Whirlpool BYCW6292W0 Operating instructions

3953947

Two Speed

Automatic Washer

A Note to You................................2

Washer Safety...............................3

Parts and Features.......................4

Using Your Washer.......................5

Starting your washer..................5

Loading.......................................6

Selecting a cycle

and time......................................7

Adding liquid chlorine bleach .....8

Adding liquid fabric softener.......8

Rinse/drain and spin ..................8

Self-cleaning lint filter.................9

Understanding normal

washer sounds...........................9

Understanding what

happens in each cycle..............10

Caring For Your Washer ............11

Troubleshooting .........................12

Assistance or Service................15

Warranty......................................16

1-800-253-1301

Call us with questions or comments.

www.crosley.com

A NOTE TO YOU

Keep this book and the sales slip together in a safe place for future reference. It is important for

you to save your sales receipt showing the date of purchase. Proof of purchase will assure

you of in-warranty service.

Thank you for buying a CROSLEY®appliance.

To ensure that you enjoy years of trouble-free operation, we developed this Use and Care Guide. It is full of

valuable information about how to operate and maintain your appliance properly and safely. Please read it

carefully.

Also, please complete and mail the Product Registration Card provided with your appliance. The card helps

us notify you about any new information on your appliance.

Please record your model’s information.

Whenever you call to request service for your

appliance, you need to know your complete model

number and serial number. You can find this

information on the model and serial number plate (see

the diagram in the “Parts and Features” section).

Please also record the purchase date of your

appliance and your dealer’s name, address, and

telephone number.

Model Number ______________________________

Serial Number ______________________________

Purchase Date ______________________________

Dealer Name ________________________________

Dealer Address ______________________________

Dealer Phone ________________________________

1-800-253-1301

The Consumer Assistance Center number is toll free.

WASHER SAFETY

IMPORTANT SAFETY INSTRUCTIONS

WARNING: To reduce the risk of fire, electric shock, or injury to persons when using the

washer, follow basic precautions, including the following:

•Read all instructions before using the

washer.

•Do not wash articles that have been

previously cleaned in, washed in, soaked

in, or spotted with gasoline, dry-cleaning

solvents, other flammable, or explosive

substances as they give off vapors that

could ignite or explode.

•Do not add gasoline, dry-cleaning sol-

vents, or other flammable, or explosive

substances to the wash water. These

substances give off vapors that could

ignite or explode.

•Under certain conditions, hydrogen gas

may be produced in a hot water system

that has not been used for 2 weeks or

more. HYDROGEN GAS IS EXPLOSIVE.

If the hot water system has not been

used for such a period, before using the

washing machine, turn on all hot water

faucets and let the water flow from each

for several minutes. This will release any

accumulated hydrogen gas. As the gas is

flammable, do not smoke or use an open

flame during this time.

SAVE THESE INSTRUCTIONS

•Do not allow children to play on or in the

washer. Close supervision of children is

necessary when the washer is used near

children.

•Before the washer is removed from

service or discarded, remove the lid.

•Do not reach into the washer if the tub or

agitator is moving.

•Do not install or store the washer where it

will be exposed to the weather.

•Do not tamper with controls.

•Do not repair or replace any part of the

washer or attempt any servicing unless

specifically recommended in this Use and

Care Guide or in published user-repair

instructions that you understand and have

the skills to carry out.

•See Installation Instructions for grounding

requirements.

You will be killed or seriously injured if you don’t

follow instructions.

You can be killed or seriously injured if you don’t

follow instructions.

Your safety and the safety of others is very important.

We have provided many important safety messages in this manual and on your appliance. Always read and

obey all safety messages.

This is the safety alert symbol.

This symbol alerts you to hazards that can kill or hurt you and others.

All safety messages will be preceded by the safety alert symbol and the word “DANGER” or

“WARNING.” These words mean:

wDANGER

wWARNING

All safety messages will identify the hazard, tell you how to reduce the chance of injury, and tell you what

can happen if the instructions are not followed.

