program or time selected upwards

E. Start push button, push to start the drying cycle

F. Activate push button; press to illuminate the Display Window.

G. Program Chart (printed on control panel door, press to open).

H. Gas On Neon

I. Anti-crease push button, press to select anti-crease mode. Indicator illuminates when anti-crease

has been selected and flashes when the dryer is in the anti-crease phase of the cycle

J. Reset push-button, resets the program to the default settings

K. Delay Start display, shows delay time selected

L. Delay Start push button, press to select delay start mode and set delay time

MOISTURE SENSING DRYER – FUNCTIONS

This sensing tumble dryer has a full moisture sensing system so you can choose the level of dryness

required on your clothing/items. Alternatively you can select a timed drying cycle.

P1 – Extra dry: clothes are extra dry and can be put away

P2 – Cupboard dry: clothes are dry enough to be put away

P3 – Mid dry: depending upon fabric, clothes are generally dry enough to be put away

P4 – Extra iron dry: clothes are almost dry but can be easily ironed

P5 – Iron dry: clothes are slightly damp and ready to be ironed

P6 – Damp dry: clothes are damp and ready to be ironed

Programs 1-6 can be operated on the full heat, half heat or cool setting.

P7 – 30 minute fixed time drying program. This program can be operated on the full or half heat setting.

P8 – 30 minute fixed time ‘airing’ program; useful for freshening up clothing. This program operates

without the heater, circulating air through the dryer at the ambient temperature.

P9 – Variable Time program – can be set from 10 min. to 180 min. drying time and can be operated on

the full heat, half heat or cool setting. To return from a time program to the main menu, press the Reset

button.

All programs from P1 to P9 can be used with the Delay Start feature. A maximum of 9 hours delay time

is available in 1 hour increments.

The anti-crease function can be selected to minimize creasing by continuing to turn the drum periodically

after the main drying cycle has finished.

SECTION 5: DRYING YOUR LAUNDRY

* Before Drying - Check care labels inside the garments

CARE LABELS YOU MAY FIND ON YOUR FABRICS

* Drying

When starting the dryer for the first time, or starting after temporary disconnection from the gas supply,

air in the pipes will prevent ignition. To clear this air, the dryer must be operated by selecting extra dry

and pressing Activate and Start. Allow the dryer to operate for 1/2 minute before stopping the dryer.

Repeat this process until continuous burning of the gas is indicated by the neon light on the control panel.

(The light will go out when in reverse tumble).

OPERATION

Open the door.

Load clothes loosely into the drum. Load sheets first, starting with one corner.

Close the door.

Dry your hands.

Plug in the machine and press the Activate button. The Display Window will illuminate. If no further

buttons are pressed, the display will go into sleep mode after 1 minute. To reactivate, press the Activate

button.

The dryer will automatically remember the program and heat setting last used. To change the program

use the (-) or (+) buttons on either side of the display window. Change the heat setting if required.

If P9 (variable time program) has been selected press the coloured Start button. A default of 120 minutes

will appear in the display window. Use the (-) or (+) buttons to adjust the drying time for your laundry

from 10 minutes up to 180 minutes. Holding the button down will rapidly change the time selected.

Select anti-crease function if required.

Press the coloured Start button to commence the drying cycle. The drum will begin rotating and will stop

automatically when your clothes are dry or the timed cycle has finished. An audible alert will sound to

indicate that the drying cycle has finished.

If you have selected the anti-crease function, the drum will continue to turn periodically for up to 8 hours

or until the dryer is stopped by opening the dryer door or by disconnecting from the mains.

If the door is opened during a drying cycle the dryer will stop. To restart, close the door, press the

Activate button then press the coloured Start button.

Once the Start button has been pressed, the program is locked and all buttons are disabled. To stop the

machine and unlock the buttons - open the door

There is an automatic 12 minute cool down period at the end of each cycle, during which the heater is

switched off and the green cool indicator is on. This helps to minimize creasing, and must always be used

fully to avoid the risk of fire.

DELAY START

To use the Delay Start feature press the Delay Start button before pressing the Start button. The Delay

Start display will show 1 hour of delay time. Repeated pressing, or holding down, of the Delay Start

button will increase the amount of delay time to a maximum of 9 hours. To cancel Delay Start, press the

Reset button. To start the delay period press Start. The delay time will start to count down in the display

window. To cancel Delay Start once the countdown has started, de-power the machine by opening the

dryer door.

NEVER SWITCH THE DRYER OFF AND LEAVE A HOT LOAD IN THE DRUM DUE TO THE

RISK OF FIRE.

- When drying large items such as sheets, we suggest you periodically stop the dryer to redistribute the

load.

