Tiger TIGERFLEX MODA User manual

TIGERFLEX®

PENT

LOG CABIN

GENERAL ASSEMBLY

INSTRUCTIONS

TIG/INS39

BEFORE YOU GET STARTED

PLEASE READ INSTRUCTIONS CAREFULLY

• Check the pack and make sure you have all the parts listed.

• When you are ready to start, make sure you have the right tools at hand (not supplied).

• Ensure there is plenty of space and a clean dry area for assembly.

TIMBER

As with all natural materials, timber can be affected during various weather conditions. For the duration of heavy

or extended periods of rain, swelling of the wood logs may occur. Warping of the wood may also occur during

excessive dry spells due to an interior moisture loss. Unfortunately, these processes cannot be avoided but can

be mitigated. It is suggested that the outdoor building is sprayed with water during extended periods of warm

sunshine and sheltered as much as possible during rain or snow.

Please do not paint or treat your cabin timbers before assembly as they must stay dry for a snug tongue and

groove t. To validate your guarantee and ensure longevity of the product, it is ESSENTIAL that your building is

treated with a suitable wood preserver or paint AFTER assembly, both internally and externally.

BUILDING A BASE

Care must be taken to ensure the product is placed on a suitable base. When thinking about where the building

and base is going to be constructed, ensure that there will be access to all sides for maintenance work and annual

treatment.

Ensure the base is rm and level and is built on rm ground, to prevent distortion. Refer to diagrams for the base

dimensions.

The constructed base must be at least the size of tanalised oor bearers as referenced in supplied construct

diagram. It is also recommended that the oor be at least 25mm above the surrounding ground level to avoid

ooding.

TYPES OF BASE

• Durable plastic grid*.

• Concrete 75mm laid on top of 75mm hard-core.

• Slabs laid on 50mm of sharp sand.

• Timber base - Self constructed/Buy pre-made.

*We recommend a Fastt EcoBase for your building. It is durable, lightweight, exible, and easy to put in place.

Please see tigersheds.com for details.

WOOD WARPING

MAY OCCUR

WINTER

EXPANSION

SUMMER

CONTRACTION

02 tigersheds.com 0113 205 4189 [email protected]

PLASTIC BASE TIMBER BASE BROKEN SLABS BARE SOIL LOOSE GRAVELCONCRETE BASE SLAB BASE

Please retain instructions for future reference

CAUTION:

All buildings should be erected

by two competent adults.

CAUTION:

It is advisable to wear safety

gloves during building installation.

Whilst all products manufactured are made to the highest standards of safety, we cannot accept responsibility for your safety whilst erecting or

using this product.

GO WITH THE PRO!:

We understand how busy life can be. Our Pro-Installation service can take the stress and strain out of assembling your

quality Tiger building for you. We recommend using professional and dedicated installers to erect your building. With their

knowledge and experience, they will ensure that your cabin is put properly in place ready for you to enjoy your space for

years to come.

If you have not booked our Pro-Installation service and would like to arrange an installation, please contact our friendly

customer support team on 0113 205 4189 (Mon – Fri 9am-5pm) or email [email protected].

• The pro-install team will contact you to arrange a suitable time and date for the tting.

• Sit back, relax and let our professional home installation service do all the hard work for you!

• Please view our Pro Installation page on our website for full terms and conditions.

MADE IN THE UK SINCE 1913.

We have been making our high quality,

great value garden buildings here in

Britain for decades.

BEFORE YOU GET STARTED

04 tigersheds.com 0113 205 4189 [email protected]

TOOLS REQUIRED

We recommend using the following tools (not supplied):

SCREWDRIVER +

RUBBER MALLET DRILL LADDER TAPE MEASURE SHARP KNIFE SPIRIT LEVEL

ASSEMBLY

• Assembly is straightforward if you follow these step-by-step instructions.

• We recommend getting everything aligned properly before screwing together and that

screw holes should be pre-drilled to avoid splitting the timber. (Do not come pre-drilled).

IMPORTANT

• Before assembly, please make sure you have a suitable base ready to erect your building on.

• Your base MUST be level and at to ensure that the building is assembled properly and is square.

• Please carefully remove the untreated timber supports that make up the boxed pallet and unpack the components in

your delivery.

• DO NOT start your build until you have checked that all the parts of your building are present and in a suitable condition.

• If you are organising a third party to install your building, it is best practice not to schedule this immediately on receipt of

your order, to give you time to check your delivery.

HAMMER

WOOD SAW

C13

FIXING KIT CONTENTS:

Clout Nails (13mm Galvanised - QTY 80)

S25

Black Screws (25mm - QTY 16)

N30

Nails (30mm Galvanised - QTY 140)

N40

Nails (40mm Galvanised - QTY 20)

S35

Screws (35mm - QTY 192)

S40

Screws (40mm - QTY 24)

S80

Screws (80mm - QTY 18)

Please retain instructions for future reference

Unpacking supplied cabin.