PARTS AND FEATURES

6 Cycle

•

2 Speed Motor

SUPER WASH

PERMANENT

PRESS

SOAK

SPIN

RINSE

OFF

SPIN

RINSE SPIN

PAUSE

HEAVY

NORMAL

PULL START PUSH STOP

OFF

Heavy Duty

Temperature

WASH

RINSE

COLD

WARM

COLD HOT

COLD

SMALL EXTRA

LARGE

Water Level

REGULAR

10 6

RINSE

SPIN

OFF

20 DELICATES

Extra Large Capacity

Cycle control knob

(includes temperature

selections)

(pp. 5-8)

Model and serial

number label

(under lid)

Basket

Tub

Water level

selector

(p. 5)

Agitator

Self-cleaning

lint filter

(bottom of

washer basket)

(p. 9)

STARTING YOUR WASHER

USING YOUR WASHER

1. Measure detergent and pour it into the

washer. If desired, add powdered or liquid

color-safe bleach.

2. Drop a sorted load of clothes loosely into your

washer.

•Load evenly to maintain washer balance.

•Mix large and small items. See the “Loading”

section.

3. Close the washer lid.

4. Turn the Water Level selector to the correct

setting for your wash load and the type of fabric

being washed.

•Choose a water level that allows the load to

move freely. See “Loading” later in this section.

•Change the setting after the water has started

filling by turning the selector to a different

setting.

continued on next page

wWARNING wWARNING

Electrical Shock Hazard

Plug into a grounded 3 prong outlet.

Do not remove ground prong.

Do not use an adapter.

Do not use an extension cord.

Failure to follow these instructions can

result in death, fire, or electrical shock.

Fire Hazard

Never place items in the washer that are

dampened with gasoline or other

flammable fluids.

No washer can completely remove oil.

Do not dry anything that has ever had any

type of oil on it (including cooking oils).

Doing so can result in death, explosion,

or fire.

5. Set the wash/rinse Temperature selector to the

correct setting for the

type of fabrics and soils

being washed.

•Use the warmest water safe for fabric.

•Follow garment label instructions.

HOT: 111°F (44°C) or above.

– Whites and pastels.

– Heavy and greasy soils.

WARM: 90 to 110°F (32 to 43°C).

– Bright colors.

– Moderate to light soils.

COLD: 70 to 90°F (21 to 32°C).

– Colors that bleed or fade.

– Light soils.

Temperature

WASH

RINSE

COLD

WARM

COLD HOT

COLD

USING YOUR WASHER

STARTING YOUR WASHER (CONT.)

8. (OPTIONAL STEP) If desired, add measured

liquid chlorine bleach after the washer starts

agitating. See “Adding Liquid Chlorine Bleach”

later in this section.

9. (OPTIONAL STEP) If desired, add measured

liquid fabric softener to the rinse water. See

“Adding Liquid Fabric Softener” later in this

section.

NOTE: To stop the washer at any time, push in

the Cycle Control knob. To restart the washer,

close the lid (if open) and pull out the Cycle

Control knob.

Loading suggestions

For these suggested full-sized loads, set the Water Level selector to the highest water level setting.

EXTRA LARGE CAPACITY WASHERS

Heavy Work

Clothes

2 pair pants

3 shirts

3 pair jeans

1 coverall

Knits

2 slacks

2 blouses

4 shirts

4 tops

2 dresses

Permanent

Press

1 double sheet

1 tablecloth

1 dress

1 blouse

2 slacks

3 shirts

2 pillowcases

Mixed Load

2 double or

1 king size sheet(s)

4 pillowcases

6 T-shirts

6 pair shorts

2 shirts

2 blouses

6 handkerchiefs

Towels

8 bath towels

8 hand towels

10 wash cloths

1 bath mat

Delicates

2 camisoles

4 slips

4 panties

2 bras

2 nighties

6. Push in the Cycle Control knob and turn it clock-

wise to the desired

wash cycle. See

“Selecting a cycle and

time” later in this

section.

7. Pull out the Cycle Control knob to start the

washer.

USING YOUR WASHER

Delicates cycle

The Delicates cycle features low-speed agitation for

gentle soil removal from delicate items and wash-

able knits. Low spin speeds minimize wrinkling.

Select this 6-minute cycle to clean lightly to moder-

ately soiled loads.

