Toto DONNA TX108LDN User manual

SPECIFICATIONS

OPERATING CONDITIONS

S06085ZZ

MAINTENANCE

Always wipe plated area with dry soft cloth, and

sometimes wipe it with cloth soaked in mild soap.

TROUBLESHOOTING

"DONNA"SINGLE LEVER LAVATORY FAUCET TX108LDN

CHECK

POINT

Flow rate unsatisfactory 1 Remove and clean

Water leaks around the body 2 Tighten

Handle is loose 3 Tighten

Plug cannot open and close 4 Tighten

Bodyswinging 5 Tighten

SOLUTION

PROBLEM

2. CONNECTING NUT

1. AERATOR

3. BOLT

4. BOLT

TX 108 LDN

"DONNA"SingleLever Lavatory Faucet

w/ 1¼" Pop-Up Waste

TX 108 LDV1

"DONNA"SingleLever Lavatory Faucet

w/o Pop-Up Waste

TX 108 LDV3N

"DONNA"SingleLever Lavatory Faucet

w/ 1¼" Pop-Up Waste & Copper Pipe

TX 108 LDV4

"DONNA"SingleLever Lavatory Faucet

w/ Copper Pipe w/o Pop-UpWaste

R12

Setting Bolt

Washer

Setting Nut

Packing

Lift Rod

Faucet

INSTALLATION

Bottom

Position

Open

Position

Plug

Siphon

Packing Triangle

Packing

Nut

Pivot Rod

Packing

Bolt

Kick Box

Bolt

Pop-Up Clip

Lavatory

Hole 35

Washer

ToCold

WaterSupply

ToHot

Water Supply

max.230 G½

46 38~51

Ø60

G1¼

114

330

max. 30

20°

112

44.5

G½

114

max. 30

20°

112

44.5

330

max.230

46 38~51

Ø60

G1¼

114

296

max. 30

20°

112

44.5

Ø9.5

114

296

max. 30

20°

112

44.5

Ø9.5

ATTENTION

Don t use abrasive cleaning material such as; detergents

containing hydrochloric acids, thinner, polishing powder,

and nylon brush.

As the product model is constantly updated, the actual

product may not look the same as it shown in the diagram,

but the basic installation principles are the same.

5. SETTING NUT

1. Water supply pressure : 0.05 ~ 0.75 MPa

2. Ensure that water supply is clean ( No Sand, Dirt, Etc )

SPESIFIKASI

KONDISI OPERASIONAL

S06085ZZ

PEMELIHARAAN

Selalu bersihkan area yang berlapis dengan kain lembut

kering, dan sesekali bersihkan dengan kain yang direndam

dalam sabun yang dicampur air.

PENYELESAIAN MASALAH

"DONNA"SINGLE LEVER LAVATORY FAUCET TX108LDN

Laju aliran tidak memuaskan 1 Lepas dan bersihkan

Air bocor disekitar bodi 2 Kencangkan

Handle longgar 3 Kencangkan

Plug tidak bisa membuka dan menutup 4 Kencangkan

Bodi goyah 5 Kencangkan

SOLUSI

MASALAH

POIN

PERIKSA

2. CONNECTING NUT

1. AERATOR

3. BOLT

4. BOLT

TX 108 LDN

"DONNA"SingleLever Lavatory Faucet

w/ 1¼" Pop-Up Waste

TX 108 LDV1

"DONNA"SingleLever Lavatory Faucet

w/o Pop-Up Waste

TX 108 LDV3N

"DONNA"SingleLever Lavatory Faucet

w/ 1¼" Pop-Up Waste & Copper Pipe

TX 108 LDV4

"DONNA"SingleLever Lavatory Faucet

w/ Copper Pipe w/o Pop-UpWaste

R12

Setting Bolt

Washer

Setting Nut

Packing

Lift Rod

Faucet

PEMASANGAN

Bottom

Position

Open

Position

Plug

Siphon

Packing Triangle

Packing

Nut

Pivot Rod

Packing

Bolt

Kick Box

Bolt

Pop-Up Clip

Lavatory

Hole 35

Washer

ToCold

WaterSupply

ToHot

Water Supply

max.230 G½

46 38~51

Ø60

G1¼

114

330

max. 30

20°

112

44.5

G½

114

max. 30

20°

112

44.5

330

max.230

46 38~51

Ø60

G1¼

114

296

max. 30

20°

112

44.5

Ø9.5

114

296

max. 30

20°

112

44.5

Ø9.5

PERHATIAN

Jangan gunakan bahan pembersih yang bersifat abrasif

seperti deterjen yang mengandung asam klorida, tinner,

bubuk polishing dan sikat nilon.

Karena model produk terus mengalami pembaharuan,

aktual produk mungkin tidak sama dengan gambar, tapi

prinsip dasar pemasangan adalah sama.

5. SETTING NUT

1. Tekanan sumber air: 0.05 ~ 0.75 MPa.

2. Pastikan kondisi sumber air adalah bersih (tidak ada pasir,

kotoran dan lain lain)
