Tucker Barbecues GT Series Assembly instructions
V08.06.2021
ASSEMBLY, INSTALLATION
AND OPERATING INSTRUCTIONS
BUILT-IN BARBECUE
GT SERIES
MODELS: GT2, GT3, GT4, GT5
IMPORTANT – PLEASE READ ALL INSTRUCTIONS
BEFORE ASSEMBLING, INSTALLING OR OPERATING
THIS APPLIANCE
V08.06.2021
1
IMPORTANT SAFETY INSTRUCTIONS
ASSEMBLY INSTRUCTIONS
- BARBECUE ASSEMBLY
INSTALLATION INSTRUCTIONS
- SPECIFICATIONS
& DIMENSIONS
- GAS INSTALATION
OPERATING INSTRUCTIONS
- LIGHTING INSTRUCTIONS
- MANUAL LIGHTING INSTRUCTIONS
- NEW BARBECUE ‘BURNING IN’ PROCESS
- PRE-HEATING THE BARBECUE BEFORE COOKING
COOKING HINTS
- COOKING WITH YOUR BARBECUE
- CLEAN UP
TROUBLESHOOTING AND SOLUTIONS
SERVICE & MAINTENANCE
- TAKING CARE OF YOUR APPLIANCE
WARRANTY
- TUCKER GT BARBECUE WARRANTY
ADDITIONAL INFORMATION
- THE GT BUILT-IN KIT
2
3
6
14
16
17
19
20
21
CONTENTS
2
IMPORTANT SAFETY
INSTRUCTIONS
• Tucker GT Barbecues are approved for
outdoor use only.
• Remove all plastic protection lm from
stainless steel components before assembly.
• Keep this manual for future reference.
• Read all instructions carefully before
assembly and usage of barbecue.
• Clean the barbecue regularly. The grease
tray must be cleaned after each use. Excess
grease build-up may cause a re and
damage is not covered by warranty.
• Always turn off the gas supply when you
nish barbecuing.
• A canvas cover for this Barbecue will extend
its life and ensure trouble free operation.
• For installation of this Barbecue into a
cabinet trolley refer to the relevant Tucker
instructions.
• Attend an operating Barbecue at all times.
• Do not use this appliance indoors or in any
enclosed area.
• Do not spray aerosols in the vicinity of this
appliance while it is in operation.
• Do not place articles on or against
appliance.
• Do not use or store ammable materials in or
near this appliances.
WARNING FOR
YOUR SAFETY
If you smell gas:
1. Shut off appliance’s gas supply
2. Extinguish any open ames
3. Open lid or hood
4. If odour persists, immediately call your gas
supplier or re department
• Always leak test /check hose connections
after lling cylinders.
• Check cylinder condition for rust and that
the date stamp is current as every gas
cylinder in Australia must be pressure tested
every ten years.
• Never disconnect the Barbecue while it is
running.
• Do not modify this appliance in any way.
• Do not allow children to operate the
barbecue.
• If a grease/fat re should arise, turn off the
gas supply immediately until extinguished.
• Always open the lid or roasting hood before
lighting the Barbecue.
HAZARDOUS FIRE OR EXPLOSION MAY
RESULT IF INSTRUCTIONS ARE IGNORED.
It is the consumer’s responsibility to ensure
that the barbecue is properly assembled,
installed and taken care of. Failure to follow the
instructions in this manual could result in serious
bodily injury and/or property damage.
3
ASSEMBLY INSTRUCTIONS
• Remove the pallet and plastic lm covering parts
of the barbecue before assembly.
• Cut away cable ties or any other packaging that
may be holding components in place.
• Check you have all the correct components
listed below.
10mm spanner
Phillips head screwdriver
TOOLS REQUIRED FOR ASSEMBLY
*Check that you have the correct gas type barbecue
(i.e. LP gas has a red sticker, natural gas has a black
sticker). The gas type label is located on the right hand
side of the barbecue body.
BARBECUE PARTS
Ceramic Tile
Quantity
x4
Nuts, Bolts and Washers
(for Grease Tray)
x1
Control Valve
Adjustment
Screwdriver
x1 GT Barbecue Body x1 Cooking Grill & Plate
GT2 - 240mm Plate & Grill
GT3 - 320mm Plate & Grill
GT4 - 400mm Plate & Grill
GT5 - 400mm Plate, 320mm Grill
& 240mm Grill
GT2 - 1 Tray
GT3 - 2 Trays
GT4 - 2 Trays
GT5 - 3 Trays
GT2 - 5 Tiles
GT3 - 10 Tiles
GT4 - 10 Tiles
GT5 - 15 Tiles
x1
Grease Tray
x2
Grease Tray
Attachment Brackets
x1
Hose & Regulator
Tile Tray
4
Read the instructions on assembly, installation and
operation of the Tucker Roasting Hood, Flat Lid
and/or Wok Burner if they are to be tted to your
barbecue.
Mobile trolleys are optional. If you have one,
read the assembly instructions and t the
barbecue onto the trolley before nal barbecue
assembly.
ADDITIONAL GT BUILT-IN KIT
This kit is an optional upgrade, designed to t a ip up
fascia to the front of the BBQ to cover the grease tray
and the base of the BBQ from view. Check Page 21
1. Turn the barbecue upside down and bolt the drip
tray brackets onto the base of the barbecue.
2. Locate the tile trays above the burners using
the holes on the rear shelf to position the trays in
place.
BARBECUE ASSEMBLY
3. Now place the ceramic tiles into the tile trays,
5 tiles per tray.