- To stop the machines during the middle of the programme simply open the door; the drum will stop

rotating automatically. To restart the machine, close the door, press the Activate button and then press the

Start button.

* After removing the dried clothes

ALWAYS CLEAN THE FILTER. Failure to clean the filter will extend drying times and could cause

the safety cut-out to operate.

SECTION 6: ADDITIONAL INFORMATION

* Any Problems?

If the clothes are not dry after normal drying time:

- Check that you have selected an appropriate programme and heat setting

- Check that the lint filter has been cleaned. A blocked filter will restrict the airflow.

- Check that the venting system is clear, and the front air inlet is not blocked.

- Ensure the dryer is not overloaded. Restart the appliance with ‘Extra Dry’ selected and the heat switch

on the high setting, press Activate and then Start buttons and observe the neon remains lit for more than

one minute. If the neon goes out within the minute wait a further three minutes before stopping and

restarting the appliance by opening and closing the door and pressing the Activate button and then the

Start button. Observe the neon remains lit for more than one minute and the appliance continues to heat

throughout the cycle (the window remains warm) and the clothes are dry at the end of the cycle.

- Pull the filter upwards and away from the appliance

- Remove any threads or fluff by hand or with a soft brush.

- Slide the filter back.

- Wash the filter occasionally in detergent solution and with a soft brush to remove

small particles.

- If your filter becomes damaged, replace it to ensure no damage is caused to the

dryer.

If all these points are checked and the laundry is still not dry, call for a service engineer.

If your machine does not work check the following before calling a service engineer:

- Check that there is a supply of electricity.

- Check that the machine is switched on and the door properly closed.

- Check the fuse in the moulded plug.

*Optional Extras

Restraining Kit - To prevent damage to the gas connection should you move the dryer.

Vent Hose - Leads the warm damp air to an open door or window.

Wall/Window Vent Kit - To make a permanent connection through a wall or window.

Stacking Kit - To enable your dryer to be secured onto the top of a front loading washing machine (to

save floor space).

The above items can be purchased as accessories for your tumble dryer from your supplier.

Instructions for stacking, if required, are supplied with the stacking kit.

THIS APPLIANCE MUST BE EARTHED

This label, positioned on the rear of your dryer, indicates the surface is hot when in operation - avoid

touching.

CAUTION

HOT SURFACE

This appliance is constructed from materials which are fully RoHS compliant.

This appliance is marked according to the European Directive 2002/96/EC

on Waste Electrical and Electronic Equipment (WEEE).

At end of life this product should be recycled and not disposed in household waste.

Contact your retailer, council or local authority for further information.

Other manuals for eco 86A

Table of contents

Other White Knight Dryer manuals

White Knight

White Knight B96G8W User manual

White Knight

White Knight ECO 43A User manual

White Knight

White Knight C8317 User manual

White Knight

White Knight 44AS User manual

White Knight

White Knight 0312 44A 15330 - 44AS User manual

White Knight

White Knight B96M8W User manual

White Knight

White Knight C44A7WL User manual

White Knight

White Knight 0312 727 15003 - 727c User manual

White Knight

White Knight HX3 8DE User manual

White Knight

White Knight 0312 427 15310 User manual

White Knight

White Knight BG 43A Quick guide

White Knight

White Knight CL372 User manual

White Knight

White Knight 44AS User manual

White Knight

White Knight 42AW User manual

White Knight

White Knight 0312 44C 15001 - C45CWUK User manual

White Knight

White Knight 0312 427 15301 - 427SV User manual

White Knight

White Knight eco 86A User manual

White Knight

White Knight 28007 T User manual

White Knight

White Knight C831WV User manual

White Knight

White Knight B96M8W User manual

White Knight

White Knight C36AW User manual

White Knight

White Knight 831 WV User manual

White Knight

White Knight C427WV User manual

White Knight

White Knight CONDENSER TUMBLE DRYERS User manual

Popular Dryer manuals by other brands

Bosch

Bosch WTA79200GB Installation and operating instructions

Amana

Amana W10233410A Use and care guide

Miele

Miele TWH 780 WP operating instructions

Asko

Asko T760 user guide

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Original instructions

Bosch

Bosch Logixx 10 WTB76556GB Instruction manual and installation instructions

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Operation and installation

Electrolux

Electrolux EW2H328R2 user manual

Beko

Beko DS8433RX1M user manual

Dawlance

Dawlance Spinner DS 6000 C owner's manual

Electrolux

Electrolux TP5080TW user manual

AEG

AEG TR838P4OB user manual

Indesit

Indesit IDV 75 instruction manual

Infiniton

Infiniton SD-DG85C manual

BOMANN

BOMANN WT 5019 instruction manual

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Installation

Asko

Asko T793C operating instructions

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer installation instructions