• From the outside working in, cut banding holding all components together and remove the Module Packs.

NOTE: PARTS MAY HAVE BECOME LOOSE OR MOVED DURING TRANSPORTATION.

• Large items like doors and windows are screwed into cross brace. Remove screws as you come to

corresponding Module Pack to reduce the risk of falling components.

• All Module Packs are individually banded together. For ease, remove from vertical position on pallet and cut

Module Pack banding when on a dry, horizontal surface.

BUILDING PACK CONTENTS:

For full details of what should be included please see the Module Pack List that is supplied with the delivery. They

are also available on request in pdf form from our helpful Customer Support team – please call 0113 205 4189

for Customer Support or use the Items Delivered Query form at tigersheds.com/contact.

Cross Brace

FLOOR JOIST

INNER BEARER

FLOOR JOINTING

PIECE

OUTER BEARER

TIGERFLEX®PENT LOG CABIN GENERAL INSTRUCTIONS

06 tigersheds.com 0113 205 4189 [email protected]

Step 1:

FLOOR BEARER ASSEMBLY:

• Position oor bearers as shown.

• Assemble inner tanalised oor bearers & oor

joists using 4x S80. (Detail A)

• Use oor jointing piece as a guide for spacing

between inner tanalised oor bearers.

• Assemble outer tanalised oor bearer & oor

jointing piece using 4x S80. (Detail A)

6x6w FLOOR

12x6w FLOOR

8x6w FLOOR 10x6w FLOOR

14x6w FLOOR

18x6w FLOOR

S80 S80 S80 S80

Please retain instructions for future reference

Step 2:

FLOOR ASSEMBLY

(CHECK WHAT SIZE YOU HAVE AND THE MODULES SUPPLIED)

• Place half logs as shown.

• Secure to tanalised oor bearer through notch at end using 1x S40 per notch. (Detail B)

• Using a utility knife or similar, cut a slight notch in the top tongue of each half log and screw through log into

tanalised oor bearer using 1x S80 per cut notch. (Detail C)

S40 S40 S40

S80

TOP TONGUE

Step 3:

FLOOR ASSEMBLY

(REFERENCE MODEL IS 12X6 THE MODA 19MM TIGERFLEX LOG CABIN WITH DOOR ON GABLE END.)

• Take full logs and slot them into place as shown. Do not secure with screws.

• For 6x6 models, use 2x full logs.

• For 8x6, 10x6 & 12x6 models, use 3x full logs.

• For 14x6 & 18x6 models, use 4x full logs.

• Decide at this point where you would like your door to be positioned. If you plan to install the door on one of

the gable ends, place your rst oorboard at the door end chosen. This is referred to as the “Door Board”.

Leave approx. 2mm gap at the edges.

08 tigersheds.com 0113 205 4189 [email protected]

TIGERFLEX®PENT LOG CABIN GENERAL INSTRUCTIONS

Step 4:

FLOOR ASSEMBLY

(MODULE PACKS: H/J & Q*)

• Take 3 oorboards and tack in place as shown below using 5x N30 per oorboard.

NOTE: DO NOT FULLY SECURE AS THESE ARE ONLY TO KEEP THE FLOOR SQUARE

BEFORE INSTALLING REMAINING FLOORBOARDS.

• Align the inner oor bearers so that they are equally spaced across the oor.

*(No Q pack supplied with 6x6 Models)

N30

Please retain instructions for future reference

Step 5:

FLOOR ASSEMBLY

• Measure corner to corner diagonally to make sure cabin oor is square. If both values are equal, your frame

is square. Realign the oor until square. Do not trim.

Step 6:

FLOOR ASSEMBLY

(MODULE PACKS: H/J & Q*)

• From the “Door Board” (see Step 3) work your way across the frame, securing remaining oorboards

using 10x N30 per oorboard.

NOTE: YOU WILL NEED TO REMOVE THE 2 FLOORBOARDS AND LOGS

THAT WERE USED TO HOLD THE FRAME TOGETHER AS YOU COME TO THEM.

• Final oorboard may need to be trimmed. Measure as shown

and cut to size. (Detail D)

*(No Q pack supplied with 6x6 Models)

10 tigersheds.com 0113 205 4189 [email protected]

TIGERFLEX®PENT LOG CABIN GENERAL INSTRUCTIONS

Step 7:

POSITIONING OF DOORS & WINDOWS

• Lay out the module packs supplied in the position you would like them to be constructed. See examples for

some inspiration. All following instructions will be based on conguration shown below. Reference model is

12x6 The Moda 19mm TigerFlex Log Cabin with door on gable end.

B Q B

A Q A

B A
