Vivo MOUNT-MSIG24 User manual

Popular Rack & Stand manuals by other brands

Salamander

Salamander Acadia AC/W/L400/WH Assembly instructions

Fohhn

Fohhn VAT-09 Mounting instruction

ricoo

ricoo FS0522 quick start guide

AMSOIL

AMSOIL BMK-22 Installation and service instructions

Kargo Master

Kargo Master 48220 installation guide

Milestone AV Technologies

Milestone AV Technologies SIMPLICITY SLF2 installation instructions

ricoo

ricoo S1222 installation instructions

Ready-Set-Mount

Ready-Set-Mount RSMCM602 instruction manual

VidaBox

VidaBox VB MNT FFS2 installation guide

Welch Allyn

Welch Allyn 48960 Assembly instructions

Arkon

Arkon CM035-ST-2 installation instructions

PROEL

PROEL PLWIN60C user manual

Agilent Technologies

Agilent Technologies E2609B installation guide

Mustang

Mustang MV-ARM4 installation guide

Mounting Solutions

Mounting Solutions WRM-320 manual

Pyle

Pyle PMKSPAD1 manual

ShelterIt

ShelterIt 21208 installation instructions

SPL

SPL RackPack?4 1040 manual

VESA Adapter for Compatible Viotek

and MSI Monitors

Scan the QR code with your mobile device or follow the link

for helpful videos and specifications related to this product.

Instruction Manual

https://vivo-us.com/products/mount-msig24

SKU: MOUNT-MSIG24

[email protected]om www.vivo-us.com 309-278-5303

Chat live with an agent!

GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST

2

PACKAGE CONTENTS

TOOLS NEEDED

WARNING!

Phillips

Screwdriver

If you do not understand these directions, or if you have any doubts about the safety of the

installation, please call a qualified technician. Check carefully to make sure there are no missing or

defective parts. Improper installation may cause damage or serious injury. Do not use this product

for any purpose that is not explicitly specified in this manual. Do not exceed weight capacity.

We cannot be liable for damage or injury caused by improper mounting, incorrect assembly or

inappropriate use.

WARNING: CHOKING HAZARD

SMALL PARTS - NOT FOR CHILDREN UNDER 3 YEARS. ADULT SUPERVISION IS REQUIRED.

A (x1)

VESA Adapter

B(x1)

M5x45

Thumbscrew

C(x1)

Pad

D(x4)

M4x12

Thumbscrew

E(x4)

Washer

3

ASSEMBLY STEPS

STEP 1

Insert M5x45mm thumbscrew (B) into the

upper hole of the VESA adapter (A) until

approximately 1/2” of thread is visible on the

front, then place the pad (C) on the end of

the screw.

STEP 2

Attach VESA adapter (A) to the monitor using original screws from the monitor’s post. Tilt the adapter

down fully, and tighten the M5x45 thumbscrew (B) until the pad (C) presses against the back of the

monitor.

STEP 3

Mount the monitor with adapter to your

VESA mount using the M4x12 thumbscrews

(D) with washers (E).

LAST UPDATED: 03/05/2020