Soak cycle

The Soak cycle features brief periods of agitation

and soak time to remove heavy soils and stains

that need pretreatment.

• Use warm water when soaking laundry. Hot water

can set stains.

• Use the amount of detergent or presoak additive

recommended by the manufacturer.

• After the Soak cycle ends, add detergent and set

a new wash cycle.

Normal cycle

The Normal cycle features high-speed agitation

followed by a brief period of low-speed agitation for

cleaning cottons and linens. High spin speeds

shorten drying time. Select 10 (Regular) or 14

(Heavy) minutes of wash time, depending on

whether your load is moderately or heavily soiled.

Super Wash – Select this 18-minute wash for

heavily soiled loads that need maximum soil

removal. Use two times the recommended amount

of detergent for this cycle.

Permanent Press cycle

The Permanent Press cycle starts with high-speed

agitation then steps down to low-speed agitation for

cleaning permanent press blends and synthetic

fabrics. To minimize wrinkling, this cycle features a

cool-down rinse and a low-speed final spin. Select

6 or 10 minutes of wash time, depending on

whether your load is lightly or moderately soiled.

SELECTING A CYCLE AND TIME

This section describes the available wash cycles

and will help you make the best cycle selections

for your wash loads. Each cycle is designed for

different types of fabric and soil levels.

•The washer pauses briefly throughout each cycle.

These pauses are normal. Refer to “Understanding

normal washer sounds” to learn more about the

sounds you may hear during a wash cycle.

•Refer to “Understanding what happens in each

cycle” later in this section to learn what happens

during a wash cycle.

SUPER WASH

PERMANENT

PRESS

SOAK

SPIN

RINSE

OFF

SPIN

RINSE SPIN

PAUSE

HEAVY

NORMAL

OFF

REGULAR

10 6

RINSE

SPIN

OFF

20 DELICATES

USING YOUR WASHER

ADDING LIQUID FABRIC SOFTENER

•Too much fabric softener can make some items

(diapers and towels) nonabsorbent. If this

happens, use less fabric softener or do not use it

every time.

•Always dilute fabric softener with 1⁄2to 1 cup (125

to 250 mL) warm water. Undiluted fabric

softener can stain fabrics.

•Add diluted fabric softener only in the final rinse.

•Fabric softener should not be mixed with other

laundry products because greasy stains may

form. If stains form, remove them by wetting the

stain and rubbing with liquid detergent or a bar

of soap. Rewash the stained item.

ADDING LIQUID CHLORINE BLEACH

Always measure liquid chlorine bleach. Do not

guess. Never use more than 1 cup (250 mL) for a full

load. Follow manufacturer’s directions for safe use.

Use a cup with a pouring spout to avoid spilling.

1. Let the washer fill and begin agitating

the load.

2. Add bleach to the wash cycle so it can be

removed in the rinse cycle. Pour bleach around

the agitator, not directly on the load.

•Follow directions on care labels. Do not use

chlorine bleach on wool, silk, spandex, acetates,

or some flame-retardant fabrics.

•When soaking with chlorine bleach, add detergent

to soak water.

NOTE: Undiluted bleach will damage any fabric it

touches. The damage appears as rips, holes, tears,

or color loss and may not show up until several

washings later.

RINSE/DRAIN AND SPIN

Rinse and Spin feature

When using extra detergent for heavily soiled

clothes, or washing special-care items, you may

find an extra rinse and spin is needed.

•For an additional rinse and spin, push in the

Cycle Control knob and turn it clockwise to any

of the Rinse settings. The washer fills to the

selected load size, agitates, drains, and spins.

Drain and Spin feature

A drain and spin may help shorten drying times for

some heavy fabrics or special-care items by

removing excess water.

•For a drain and spin, push in the Cycle Control

knob and turn it clockwise to any of the Spin

settings. Then pull out the Cycle Control knob.

The washer drains, then spins.

USING YOUR WASHER

UNDERSTANDING NORMAL WASHER SOUNDS

During drain

If water is drained quickly from your washer

(depending on your installation), you may hear air

being pulled through the pump during the end of

draining.

After drain and before spin

When the cycle changes from draining to spinning,

you may hear gears engaging.

