GTR BARBECUE
ASSEMBLY, INSTALLATION AND
OPERATION MANUAL
PLEASE READ ALL INSTRUCTIONS BEFORE YOU ASSEMBLE, INSTALL OR OPERATE THIS APPLIANCE.
IMPORTANT
GTRL1, GTRL2, GTRL3, GTRL4, GTRL5, GTRL6
GTRL1SW, GTRL2SW, GTRL3SW, GTRL4SW, GTRL5SW, GTRL6SW.
GTRL1SSWL, GTRL2SSWL, GTRL3SSWL, GTRL4SSWL, GTRL5SSWL, GTRL6SSWL.
THIS MANUAL COVERS THE FOLLOWING MODEL GTR BBQS:
V16.10.2023
1
BBQ PARTS LIST
ASSEMBLY INSTRUCTIONS
- OPTIONAL BBQ BUILT-IN KIT
- BBQ ASSEMBLY
- OPTIONAL GTR BBQ HINGED FLAT LID ASSEMBLY
- OPTIONAL GTR BBQ ROASTING HOOD ASSEMBLY
INSTALLATION INSTRUCTIONS
- LOCATION REQUIREMENTS AND RESTRICTIONS
- DIAGRAMMATIC REPRESENTATIONS OF OUTDOOR AREAS
- GTR BBQ AND WOK CLEARANCES TO COMBUSTIBLE MATERIALS
- BBQ, WOK DIMENSIONS & CUT-OUT DIMENSIONS
- BBQ, WOK DIMENSIONS WITH BUILT-IN KIT & CUT-OUT DIMENSIONS
- BBQ, WOK DIMENSIONS WITH INSULATION JACKET & CUT-OUT DIMENSIONS
- OPTIONAL GTR PRO SERIES CABINET TROLLEY
- GAS CONSUMPTION OF GTR BBQS AND WOKS
- GAS CYLINDER CONNECTION AND LEAK TEST PROCEDURE
- RETICULATED GAS SUPPLY CONNECTIONS
- GAS CONVERSION PROCEDURE FROM LPG (PROPANE) TO NATURAL GAS
OPERATING INSTRUCTIONS
-
LIGHTING INSTRUCTIONS
- MANUAL LIGHTING INSTRUCTIONS
- NEW BBQ ‘BURNING IN’ PROCESS
- PRE-HEATING THE BBQ BEFORE COOKING
- COOKING TIPS
- CLEAN UP
SERVICE AND MAINTENANCE
- TAKING CARE OF THE APPLIANCE
- TROUBLESHOOTING AND SOLUTIONS
WARRANTY
-
WARRANTY PERIOD
- NOT COVERED
- CONDITIONS OF THIS WARRANTY
2
3
4
8
28
31
34
IMPORTANT SAFETY INSTRUCTIONS AND WARNINGS
2
• Tucker GTR BBQs are approved for
outdoor use only.
• Remove all plastic protection lm from
stainless steel components before
assembly.
• Keep this manual for future reference.
• Always clean the grease tray before use
and regularly check the BBQ for excess
grease build up, as damage by grease/
fat res are not covered by warranty.
• Always turn off the gas supply when you
nish cooking.
• A canvas cover for the BBQ will extend its
life and ensure trouble free operation.
• Never place the solid griddle plate above
the charcoal tray, only place the open
grills above the charcoal tray.
• For installation of this BBQ into a cabinet
trolley, refer to the relevant instructions.
• For installation of this BBQ into an
insulation jacket, refer to the relevant
instructions.
• Attend an operating BBQ at all times.
• DO NOT use this appliance indoors or in
any enclosed area.
• DO NOT spray aerosols in the vicinity of
this appliance while it is in operation.
• DO NOT place articles on or against this
appliance.
• DO NOT use or store ammable materials
in or near this appliance.
• Always leak test /check hose connections
after lling cylinders.
• Check cylinder condition for rust and
that the date stamp is current as every
gas cylinder in Australia must be pressure
tested every ten years.
• Never disconnect the gas supply from the
BBQ whilst it is running.
• DO NOT modify this appliance in any way.
• DO NOT allow children to operate the BBQ.
• If a grease/fat re should arise, turn
off the gas supply immediately until
extinguished.
• Always open the Lid or Roasting Hood
before lighting.
• DO NOT use an adapter at the cylinder
connection.
• DO NOT install in or connect to the
consumer piping or gas supply system of
a boat or caravan.
WARNING FOR YOUR SAFETY, IF YOU SMELL GAS
1. Shut off the gas supply to the appliance.
2. Extinguish any open ames.
3. Open lid or hood.
4. If odour continues, immediately call your gas supplier or your re
department.
