Whirlpool GSL9365EZ1 User manual

A Note to You............ 2

Washer Safety ..........3

Parts and Features ... 4

Operating Your

Washer......................5

Caring for Your

Washer.................... 11

Troubleshooting ...... 12

Requesting

Assistance or

Service .................... 16

Index ....................... 19

Warranty ................. 20

In the U.S.A. for assistance or service,

call the Consumer Assistance Center:

1-800-253-1301

In Canada for assistance or service,

see page 17.

3950309

Three speed

automatic washers

Home Appliances

MAGCORP_CD

ANOTE TO YOU

Thank you for buying a WHIRLPOOL*appliance.

The Whirlpool Brand is committed to designing quality products that consistently perform for you to make

your life easier. To ensure that you enjoy years of trouble-free operation, we developed this Use and Care

Guide. It is full of valuable information about how to operate and maintain your appliance properly and safely.

Please read it carefully.

Also, complete and mail the Ownership Registration Card provided with your appliance. The card helps us

notify you about any new information on your appliance.

Please record your model’s information.

Whenever you call to request service for your appli-

ance, you need to know your complete model number

and serial number. You can find this information on the

model and serial number label (see the diagram on the

“Parts and Features” page for the location of the label).

Also, record the other information shown in the next

column.

Keep this book and the sales slip together in a safe place for future reference.

Model Number __________________________________

Serial Number ___________________________________

Purchase Date __________________________________

Dealer Name ____________________________________

Dealer Address __________________________________

Dealer Phone ___________________________________

1-800-253-1301

Our Consumer Assistance Center number is toll free.

In Canada, for assistance or service, see the “Requesting Assistance or Service” section.

To find detailed product information, the location of the nearest Whirlpool dealer or authorized servicer, to

purchase an accessory item, or register your appliance on-line, please visit our Web site at

www.whirlpool.com

In Canada, visit our Web site at www.whirlpool.com/canada

WASHERSAFETY

IMPORTANT SAFETY INSTRUCTIONS

WARNING –To reduce the risk of fire, electric shock, or injury to persons when using the washer, follow

basic precautions, including the following:

•Read all instructions before using the washer.

•Do not wash articles that have been previously

cleaned in, washed in, soaked in, or spotted with

gasoline, dry-cleaning solvents, other flammable,

or explosive substances as they give off vapors

that could ignite or explode.

•Do not add gasoline, dry-cleaning solvents, or

other flammable, or explosive substances to the

wash water. These substances give off vapors

that could ignite or explode.

•Under certain conditions, hydrogen gas may be

produced in a hot water system that has not been

used for 2 weeks or more. HYDROGEN GAS IS

EXPLOSIVE. If the hot water system has not been

used for such a period, before using the washing

machine, turn on all hot water faucets and let the

water flow from each for several minutes. This will

release any accumulated hydrogen gas. As the

gas is flammable, do not smoke or use an open

flame during this time.

– SAVE THESE INSTRUCTIONS –

•Do not allow children to play on or in the washer.

Close supervision of children is necessary when the

washer is used near children.

•Before the washer is removed from service or

discarded, remove the door.

•Do not reach into the washer if the tub or agitator is

moving.

•Do not install or store the washer where it will be

exposed to the weather.

•Do not tamper with controls.

•Do not repair or replace any part of the washer or

attempt any servicing unless specifically recom-

mended in this Use and Care Guide or in published

user-repair instructions that you understand and

have the skills to carry out.

•See Installation Instructions for grounding

requirements.

You will be killed or seriously injured if you don’t

follow instructions.

You can be killed or seriously injured if you don’t

follow instructions.

Your safety and the safety of others is very important.

We have provided many important safety messages in this manual and on your appliance. Always read and

obey all safety messages.

This is the safety alert symbol.

This symbol alerts you to hazards that can kill or hurt you and others.

All safety messages will be preceded by the safety alert symbol and the word “DANGER” or

“WARNING.” These words mean:

wDANGER

wWARNING

All safety messages will identify the hazard, tell you how to reduce the chance of injury, and tell you what can

happen if the instructions are not followed.

Load SizeLoad Size Speed SelectSpeed Select

Heavy Duty • Large CapacityHeavy Duty • Large Capacity

Extra

Large

Medium Large

Pull StartPull Start

Push StopPush Stop

Permanent

Press

Normal

Super WashSuper Wash

Hand WashablesHand Washables

Regular

Light

Normal

Light

Normal

Soft Wash

Heavy

Delicates

SpinSpin

Spin

SpinSpin

Off

Rinse

Cool

Down

Rinse

Extra

RinseRinse

Extra

RinseRinse

X-RinseRinse

Pause

Temperature Speed SelectSpeed Select

Hot WarmWarm WarmWarm ColdCold

Wash

Cold WarmWarm Cold Warm

Rinse

Low High

High Low

8 Cycle - 2 Speed8 Cycle - 2 Speed

Small

Off

On On

Off

End of Cycle SignalEnd of Cycle Signal

Agitate

Spin

High High Low Low

PARTS AND FEATURES

The parts and features of your washer are illustrated on this page. Become familiar with all parts

and features before using your washer. Page references are included next to some features. Refer

to those pages for more information about the features.

