Moxi
TrueFit quick reference fitting guide
Powered by Era,
™ Moxi™ is a beautiful little CRT which features an open fit
strategy that combines three proprietary technologies: Automatic Program
with SmartFocus,
™ Natural Sound Balance and Pinna Effect. Your clients can
enjoy Moxi attitude with the highest fidelity, most natural sound.
Programming Moxi in TrueFit
This quick reference guide will lead you through the steps of a simplified
fitting for Moxi hearing instruments using Unitron’s TrueFit™ fitting software.
To detect the Moxi hearing instrument(s), choose your desired programming
interface.
• If using iCube, insert the batteries into the Moxi hearing instruments and
close the battery door.
• If using NOAHlink or HI-PRO, open the battery door and insert the
programming cable, using the cable tool, into the Moxi programming port.
Note: Hearing instrument controls, accessories, easy-t, audio streaming and automatic
microphone options are deactivated during programming.
1. Client
a. Information
NOAH
W i t h i n Client, click on Information and enter the client’s experience level
with hearing instruments.
Standalone
W i t h i n Client, click on Information. Click the New
Client button, enter the client’s information and click
Save. Click the Blank Session button to begin a new
session. Specify the client’s experience level with
hearing instruments using the drop down box.
b. Audiogram
If using Standalone TrueFit, click the Audiogram
button. Enter the client’s audiogram and select the
transducer used for audiometry.
When using iCube, insert
a battery into Moxi’s
battery compartment.
When using NOAHlink
or HI-PRO, insert the
programming cable
into Moxi.
Select the client’s hearing instrument experience level.
Choose the icon of the accessory you are pairing.
Select Activate to begin the pairing process.
Within Acoustics, you can configure the receiver type,
ear piece and venting.
2. Instruments
a. Selection
1. W i t h i n Instruments, click on Selection and choose
your desired programming interface from the
drop-down list under the detect button.
2. Click the Detect button. The hearing instrument
model, style, matrix and serial number are
displayed, and the communication status is
updated.
b. Acoustics
1. W i t h i n Instruments, click on Acoustics.
2. Configure the receiver type (xS, xP or xSP), ear
piece and vent characteristics (if applicable) from
the drop down lists for each hearing instrument.
If desired, specify the wire length for record
keeping purposes.
3. For custom earpieces with IntelliVent, enter
the code and the software will automatically
configure the hearing instrument for optimal
venting.
4. Click the Quick Fit button.
c. Accessories
1. W i t h i n Instruments, click on Accessories.
2. Click on the icon of the accessory you are pairing
to the Moxi hearing instrument(s).
3. Click the Activate button to pair the selected
accessory. Follow the on-screen instructions.
Select Detect to connect to the hearing instruments and
display the associated model, style and serial number.
3. Fitting
a. Feedback Optimization
1. W i t h i n Fitting, click on Feedback Optimization.
2. Click the Start feedback test button and follow
the on-screen instructions to perform feedback
optimization for each hearing instrument.
b. Tuning
1. W i t h i n Fitting, click on Tuning to manually fine
tune listening programs. If desired, configure the
adaptation manager, occlusion manager, Soft/
Mod/Loud Controls and MPO/Gain/CR Controls.
Fitting Advice can also be used to suggest and
apply fine tuning solutions.
2. C l i c k Soft/Mod/Loud Controls. From the program
selector list, choose the desired program(s)
to adjust. Select the desired input level (soft,
moderate, loud or all) and frequency region for
adjustment. Increase or decrease settings using
the +/- buttons.
3. C l i c k MPO/Gain/CR Controls. From the program
selector list, choose the desired program(s) to
adjust. Select the desired adjustment (MPO/Gain/
CR) and frequency region for adjustment. Increase
or decrease settings using the +/- buttons.
Perform feedback optimization for each Moxi hearing
instrument.
A/11-040 027-5672-02
For more information about fitting Moxi hearing instruments or
Unitron’s TrueFit fitting software, visit the Help feature within TrueFit.
Within End Fitting, you can view a summary of your fitting.
4. End fitting
W i t h i n End Fitting, you can configure beep
notifications, volume control settings, and push
button configuration, along with other hearing
instrument options.
1. To end the fitting, click on Fitting Summary and
select the Print & Save button.
2. To close the session, click on the Close Session
button.
3. After closing the session:
• If using iCube, restart your hearing
instrument(s) by opening and closing the
battery door(s).
• If using NOAHlink or HI-PRO, remove the
program cable, insert the batteries and close
the battery door.