HAZARDOUS FIRE OR EXPLOSION MAY
RESULT IF INSTRUCTIONS ARE IGNORED
It is the consumer’s responsibility to see that
the BBQ is properly assembled, installed and
taken care of. Failure to follow the instructions
in this manual could result in serious bodily
injury and /or property damage.
IMPORTANT SAFETY
INSTRUCTIONS AND WARNINGS
3
BBQ PARTS LIST
BBQ PARTS LIST
1x BBQ Body
1x Grease Tray Concealment Panel
(used in conjunction with Built-In Kits, Insulation
Jackets and Cabinet Trolley assemblies.)
1x Grease Tray
1x Control Valve
Adjustment
Screwdriver
1x Manual Lighting
Match Holder
1x Grill 1x Plate
1x Hose & Regulator
Large Flare GuardSmall Flare Guard
GTR BBQ GRIDDLE PLATE, GRILL & FLARE GUARD COMBINATIONS
GTRL1 GTRL2 GTRL3 GTRL4 GTRL5 GTRL6
Griddle Plate 160mm 320mm 240mm 320mm 400mm 400mm
or or + + + +
Grill 160mm 320mm 240mm 320mm 400mm 240mm
320mm
Small Flare
Guard 122234
Large Flare
Guard 011223
4 x
M6x35 Bolts
4 x
Bolt Spacer
Support
Left
Rear
RearFront
Front
Right
4
Phillips head screwdriver
TOOLS REQUIRED FOR ASSEMBLY
CHECK THE BBQ GAS TYPE
The Gas Type Label is located on the right
hand side of the BBQ front panel.
• Cut away any packaging or cable
ties that may be holding components
in place.
LPG (Propane Gas)
Natural Gas
ASSEMBLY INSTRUCTIONS
Please read all separate instructions on Assembly,
Installation and Operation of Built-In Kit, Insulation
Jacket, Cabinet Trolley, Roasting Hood, Flat Lid and
/ or Wok Burner if they are to be t to the BBQ.
The Built-In Kit is used for installations of the BBQ into
benchtops made from non-combustible material.
The Built-In Kit comprises two parts :
2 x 2.5mm tick stainless steel BBQ support angles
which allow the BBQ to be hung between two
benchtops and 2 x small brackets designed to
support the “Flip up” Grease Tray concealment
panel which needs to be bolted to the BBQ at the
base of the front panel.
Red Sticker
Black Sticker
OPTIONAL GTR BBQ BUILT-IN KIT
The built-in kit hides the grease tray from
sight which improves the overall look of the
installation.
The GTR BBQ can be installed without a
built in kit. The installation does not look as
tidy because the front panel protrudes out
from the benchtop but it allows the BBQ
to be installed into a cut out up to 35mm
narrower than the built-in kit allows.
The BBQ has a 20mm lip, on both sides of
the body. It is 20mm below the cooking
surface and can be used to support the
BBQ between two benchtops.
The built in kit is not to be installed onto a
tucker cabinet trolley or insulation jacket.
3. Tighten the bolts up so the support angles are
rmly attached to the sides of the BBQ and the
tops of the angles are still ush with the top of
the BBQ when nished.
1. Firstly bolt the support angles to each side of the
BBQ.
2. Line up the top of the angles with the top of the
BBQ and then line up the holes in the angles with
the holes in the sides of the BBQ.
Place a spacer between the BBQ and the angles
and then push the bolts through them both and
then screw the bolts into the sides BBQ body.
BUILT-IN KIT - BBQ SUPPORT ANGLE ASSEMBLY
2 x
Grease Tray
Fascia Brackets
2 x
Spacers
2 x
M4x10 Short Bolts
2 x
Washers
Left Right
5
ASSEMBLY INSTRUCTIONS
1. Attach the left and right brackets to the bottom
corners of the BBQ front panel.
Slide the brackets over the corners as per the
picture below and then bolt them into the BBQ
using the small bolts provided. The bolts do not
require any nuts as the holes in the BBQ are
pre-threaded.
2. Before attaching the grease tray concealment
panel remove the grease tray from the BBQ.
3. Remove the attachment bolts from the ends
of the concealment panel. Align the holes in
the ends of the panel up with the holes in the
brackets, place a spacer between the panel
and the bracket and then screw the bolts
through the sides of the bracket and into the
panel as per the picture below.
BUILT-IN KIT - GREASE TRAY CONCEALMENT
PANEL ASSEMBLY
DO NOT over tighten these bolts or you will
have trouble ipping up the panel.
6
ASSEMBLY INSTRUCTIONS
The Wok Trivet is used to support either a Wok or
Pot with a diameter of no less than 230mm.
The SSWL Wok burner can be optioned with a
Hinged Flat Lid or a Roasting Hood to protect it
from the weather when not in use.
BBQ ASSEMBLY
4. Once the grease tray concealment panel is
attached, ip it open and slide the grease tray
into the BBQ and then fold the panel back down.