NOTE: The drawings in this book may vary from your washer model. They are designed to show

the different features of all models covered by this book. Your model may not include all features.

Cycle control knob

(pp. 7-9)

Liquid chlorine

bleach dispenser

(p. 5)

Model and serial

number label

(under lid)

Basket

Tub

Load size

selector

(p. 6)

CLEAN TOUCH*

panel

Liquid fabric

softener

dispenser

(pp. 6, 11)

Agitator

MAGIC CLEAN*

lint filter

(bottom of

washer basket)

(p. 9)

Cycle signal selector

(p. 6)

Water temperature

selector

(p. 6)

Extra rinse selector

(p. 6)

To get the best washing results possible, you must use your washer correctly. This section tells

you how to use your washer properly and efficiently.

USING YOUR WASHER

OPERATING YOURWASHER

1. Measure detergent and pour it into the washer.

•If desired, you may

also add powder or

liquid color-safe

bleach.

•Add extra detergent

for the Super Wash

cycle.

2. Drop a sorted load of clothes loosely into your

washer, filling to the

top row of holes.

•Load evenly to main-

tain washer balance.

Mix large and small

items.

•Items should move

easily through the wash

water. Overloading can

cause poor cleaning.

•To reduce wrinkling

of permanent press clothes and some synthetic

knits, use a large load size to provide more space

(see step 6).

continued on next page

3. (OPTIONAL STEP) Pour measured liquid chlorine

bleach into the liquid

chlorine bleach dis-

penser. Bleach will

be diluted automatically

during the wash part of

the cycle.

•Never use more than

1 cup (250 mL) for a full

load. Use less with a

smaller load size.

•Follow the manufac-

turer’s directions for safe use.

•To avoid spilling, use a cup with a pouring spout.

Do not let bleach splash, drip, or run down into the

washer basket.

•Make sure you use only liquid chlorine bleach in

this dispenser.

wWARNING

Explosion Hazard

Never place items in the washer that are

dampened with gasoline or other

flammable fluids.

No washer can completely remove oil.

Do not dry anything that has ever had any

type of oil on it (including cooking oils).

Doing so can result in death, explosion,

or fire.

wWARNING

Electrical Shock Hazard

Plug into a grounded 3 prong outlet.

Do not remove ground prong.

Do not use an adapter.

Do not use an extension cord.

Failure to follow these instructions can

result in death, fire, or electrical shock.

6. Turn the Load Size selector to the correct setting

for your wash load and

the type of fabric being

washed.

•Your washer has five

load size settings.

•Choose a load size

that allows the load to

move freely for best

fabric care. See

“Loading” later in this

section.

•Change the setting after the washer has

started filling by turning the selector to a

different setting.

OPERATING YOUR WASHER

USING YOUR WASHER (CONT.)

4. (OPTIONAL STEP) Pour measured liquid fabric

softener into the fabric

softener dispenser.

•Do not spill or drip

any fabric softener on

the clothes.

•Make sure you use

only liquid fabric

softener in this

dispenser.

7. Set the Water Temperature selector to the correct

setting for the type of

fabric and soils being

washed.

•Your washer uses the

Accuwash automatic

temperature control.

Accuwash maintains a

uniform water tempera-

ture by regulating

incoming hot and cold

water. This helps elimi-

nate undissolved detergent and ensures consis-

tent cleaning results. The cold wash is maintained

at approximately 75°F (24°C). The warm wash is

maintained at approximately 100°F (38°C).

NOTE: Make sure that both hot and cold water

faucets are turned on, or the Accuwash feature

will not work properly.

•Use the warmest water safe for fabric.

•Follow garment label instructions.

HOT: 130°F (54°C) or above.

– Whites and pastels.

– Heavy and greasy soils.

WARM: 90° to 110°F (32° to 44°C).

– Bright colors.

– Moderate to light soils.

COLD: 70° to 90°F (21° to 32°C).

– Colors that bleed or fade.

– Light soils.

8. (OPTIONAL STEP) Your washer has an Extra

Rinse selector. For an additional rinse and spin

at the end of a wash cycle, set the Extra Rinse

selector to On.

9. (OPTIONAL STEP) Set the Cycle Signal selector

to On if you want your washer to sound a signal

when the wash cycle is finished. This signal is

helpful when you are washing items that should

be removed from the washer as soon as the

cycle ends.

