Wharfedale Pro Titan Sub A12 User manual

Professional Sound Systems

Service Manual

Wharfedale Professional

IAG House, Sovereign Court, Ermine Business Park, Huntingdon, Cambs, PE29 6XU, England

www.wharfedalepro.com

SPECIFICATION

ASSEMBLY SKETCH

SCHEMATIC DIAGRAM

ASSEMBLY PARTS LIST

ELECTRONIC PARTS LIST

SCHEMATIC DIAGRAM

ELECTRONIC PARTS LIST

Titan Sub A12

1.SPECIFICATIONS

System Type Reflex subwoofer

Frequency Response (+/-3dB) 55-200Hz

Enclosure Material 15mm MDF

Enclosure Colour Grey

Frame material steel frame

Size (mm / inches) 305mm / 12

Coil Size (mm / inches) 64.26mm / 2.5

Impedance 4 ohm

Speaker Pole Adapter Yes

Inputs A & B - Type / Connection Balanced Line Level inputs via two combo

connectors

Output A & B Type / Connection Balanced Line Level inputs via two combo

connectors

Input Sensitivity 0.37V

High Pass Frequency Selection 150Hz

Phase Switch Selection 0/180

Crossover Frequency 80Hz/100Hz/120Hz/150Hz/180Hz/200Hz (adjustable)

Speaker Level Input Impedance

Speaker Level Input Connection

Amplifier Power:

Continuous 250W

Peak 500W

Power On Indicator LED

Power On Protection Power switch on / off mute

Thermal Protection Amplifier shutdown, auto reset

Low Line Voltage Shut Down 60% Nominal line voltage

Driver Protection Independent LF limiters

DC Protection Yes

Short Protection Yes

Clip Limiter: Turns on approx 250W output

Limiter Indicator Red LED

Power Indicator Blue LED

Dimensions (mm / inches):

Height 360.0mm/14.2

Width 493.0mm/19.4

Depth 431.0mm/16.9

Weight (Net) kg / lbs 22.31kg /49.0lbs

Weight (Gross) kg / lbs 26.

26kg / 57.8lbs

2.ASSEMBLY SKETCH

3.SCHEMATIC DIAGRAM

4.SCHEMATIC DIAGRAM

5.SCHEMATIC DIAGRAM

6.SCHEMATIC DIAGRAM

7.SCHEMATIC DIAGRAM

8.ASSEMBLY PARTS LIST

R/N P/N PART NAME DESCRIPTION QTY

1 537-4002300801AR SCREW MP(+)4*30 10

2 ZC-47300-07R AMPLIFIER 1

3 344-2142400001R CABINET 1

4 534-6001400801AR SCREW MK(+)6*40 4

5 259-2142500001R SPEAKER STAND ADAPTER 1

6 ZD-70302-01R WOOFER 1

7 537-5001250801AR SCREW MT(+)5*25 8

8 310-2142400001R FRONT GRILLE 1

9 313-2104900001R LOGO 1

10 226-0380001515R RUBBER FOOT 4

11 558-4001258061AR SCREW M4*25 4

12 243-2009000001R HANDLE 2

13 523-4013250601R SCREW 8

9.ELECTRONIC PARTS LIST

R/N P/N PART NAME DESCRIPTION QTY LOCATION

1 019-0556122001R POWER LED BLUE 1

2 031-4200510121R FUSE T3.15A 250V 5*20mm 1

3 042-1003005001R POWER SWITCH RF-1003TV-5AC250V 1

4 044-2600000000R POWER SOCKET RF-2004 1

5 055-0311022133R RIBBON CABLE 11PIN L=300MM 1

6 055-0402030333R UL1617 18# 2PIN 1

7 055-1303600333R C-022-4 L=600 24# 1

8 060-0180120100R WIRE 1617#18 BROWN 1

9 060-0180120300R BLUE 18# C-022-8 1

10 060-0180151004R C-022-6 L=150 18# 1

11 071-1100000000R CABLE TIES 100MM YJ-100 8

088-1472414500R POWER BOARD 1

1 001-1002203010R RESISTOR 1K 1/8W F 1 R8

2 001-1003203010R RESISTOR 10K 1/8W F 5 R1 2 9 12 14

3 001-1803203010R RESISTOR 18K 1/8W F 3 R11 13 16

4 001-2203203010R RESISTOR 22K 1/8W F 1 R10

5 001-3300103050R RESISTOR 33 OHM 1/8W J 2 R17 18

6 001-5602103050R RESISTOR 5.6K 1/8W J 1 R20

7 001-9102203010R RESISTOR 9.1K 1/8W F 1 R19

8 006-1004061194R CAPACITOR 10uF 100V 1 C9

9 006-2291051163R CAPACITOR 2.2UF/50V 10% 1 C35

10 006-4700051251R CAPACITOR 47uF 35V 1 C1

11 014-1020100002R CAPACITOR AMZ 0.001UF 50V 5% 2 C3 7

12 014-4740311028R CAPACITOR MKS2 470nF 100V 10% 1 C8

13 017-1124000000R IC IR2153D DIP-8 IR 1 U1

14 018-3408050115R TRANSISTOR SS8050 TO-92 3 Q1 3 4

15 018-3408550115R TRANSISTOR SS8550C TO-92 1 Q2

16 057-2545011241R JACK 24P BLACK 0.5 CON1

17 067-1104148000R DIODE IN4148 6 D1 34678

18 067-2200107000R DIODE HER107 JAL 1 D5

19 067-3305246000R ZENER 16V 1/2W IN5246 2 ZD1 2

20 007-0108062060R CAPACITOR 0.1UF 50V 3 C2 5 6

21 053-1407001676R POWER PCB FR-4 1.6 10Z 1

088-1472415500R AMP BOARD 1

1 057-2545011241R JACK 24P BLACK 0.5 CON3

2 002-1002032010R RESISTOR 1K 1/8W 1% 0805 1 R41

3 002-1003032010R RESISTOR 10KOHM 1/8W 1% 0805 2 R37 42

4 002-2003032010R RESISTOR 20KOHM 1/8W 1% 0805 1 R52

5 002-2003403010R RESISTOR 2K 0805 1% 0.125W 1 R36

RIBBON CABLE
