TRENDnet 15-AH28B User manual

15-AH28B

Outdoor Internet Camera Server Housing

with Fan & Heater

Max Size Camera

Weight

Clear Window Area

Finish

Heater

Fan

Glass

Proposal

• L mm: 195 • W mm: 70 • H mm: 70

• 3mm

• Outdoor

• 2kg (4.55lb)

• Ø78

• Light Gray Powder – coating Body, Black End Caps

• Turn on at 5?±2?, Turn off at 10?±2?

• Turn on When Power in

• 90 ~ 230V AC

Housing Size

SPECIFICATIONS

Power Supply

Items

• L mm: 440 • W mm: 139 • H mm: 110

Housing Material • Aluminum

• Cable for camera can be run through centre of bracket for anti tamper protection

• Max Load: 10 kg.

• Construction: Steel

• Height: 230 mm

• Fixing: 4 screws

• Swivel Angle: 90ﾟ

• Tilt Angle: 120ﾟ

• Weight:4.7kg (10.5lb)

• Dimension:6.7 x3x48 cm (2.6 x1.2 x19 inches)

ORDERING INFORMATION

To Order Please Call:

1-888-326-6061

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web:

Email: [email protected]

www.trendnet.com

Heavy Duty Bracket

FEATURES

• Aluminum construction

• Additional heat insulation

• External use

• Require additional equipments for cable installation

Supported Models

• TV-IP201 / TV-IP201W

• TV-IP100 / TV-IP100W

• TV-IP301 / TV-IP301W

Ps. Cameras need to use the Camera’s own power adapter

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet

products and is subject to change at any time, without notice. For the most recent product information please visit

http://www.trendnet.com.

• Flip open top

• 2 Year Warranty
