Vivo STAND-V002V User manual

   

Instruction Manual

Email: [email protected]

Live chat: www.vivo-us.com

Call: 1-800-371- 6 4

-   

 

phillips screwdriver

 

Scan the QR code with your mobile device or follow the link

to helpful videos and specifications related to this product.

 (x1)

Pole

 (x1)

Clamp

 (x2)

Arm wit VESA

Plate

 (x1)

Grommet Base

 (x1)

Bolt

 (x1)

Support Plate

(x1)

M1 Waser

! (x1)

Sprin Waser

" (x2)

Arm

# (x2)

Wire Co er

$ (x2)

Axis Co er

% (x2)

Stopper Rin

 (x6)

M4x6 Bolt

& (x2)

M1x1$ Bolt

 (x1)

Allen Wrenc

 (x8)

M4x3

(x8)

M4 Spacer

 (x2)

Cable Clip

 (x2)

M6x12 Bolt

' (x8)

M4x12 Tumb

Screw

( (x1)

Wrenc

- -)*++,, -.+*+ ,,

* 

Attach VESA plate arms (C) to arms (I) with screws (N) and axis covers

(K) as shown in diagram. Attach wire covers (J) with screws (M) as

shown in diagram. (Optional – Skip this step for shorter arms.)

* /

Slide one stopper ring (L) onto pole (A) and tighten at desired height

using allen wrench (P). Slide one assembled arm onto pole (A). Slide

second stopper ring (L) onto pole (A) and tighten at desired height

using allen wrench (P). Slide second assembled arm onto pole (A).

.01 *

* 2

&*  34 .* "

Attach pole (A) to clamp (B) at desired depth with bolts (O) using allen

wrench (P).

Remove clamp base and screws from

pole. Attach grommet base (D) to

pole (A) using previously removed

screws. Position the pole with base

on mounting surface and secure

using support plate (F), bolt (E), M10

washer (G) and spring washer (H). If

no grommet hole is present, drill 3/8”

(10mm) hole through the mounting

surface.

&*  ..  "

* 5

&*    

Attach monitors to VESA plates using thumb screws (Q).

&*  ,  

Attach monitors to VESA plates using screws (R) and spacers (S).

* 6

Remove cable covers from spring arms. Run cables through covers

and reinstall to arms. Install cable clips (T) to back of pole and

manage cables.

Adjust arm swivel joints by tightening or loosening grub screws on

each joint with small Allen Wrench (P).

* 7

Adjust arm tension by turning screw on top of center joint with large

Allen Wrench (P). Clockwise reduces tension, counter-clockwise

increases tension. The tension should be just enough to hold your

monitor in place without lifting itself up.

If you do not understand these directions, or if you have any

doubts about the safety of the installation, please call a

qualified technician. Check carefully to make sure there are no

missing or defective parts. Improper installation may cause

damage or serious injury. Do not use this product for any

purpose that is not explicitly specified in this manual. We

cannot be liable for damage or injury caused by incorrect

assembly or inappropriate use.

Email: help@vivo-us.com

Live chat: www.vivo-us.com

Call: 1-800-371- 6 4

For more VIVO products, check out our

website at

www.vivo-us.com.

If any parts are received damaged or defective, please contact

us. We are happy to replace parts to ensure you have a fully

functioning product.

81 9

  

Last updated: 0 /23/18 4