Your new washer may make sounds your old one

didn’t. Because the sounds may be unfamiliar, you

may be concerned about them. Don’t be; most of

them are normal.

The following describes some of the sounds you

may hear and what causes them.

Your washer has a self-cleaning lint filter at the bot-

tom of the basket. Wash and rinse water flow over

the filter during agitation, separating the lint from

the water. The lint spins out of the system during

the spin part of the cycle.

If your washer drains into a tub, remove any lint

collected in the tub or strainer.

Self-cleaning

lint filter

Basket

interior

SELF-CLEANING LINT FILTER

USING YOUR WASHER

UNDERSTANDING WHAT HAPPENS IN EACH CYCLE

When the Cycle Control knob is set to a number and

pulled out, the washer fills (to the selected water

level) before agitation and timing start. The washer

begins agitating immediately after filling; agitation

occurs with the washer lid up or down.

After agitation starts, the Cycle Control knob turns

clockwise until it points to an Off area and the

cycle ends.

NOTE: The washer pauses briefly throughout

each cycle. These pauses are normal for washer

operation.

Sequence of cycles

Fill

▼

Rinse

▼

Drain-No agitation

▼

Spin-Spray rinse

▼

Spin

▼

Off

Fill

▼

Wash selected time

▼

Drain*

No agitation

▼

Spin

▼

WASH RINSE

*The Permanent Press cycle partially drains, fills, agitates

briefly, and drains.

Table of contents

Other Whirlpool Washer manuals

Whirlpool

Whirlpool LSC9355BQ1 User manual

Whirlpool

Whirlpool PEWETER 3RGSC9400RL0 User manual

Whirlpool

Whirlpool 6LSC9255BQ2 User manual

Whirlpool

Whirlpool LA6053XS User manual

Whirlpool

Whirlpool LCE4332PQ0 User manual

Whirlpool

Whirlpool LSQ9110KQ1 User manual

Whirlpool

Whirlpool LASOOXP User manual

Whirlpool

Whirlpool AWM 243 User manual

Whirlpool

Whirlpool FSCR90410 Installation and operation manual

Whirlpool

Whirlpool LA5700XS User manual

Whirlpool

Whirlpool WVP9000S User manual

Whirlpool

Whirlpool FWFBE71683 User manual

Whirlpool

Whirlpool Cabrio WTW8700EC User manual

Whirlpool

Whirlpool Duet Steam WFW9750WL Assembly instructions

Whirlpool

Whirlpool W10275729D User manual

Whirlpool

Whirlpool Duet steam WFW9640XW Assembly instructions

Whirlpool

Whirlpool LA53OOXP User manual

Whirlpool

Whirlpool LA531OXP User manual

Whirlpool

Whirlpool AWO/D 43136 User manual

Whirlpool

Whirlpool W10682798A-SP User manual

Whirlpool

Whirlpool Duet WFW9200SQ00 Troubleshooting guide

Whirlpool

Whirlpool AWO 9561 User manual

Whirlpool

Whirlpool WFW9050XW User manual

Whirlpool

Whirlpool LA5600XM User manual

Popular Washer manuals by other brands

Tricity Bendix

Tricity Bendix AW 1000 W Operating & installation instructions

Panasonic

Panasonic NA-F60L5WRB operating instructions

GE WSLP1500 Dimensions and installation information

Electrolux

Electrolux EWF1284EDW Service manual

Bosch

Bosch WAN2829BSN User manual and installation instructions

LG TV2516DV3B owner's manual

LG TH2517DSAV owner's manual

VESTEL

VESTEL CMH-XL 7510 TE user manual

AEG

AEG 74335 User information

Johnson

Johnson JWF721A user manual

Beko

Beko WTE7604XLW0 owner's manual

Danby

Danby DTT100A1WDB Owner's use and care guide

Amica

Amica WA 14 Ex operating instructions

Daewoo

Daewoo DWD-F1222 instruction manual

Bosch

Bosch WAS28461AU instruction manual

Miele

Miele PW 6080 Vario manual

Finlux

Finlux FLX108CF220 user manual

Beko

Beko WKB 51231 PTMA manual
