TRENDnet TBW-103UB User manual

TBW-103UB

Quick Installation Guide

Table of Contents

(Version 01.10.2006)

English ......................................................................................................

Troubleshooting .........................................................................................

1. Before You Start

2. How to Install .....................................................................................

3. Using the Wireless Adapter ...............................................................

4. Using the Bluetooth Adapter ..............................................................

................................................................................

1. Windows 2000 or XP installed

2. One USB 1.1 port available

3. A CD-ROM Drive

System Requirements

1. Before You Start

English

802.11g Wireless & Bluetooth

Combo USB 2.0 Adapter

(TBW-103UB)

54Mbps 802.11g

Wireless Firewall Router

(TEW-432BRP)

Bluetooth Headset

High-Power Bluetooth

USB Adapter

(TEW-102UB)

USB Printer

54Mbps 802.11g Wireless

USB 2.0 Print Server

(TEW-P1UG)

Internet

wirelessbluetooth

Package Content

TBW-103UB

Utility CD-ROM

Quick Installation Guide

USB Cable

Note: Do not connect the Wireless USB Adapter to your computer until you

have finished installing the Utility and Driver.

2. How to Install

English

1. Insert the installation CD into your

CD-ROM drive and click 802.11g

WLAN Setup Driver.

2. Continue to click Next until you see

the window below.

Note: TRENDnet's Wireless Adapters have been fully tested under all

supported Windows Operating Systems and have been approved for their

functionality.

3. Click Continue Anyway or Click

Yes.

4. Click Finish.

5. Return to the software utility and

click Class 2 Bluetooth Setup

Driver.

English

7. Click Next for each installation

step, and select Yes, I want to

restart my computer now. Click

Finish.

6. Click OK.

8. Connect the TBW-103UB into your

computer's USB port.

English

9. Select No, not this time, and click

Next.

11. Click Next.

10. Select Install the software

automatically. Click Next.

Note: TRENDnet's Wireless Adapters have been fully tested under all

supported Windows Operating Systems and have been approved for their

functionality.

12. Click Continue Anyway or Click

Yes.

13. Click Finish.

14. After finalizing your software

installation, Restart your computer.

English

3. Using the Wireless Adapter

English

1. Double-click the wireless icon on

your system tray.

3. Please verify your connection

status.

2. Select 802.11g USB 2.0 WLAN

Dongle from the Network Adapter

drop down menu. Next double-

click the SSID you wish to connect

to within the Available Network

window.

4. Using the Bluetooth Adapter

English

1. Double-click the bluetooth icon on

your system tray.

3. Double-click the Bluetooth enabled

device. All available Bluetooth

services are highlighted in yellow

for your convenience. Double-click

the Bluetooth service you want to

enable.

2. Click the orange ball to search for

Bluetooth devices.

Note: For more detail on advanced features, please consult the User's Guide.

Your installation is now complete.
