Vivo STAND-V002C User manual
Monito an Laptop
Des Mount
Instruction Manual
Email: help@vivo-us.com
Live chat: www.vivo-us.com
Call: 1-800-371- 6 4
-Moel STAND V002C
Tools Requie
phillips screwdriver
Pacage Contents
1
Scan the QR code with your mobile device or follow the link
to helpful videos and specifications related to this product.
- -https vivo us.com poucts stan v002c
a (x1)
Pole
b (x1)
“ C Clamp
c (x1)
“ C Clamp Brace
(x1)
Swivel Arms
e(x2)
VESA Plate
f (x3)
M5x14
g (x2)
M x12
h (x2)
Nut
i (x1)
M10
j (x1)
Support Plate
(x1)
M10 Washer
l (x1)
Sprin' Washer
m (x1)
Grommet Base
Plate
n2 (x3)
Wire Clip
o (x1)
Allen Key
(x )
M4x30
s(x )
M4 Spacer
t (x1)
Laptop Tray
n1 (x1)
Wire Clip
p (x1)
Wrench
q (x )
M4x12
v (x4)
M4 Nut
u (x4)
M4x10
w1 (x1)
Soft Pad
w2 (x1)
Soft Pad
Assembl) Steps
2
Step 1 Install the Pole to the Destop
Option A Des Clamp Installation
Install the “C” Clamp Brace (c) to the Pole (a)
using 3pcs M x14 Bolts (f), and tighten using
the Allen Key (o), see Figure 1. Attach Soft Pad
(w1) to the “C” Clamp Brace (c), see Figure 2.
Install the “C” Clamp (b) to the pole assembly
according to the thickness of the desktop. The
thickness can be changed to three positions.
Connect it using 2pcs M8x12 Bolts (g), and
tighten using the Allen Key (o). Tighten the “C”
Clamp (b) to the desktop using the plastic
knob, see Figure 3.
Option B Existing Gommet Base Installation
If the existing grommet hole comes with a
plastic protector, remove it to ensure a flat
surface before installing the desk mount.
Install the Grommet Base Plate (m) to the
Pole (a) using 3pcs M x14 Bolts (f), and
tighten using the Allen Key (o), see Figure 4.
Attach Soft Pad (w2) to the Grommet Base
Plate (m), see Figure . Position the Pole (a)
on the mounting surface and secure using
the Support Plate (j), M10 Washer (k), Spring
Washer (l) and M10 Bolt (i). Fasten the M10
Bolt using provided Wrench (p), see Figure 6.
Option C Self Dille Gommet Base Installation
Position the Pole (a) on the mounting
surface and mark the center hole. Drill a
3/8" (10mm) diameter hole at the marked
position through the mounting surface.
Install the Grommet Base Plate (m) to the
Pole (a) using 3pcs M x14 Bolts (f), and
tighten using the Allen Key (o), see Figure
7. Attach Soft Pad (w2) to the Grommet
Base Plate (m), see Figure 8. Position the
Pole (a) on the mounting surface and
secure using the Support Plate (j), M10
Washer (k), Spring Washer (l) and M10 Bolt
(i). Fasten the M10 Bolt using provided
Wrench (p), see Figure 9.
j
i
k
l
a
m
f
Figure 4
Figure 6
w2 Figure 5
j
i
k
l
a
m
f
Figure 7
Figure 9
w2
Figure 8
Step 2 Install Am to the Pole
Install Swivel Arms (d) to the Pole (a).
Fasten the bolt with supplied Allen Key
(o). Attach the Wire Clip (n1) to the Pole
(a) and (n2) to the Swivel Arms (d).
Step 3 Attach the VESA Plate to the Laptop Ta) o
Monito
Fo Laptop Fo Monito with Flat Bac
Fo Monito with
Cuve o Recesse
Bac
e
g
o
b
Plastic Knob
a
c
f
Figure 1
Figure 3
w1
Figure 2
o
3
Step 5 Mae the Necessa) Ajustments
Tighten the bolt with the supplied Allen Key (o) to fix the tilt angle.
Use the supplied Allen Key
(o) to make the necessary
adjustments
Step 4 Slie the Monito onto the Hea of Swivel
Am
Slide the monitor onto the head of Swivel Arm (d) as shown in the diagram.
Install the security Nut (h). Make sure the security nut is installed before you rotate
the monitor.
o
If you do not understand these directions, or if you have any
doubts about the safety of the installation, please call a
qualified technician. Check carefully to make sure there are no
missing or defective parts. Improper installation may cause
damage or serious injury. Do not use this product for any
purpose that is not explicitly specified in this manual. We
cannot be liable for damage or injury caused by incorrect
assembly or inappropriate use.
Email: help@vivo-us.com
Live chat: www.vivo-us.com
Call: 1-800-371- 6 4
For more VIVO products, check out our
website at
www.vivo-us.com.
If any parts are received damaged or defective, please contact
us. We are happy to replace parts to ensure you have a fully
functioning product.
Safet) Waning
Contact us at
Last updated: 0 /11/2018 4
Step 6 Manage the Wies an Stoe the Allen Ke)s
