Unitron Quantum User manual
Quantum
micro BTE
(behind-the-ear)
hearing aid guide
Thank you
Thank you for choosing Unitron hearing aids.
At Unitron, we care deeply about people with
hearing loss. We work closely with hearing
healthcare professionals to make advanced,
purpose-driven solutions available to everyone.
Because hearing matters.
Your hearing aids
Hearing healthcare professional: _____________
____________________________________
Telephone: __________________________________
Model: ______________________________________
Serial number: _______________________________
Replacement batteries: Size 312
Warranty: ___________________________________
Program 1 is for: ______________________________
Program 2 is for: _____________________________
Program 3 is for: _____________________________
Program 4 is for: _____________________________
Date of purchase: _____________________________
Quick reference
Changing batteries Low battery warning
2 beeps every
30 minutes
312
On/Off
Plus
(+) signs
on off open
Push button
switching programs
volume control; right aid=louder,
left aid=softer
comfort-clarity control; right aid=clarity,
left aid=comfort
Table of contents
Your hearing aids at a glance ...........................................................2
Putting your hearing aids on your ears ............................................4
Turning your hearing aids on and off ............................................. 6
Battery information ......................................................................... 8
Tips for wearing hearing aids for the first time ..............................12
Operating instructions ...................................................................14
Using the telephone...................................................................... 20
Caring for your hearing aids ...........................................................21
Cleaning your hearing aids ........................................................... 22
Signature features of your hearing aids ....................................... 26
Troubleshooting guide .................................................................. 29
Warnings ....................................................................................... 34
Warning to hearing aid dispensers
(to comply with the U.S. Food and Drug
Administration (FDA) regulations) ............................................... 38
Compliance information ................................................................41
Client feedback ............................................................................. 43
Additional notes ............................................................................ 44
2
Your hearing aids at a glance
1 Earhook - your custom made earmold attaches to
your hearing aids using the earhook
2 Microphone - sound enters your hearing aids via
the microphones. Microphone shield - protects
microphones from dirt & debris
3 Push button - switches between listening
programs or changes the volume level or comfort-
clarity, depending on your customized fitting
4 Battery door/on & off - close the door to turn on
your hearing aids, partly open the door to turn off
your hearing aids. Opening the door all the way
gives you access to change the battery
5 Earmold - allows the sound to pass from the
hearing aids to the ear and holds the hearing aids
in place
6 Slim tube - sound travels down the slim tube to
the ear canal
7 Dome - holds the slim tube in place in your ear
canal
8 Retention piece - helps prevent the dome and slim
tube from moving out of the ear canal
3
Your hearing aids at a glance
2
3
2
4
2
3
2
4
1
5
6
8
7
4
Putting your hearing aids on your ears
Your behind-the-ear (BTE) hearing aids may be
color-coded with a small dot on the battery door:
red = right ear; blue = left ear.
BTEs with earmolds
1. Hold the earmold between
your thumb and index finger.
The opening should be
pointing in towards your ear
canal with the BTE resting
upwards over the top of your
ear.
2. Carefully insert the earmold
in your ear. You may need
to twist it slightly to the
back. The earmold should
fit into your ear snugly and
comfortably. Pulling down
and back on your earlobe may help you insert
the earmold into your ear canal more easily.
1.
2.
5
1.
3.
3.
2.
3. Place the hearing aid over
the top of your ear.
BTEs with slim tubes
1. Place the hearing aid over
the top of your ear. The
slim tube should lie flush
against your head and not
stick out.
2. Hold the slim tube where it
attaches to the dome and
gently push the dome into
your ear canal.
3. Place the retention piece
in your ear so it rests at the
bottom of the opening of
your ear canal.
6
Turning your hearing aids on and off
Your hearing aids have a three-position battery
door that acts as an on/off switch and that
allows access to the battery compartment.
1. ON: Close the battery door
fully.
Note: It may take 5 seconds
before the hearing aid turns
on. Your hearing healthcare
provider can additionally
increase the start up delay if
required.
2. OFF: Partially open the
battery door.
off
2.
1.
on