1. Place the are guards into the BBQ. The are
guards are required only beneath the stainless
steel cooking grills.
The small are guards sit directly above the
burners and the large are guards sit between
the burners as per photos below.
2. Next place the stainless steel cooking grills into
the BBQ so that they are sitting directly above the
are guards and then place the hot plate next to
the grills.
3. If the BBQ has a wok burner integrated into the
body simply remove any cable ties securing the
wok and trivet and then place the trivet back
into position above the wok burner.
The GTR BBQ can be installed with either a Flat Lid
or a Roasting Hood to help protect the cooking
surfaces from the weather.
When you have nished the BBQ assembly and
installation, you can then t the lid or roasting hood
onto the BBQ.
DO NOT place the hot plate above the are guards
or it will not get hot.
7
OPTIONAL GTR BBQ
HINGED FLAT LID ASSEMBLY
OPTIONAL GTR BBQ
ROASTING HOOD ASSEMBLY
1. Remove the Flat Lid from its carton.
2. Place the Lid on top of the BBQ.
3. Slide the locating lugs, xed to the Lid hinges,
into the slots in the top of the BBQ.
4. When the lid is in position, secure the lid to the
BBQ using the 2 x phillips head bolts provided
into the 2 holes in the top of the BBQ.
1. Remove the hood from its carton and cut away
any packaging/ cable ties that may be securing
the handle, instructions, roasting rack, cooking
shelf and baking pan inside the hood.
2. Next, attach the handle to the front of the
roasting hood using a 10mm spanner to tighten
the nuts.
3. Now, simply place the roasting hood on top
of the BBQ.
4. Slide the front locating lugs in the base of the
roasting hood into the front slots in the top of the
BBQ and then lower the back of the roasting
hood down so the locating lugs in the back of
the roasting hood locate into the slots in the back
of the BBQ and you have the roasting hood
installed.
ASSEMBLY INSTRUCTIONS
The Roasting Hoods cooking shelf can then
be placed into the rear of the hood by
simply sitting it onto the locating pins in the
rear of the roasting hood.
The roasting rack and baking pan are
generally used when roasting and can be
stored away in a cupboard until needed.
For further instructions refer to the roasting
hood instruction manual.
8
LOCATION REQUIREMENTS
AND RESTRICTIONS
Read the important information on the
front panel of the BBQ.
This BBQ is designed and approved for
outdoor use only.
DO NOT use this appliance indoors or on
marine craft.
This appliance shall only be used in an above
ground, open-air situation with natural ventilation,
without stagnant areas where gas leakage and
products of combustion are rapidly dispersed by
wind and natural convection.
INSTALLATION INSTRUCTIONS
Any enclosure in which the appliance is used shall
comply with one of the following:
• An enclosure with walls on all sides, but at
least one permanent opening at ground level
and no overhead cover. (gure 1)
• Within a partial enclosure that includes an
overhead enclosure and no more than two
walls. (gure 2 and 3)
• Within a partial enclosure that includes an
overhead cover and more than two walls,
the following shall apply. (gures 4 and 5)
• At least 25% of the total wall area is
completely open.
• At least 30% of the remaining wall area is
open and unrestricted.
• In the case of balconies, at least 20% of the
total of the side, back and front wall areas
shall be and remain open and unrestricted.
9
INSTALLATION INSTRUCTIONS
FIGURE 2 - OUTDOOR AREA - EXAMPLE 2
FIGURE 3 - OUTDOOR AREA - EXAMPLE 3
Both ends open.
Two sides open.
FIGURE 4 - OUTDOOR AREA - EXAMPLE 4
FIGURE 5 - OUTDOOR AREA - EXAMPLE 5
Open side at least 25% of total wall area.
30% or more in total of the remaining wall area is
open and unrestricted.
Open side at least 25% of total wall area.
30% or more in total of the remaining wall area is
open and unrestricted.
DIAGRAMMATIC REPRESENTATIONS
OF OUTDOOR AREAS
FIGURE 1 - OUTDOOR AREA - EXAMPLE 1
The following gures are diagrammatic
representations of outdoor areas. Rectangular
areas have been used in these gures – the same
principles apply to any other shaped area.
This manual suits for next models
17
Table of contents
Other Tucker Barbecues Grill manuals
Tucker Barbecues
Tucker Barbecues GTR Series Assembly instructions
Tucker Barbecues
Tucker Barbecues GT Series Assembly instructions
Tucker Barbecues
Tucker Barbecues CHARCOAL DELUXE Assembly instructions
Tucker Barbecues
Tucker Barbecues GTR Series Assembly instructions
Tucker Barbecues
Tucker Barbecues S Wok Assembly instructions
Tucker Barbecues
Tucker Barbecues Horizon Assembly instructions
Tucker Barbecues
Tucker Barbecues GTR Series Instruction manual
