Whirlpool LER3622PQ1 User manual

BULKHEAD PARTS

For Model: LER3622PQ1

(Designer White)

11−04 Litho in U.S.A. (djc) Part No. 8180578

COMPACT

ELECTRIC DRYER

BULKHEAD PARTS

For Model: LER3622PQ1

(Designer White)

8180578

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 Literature Parts

8562114 Use & Care Guide

9830513 Label, Operating

Instructions

9831749 Label, Wiring

Diagram

2 8566189 Air Duct Assembly

3 3390646 Screw, 8−18 x 5/16

4 3398128 Thermostat,

Internal Bias

5 3403607 Thermal Limiter

195 F (91C)

6 339956 Seal

7 696426 Wheel, Blower

8 694419 Buzzer, Mini

9 489463 Screw, 8−18 x 5/8

10 696419 Scroll, Fan

11 695931 Bulkhead

12 3398161 Clip

13 3401380 Box, Heater

14 343641 Screw, 10−16 x 1/2

15 359702 Cap, Screw

16 9830393 Clip

17 3404154 Thermostat, 200 F

(93.3 )

18 348197 Washer, Support

19 8066086 Drum Hole

Plug

20 94614 Terminal

22 3403586 Heater Element

23 279457 Wire Kit (For

Heater Element

Wiring Harness

Repair)

24 3936144 Connector

3−Circuit

25 3397269 Connector, Timer

26 345325 Gusset (2)

27 3359452 Nut, 3/8−16

28 695943 Drum Assembly

29 345648 Seal, Rear

30 97787 Screw, 11−16 x 3/4

31 685207 Baffle, Drum (3)

32 3394508 Ring, Bearing

33 3395683 Housing,

Connector

34 690997 Ring, Tri

35 3397588 Roller, Support

36 3399506 Shaft, L.H.

37 3399507 Shaft, R.H.

38 90767 Screw, 8−18 x 3/8

39 3401077 Resistor

Assembly

41 8531964 Lint Screen

43 8531967 Cover, Lint

Screen

44 342202 Screw, 10−16 x 1/4

46 8066094 Seal

48 8299821 Harness, Wiring

50 3388703 Washer, Support

55 696302 Shield, Exhaust

CABINET PARTS

For Model: LER3622PQ1

(Designer White)

8180578

CABINET PARTS

For Model: LER3622PQ1

(Designer White)

8180578

Illus. Part

No. No. DESCRIPTION

1 343641 Screw, 10−16 x 1/2

2 695201 Panel, Rear

3 348726 Base Assembly

4 660658 Clamp, Motor (2)

5 8538265 Motor, 60 Hz.

6 697776 Screw, Ground

(10−32 x 5/8)

7 696541 Base, Motor

8 8066084 Bushing, Snap

9 691366 Idler & Pulley

Assembly

10 3397659 Block, Terminal

11 3393657 Retainer, Belt

12 8066051 Pulley, Motor

60 Hz.

13 3393008 Screw, 10−16 x 1/2

14 3396795 Cover, Terminal

Block

15 8066064 Belt, Drive

16 348705 Panel, Side (2)

17 690259 Support,

Terminal Block

18 3406104 Door Switch

Assembly

19 697773 Screw, 6−20 x 7/8

20 693943 Front Panel

21 685203 Clip, Felt Pad

22 8066123 Seal & Bearing

Assembly

23 345670 Lock, Top

24 3389441 Catch, Door

25 348023 Hinge & Pin

Assembly (2)

26 696144 Strike, Panel

27 3390734 Seal, Door

28 694091 Screw, 8−18 x 3/8

29 695656 Door, Rear

30 348205 Door, Front

31 8562104 Handle, Door

32 3390631 Screw, 10−16 x 3/8

33 233550 Foot (4)

34 3394083 Clip (2)

35 98234 Clip, Panel

TOP AND CONSOLE PARTS

For Model: LER3622PQ1

(Designer White)

8180578

Illus. Part

No. No. DESCRIPTION

1 345703 Top

2 307563 Rivet, Pop

3 3390631 Screw, 10−16 x 3/8

4 8563882 Timer, 60 Hz.

5 Timer Motor

(Not Serviceable)

6 348171 Bracket, Timer

7 311865 Screw, 8−32 x 7/32

8 3390646 Screw, 8−18 x 5/16

9 8562102 Panel, Control

10 8544955 Timer Knob

Assembly

11 3977456 Switch,

Push−To−Start

12 8544939 Knob,

Push−To−Start

13 343641 Screw, 10−16 x 1/2

14 3406860 Bracket,

Front Panel

15 8536939 Clip, Spring

OPTIONAL PARTS (NOT INCLUDED)

For Model: LER3622PQ1

(Designer White)

8180578

Illus. Part

No. No. DESCRIPTION

PAINT, TOUCH−UP (1/2oz.)

72017 White

PAINT, PRESSURIZED SPRAY

(12 oz.)

350938 Primer, Gray

350930 White

PAINT, BULK (1 qt.)

799344 White (Uncut)