5. Close the washer lid.

•Dilute liquid fabric softener by filling the dis-

penser with warm

water until liquid

reaches the

crossbar in the

opening.

•Softener is added

automatically during

the rinse portion of

the cycle.

OPERATING YOUR WASHER

USING YOUR WASHER (CONT.)

10. Push in the Cycle Control knob and turn it to

the wash cycle you

want. See “Cycle

descriptions” later in

this section.

•Reduce the wash

time when using a

small load size setting.

11. Pull out the Cycle Control knob to start the

washer.

NOTE: To stop the washer at any time, push in the

Cycle Control knob. To restart the washer, close

the lid (if open) and pull out the Cycle Control knob.

Loading suggestions

For these suggested full-sized loads, set the Load Size selector to the highest load size setting.

SUPER CAPACITY PLUS WASHERS

Heavy Work Clothes

3 pair pants

3 shirts

4 pair jeans

1 coverall

1 overall

Towels

10 bath towels

10 hand towels

14 wash cloths

1 bath mat

Mixed Load

3 double sheets

4 pillowcases

8 T-shirts

6 pair shorts

2 shirts

2 blouses

8 handkerchiefs

Delicates

3 camisoles

1 quilted robe

4 slips

4 panties

2 bras

2 nighties

1 baby’s dress

SELECTING ACYCLE AND TIME

This section describes the available wash cycles

and will help you make the best cycle selections

for your wash loads. Each cycle is designed for

different types of fabric and soil levels.

•The washer pauses briefly throughout each cycle.

These pauses are normal. Refer to “Understanding

normal washer sounds” to learn more about the

sounds you may hear during a wash cycle.

•Refer to “Understanding what happens in each

cycle” later in this section to learn what happens

during a wash cycle.

OPERATING YOUR WASHER

CYCLE DESCRIPTIONS

Ultimate Care*cycle

(Hand Washables)

The Ultimate Care (Hand Washables) cycle features

a series of brief, extra low-speed agitations

(7 seconds) and short soaks (12 seconds) to gently

clean special-care items. Extra low spin speeds

minimize wrinkling. Use 6 minutes of wash time to

clean lightly soiled hand washables.

Garments are labeled “Hand Wash” because:

•The fiber or construction may be sensitive to

agitation.

•The fabric contains sensitive dyes that may bleed.

Properly sort and then use your Hand Washables

cycle for gentle washing. Follow care label direc-

tions for drying. Items that may shrink should be

dried flat. Block these items by gently stretching to

original measurements. Woolens tend to shrink

more the first time they are washed.

•If items appear to be floating due to trapped air,

stop the washer by pushing in the Cycle Control

knob. Push items down into the water. Restart the

washer.

Normal cycle

The Normal cycle features high-speed agitation for

cleaning cottons and linens. High spin speeds

shorten drying times. Select 9 (Regular), 12 (Regu-

lar/Heavy), or 15 (Heavy) minutes of wash time,

depending on whether your load is moderately or

heavily soiled. For lightly soiled cotton and linen

fabrics, use the 6-minute Light setting.

Super Wash – Select the 18-minute Super Wash

feature to wash heavily soiled loads that need

maximum soil removal. Use two times the amount

of recommended detergent for this cycle.

Permanent Press cycle

The Permanent Press cycle starts with high-speed

agitation and then steps down to low-speed agita-

tion for cleaning permanent press blends and

synthetic fabrics. To minimize wrinkling, this cycle

features a cool-down rinse and a low-speed final

spin. Select 3 (Extra Light), 6 (Light) or 9 (Regular)

minutes to clean very light to moderately soiled

loads.

Extra Delicate cycle

The Extra Delicate cycle features an extra

low-speed agitation for gentle soil removal from

delicate items and washable knits. Extra low spin

speeds minimize wrinkling. Select 3 (Light) or 6

(Regular) minutes to clean light to moderately

soiled loads.

RINSE/DRAIN AND SPIN

Rinse and Spin feature

When using extra detergent for heavily soiled

clothes, or washing special-care items, you may

find an extra rinse and spin is needed.

•For an additional rinse and spin, push in the

Cycle Control knob and turn it clockwise to any

of the Rinse settings. The washer fills to the

selected load size, agitates, drains, and spins.

NOTE: An Extra Rinse option is also available. See

“Using your washer” earlier in this section.

Drain and Spin feature

A drain and spin may help shorten drying times for

some heavy fabrics or special-care items by remov-

ing excess water.

•For a drain and spin, push in the Cycle Control

knob and turn it clockwise to any of the Spin

settings. Then pull out the Cycle Control knob.

The washer drains, then spins.