5
5. Place the grease tray into the front of the
barbecue on the support rails in the base of the
barbecue.
Once you have assembled the barbecue,
wipe it over with some stainless steel polish
and a soft cloth. A little cooking oil on a
soft cloth also works to remove marks or
ngerprints from the BBQ. This also helps
protect the barbecue from tea-staining in
coastal conditions.
4. Place the cooking grills above the location of
the ceramic tiles and place the hot plate on the
other side.
You don’t need tiles under the solid
cooking plate.
6
INSTALLATION INSTRUCTIONS
INSTALLATION INSTRUCTIONS
READ THE IMPORTANT INFORMATION ON THE
RATING PLATE ON THE FRONT OF THE BARBECUE.
TUCKER GT BARBECUES ARE MADE AND APPROVED
TO AUSTRALIAN STANDARDS A.G.A. APPROVAL NO.
AGA 4136
The GT series barbecues are designed and
approved for outdoor use only.
To install the barbecue onto a GT trolley, read the
relevant manuals and instructions.
If a roasting hood is to be installed onto the
barbecue face the front of the BBQ into the
prevailing wind.
For LP Gas connections, an approved 2.75 kPa
regulator and hose assembly connection to the
appliance is tted by the manufacturer.
The appliance inlet is 3/8 S.A.E. male and is located
at the base of the barbecue on the front right hand
side, approximately 100mm in depth from the front
of the cooking grill and 60mm in from the front right
hand side, at the base of the barbecue.
The minimum capacity propane cylinder for this
barbecue is 4kg.
This barbecue is intended to be installed into a
Tucker GT Cabinet Trolley. Alternatively, it may be set
into brickwork. Regardless, be sensible about where
you locate the barbecue.
The barbecue must be located on rm and level
ground.
Do not locate the barbecue below or around
combustible materials or surfaces such as
overhanging trees, bushes or ammable liquids.
Do not obstruct any of the air ventilation openings at
the front of the barbecue.
Do not use this appliance indoors or on marine craft.
This appliance shall only be used in an above
ground, open-air situation with natural ventilation,
without stagnant areas where gas leakage and
products of combustion are rapidly dispersed by
wind and natural convection.
Strong winds blowing into the back or across
the back of the Roasting Hood while you are
cooking with the hood closed can cause the
barbecue to overheat. The Roasting Hood
vents at the rear top of the Roasting Hood.
Hot air inside the hood is released through this
vent when the hood is shut.
Hot air retained in the hood during cooking
may not be able to be released naturally
through the rear vent of the hood if a strong
wind is blowing into the back of the vent.
In freezing conditions, the pressure of propane
gas can decrease in the cylinder tank,
causing a lack of gas pressure which may
affect the way the barbecue operates.
Any enclosure in which the appliance is used shall
comply with one of the following:
• An enclosure with walls on all sided, but at least
one permanent opening at ground level and no
overhead cover (gure 1)
• Within a partial enclosure that includes an
overhead enclosure and no more than two walls
(gure 2)
• Within a partial enclosure that includes an
overhead cover and more than two walls, the
following shall apply (gures 3, 4 and 5):
(a.) At least 25% of the total wall area is
completely open
(b.) At least 30% of the remaining wall area is
open and unrestricted
• In the case of balconies, at least 20% of the total
of the side, back and front wall areas shall be
and remain open and unrestricted.
If your installation space differs, contact your
nearest dealer.
7
DIAGRAMMATICAL REPRESENTATIONS
OF OUTDOOR AREAS
FIGURE 1 – OUTDOOR AREA (EXAMPLE 1)
FIGURE 2 – OUTDOOR AREA (EXAMPLE 2)
FIGURE 3 – OUTDOOR AREA (EXAMPLE 3)
The following gures are diagrammatical
representations of outdoor areas. The areas used
in the gures below are examples – the same
principles apply to any other shaped area.
Both ends open
Both ends open
FIGURE 4 – OUTDOOR AREA (EXAMPLE 4)
Open side at least 25%
of total wall area
FIGURE 5 – OUTDOOR AREA (EXAMPLE 5)
30% or more in total
of the remaining wall
area is open and
unrestricted.
Open at side at least
25% of total wall area.
30% Or more in total of
the remaining wall area
is open and unrestricted
Open side at least 25%
of total wall area.
30% or more in total
of the remaining wall
area is open and
unrestricted.
8
BARBECUE GAS CONSUMPTION
(in megajoules per hour)
Model Natural Gas
(MJ/hr) LPG (MJ/hr)
GT2 27 27
GT3 41 41
GT4 54 54
GT5 68 68
Natural gas injector size: 1.6mm, Pressure 1kPa
Propane gas injector size: 1mm, Pressure
2.75 kPa
Wok Type Natural Gas
(MJ/hr) LPG (MJ/hr)
Integrated
S Wok/ST Wok 12.5 15
Natural gas injector size: 1.8mm, Pressure 1kPa
Propane gas injector size: 1.1mm, Pressure
2.75 kPa
B
A
320mm
255mm
565mm
610mm
715mm
515mm
9
DIMENSIONS OF GT BARBECUES
Model (A) (B)
GT2 535mm 500mm
GT3 700mm 660mm
GT4 857mm 820mm
GT5 1015mm 980mm
Manifold Location on BBQ
The GT BBQ Manifold location is found as follows:
60mm from the right hand side of the BBQ to the
centre of the manifold.
100mm from the front of the BBQ to the centre of the
manifold.
The Manifold diameter is a 20mm square tube.
The Gas inlet protrudes 10mm lower than the
BBQ Body.
NOTE