Your washer has a self-cleaning lint filter at the

bottom of the basket. Wash and rinse water flow

over the filter during agitation, separating the lint

from the water. The lint spins out of the system

during the spin part of the cycle.

If your washer drains into a tub, remove any lint

collected in the tub or strainer.

MAGIC CLEAN

lint filter

Basket

interior

MAGICCLEAN*LINT FILTER

UNDERSTANDING NORMAL WASHER SOUNDS

During drain

If water is drained quickly from your washer (depend-

ing on your installation), you may hear air being

pulled through the pump during the end of draining.

After drain and before spin

When the cycle changes from draining to spinning,

you may hear gears engaging.

Your new washer may make sounds your old one

didn’t. Because the sounds may be unfamiliar, you

may be concerned about them. Don’t be; most of

them are normal.

The following describes some of the sounds you

may hear and what causes them.

During washing

When you select a small load size setting, your

washer has a lower water level. This may cause a

clicking sound from the upper part of the agitator.

OPERATING YOUR WASHER

UNDERSTANDING WHAT HAPPENS IN EACH CYCLE

When the Cycle Control knob is set to a number

and pulled out, the washer fills (to the selected load

size) before agitation and timing start. The washer

begins agitating immediately after filling; agitation

occurs with the washer lid up or down.

During agitation, the XTRA ROLLACTION* agitator

creates a continuous

rollover action that pro-

vides a thorough cleaning

of the wash load.

After agitation starts, the Cycle Control knob turns

clockwise until it points to an Off area and the

cycle ends.

NOTE: The washer pauses briefly throughout

each cycle. These pauses are normal for washer

operation.

Sequence of cycles

Fill

▼

Rinse

▼

Drain-No agitation

▼

Spin-Spray rinse

▼

Spin

▼

Off

Fill

▼

Wash selected time

▼

Drain†

No agitation

▼

Spin

▼

WASH RINSE

†The Permanent Press cycle partially drains, fills, agitates

briefly, and drains.

OPERATING YOUR WASHER

This manual suits for next models

Table of contents

Other Whirlpool Washer manuals

Whirlpool

Whirlpool W10856086A User manual

Whirlpool

Whirlpool GSW9800PW User manual

Whirlpool

Whirlpool 3363565 User manual

Whirlpool

Whirlpool AWM8121 User manual

Whirlpool

Whirlpool LXR7144EQ2 User manual

Whirlpool

Whirlpool LA58OOXT User manual

Whirlpool

Whirlpool LXR9445JQ0 User manual

Whirlpool

Whirlpool 4GMVWC100 User manual

Whirlpool

Whirlpool CAM2762KQ User manual

Whirlpool

Whirlpool WVP9000S User manual

Whirlpool

Whirlpool Duet HT GHW9250ML1 User manual

Whirlpool

Whirlpool AZB 9682 User manual

Whirlpool

Whirlpool AUTOMATIC WASHER WITH CATALYST CLEANING... User manual

Whirlpool

Whirlpool 8540904 Assembly instructions

Whirlpool

Whirlpool FFT M22 9X3B EE User manual

Whirlpool

Whirlpool WFW94HEX Series User manual

Whirlpool

Whirlpool FSCR80420 Installation and operation manual

Whirlpool

Whirlpool LCE4332PQ - 22" Washer w/2.1 cu. Ft.... User manual

Whirlpool

Whirlpool LA6400XP User manual

Whirlpool

Whirlpool LSR7233DQ0 User manual

Whirlpool

Whirlpool 3LCHW9100YQ User manual

Whirlpool

Whirlpool CAE2745 User manual

Whirlpool

Whirlpool 4KWTW4605FW0 User manual

Whirlpool

Whirlpool FSCR80214 Installation and operation manual

Popular Washer manuals by other brands

Tricity Bendix

Tricity Bendix AW 1000 W Operating & installation instructions

Panasonic

Panasonic NA-F60L5WRB operating instructions

GE WSLP1500 Dimensions and installation information

Electrolux

Electrolux EWF1284EDW Service manual

Bosch

Bosch WAN2829BSN User manual and installation instructions

LG TV2516DV3B owner's manual

LG TH2517DSAV owner's manual

VESTEL

VESTEL CMH-XL 7510 TE user manual

AEG

AEG 74335 User information

Johnson

Johnson JWF721A user manual

Beko

Beko WTE7604XLW0 owner's manual

Danby

Danby DTT100A1WDB Owner's use and care guide

Amica

Amica WA 14 Ex operating instructions

Daewoo

Daewoo DWD-F1222 instruction manual

Bosch

Bosch WAS28461AU instruction manual

Miele

Miele PW 6080 Vario manual

Finlux

Finlux FLX108CF220 user manual

Beko

Beko WKB 51231 PTMA manual
