Thetford ELECTRA MAGIC User manual

Because We Take Your Leisure Seriously

ELECTRA MAGIC®

Owner’s Manual

RV and Marine

Recirculating Toilets

Enfocus Software - Customer Support

Operating Instructions

1. Initial Flush Charge

A. Filluntilwaterreachesslightlyabove

thechargelevel(blueline)onindica-

tor dial.

B. Add Thetford Aqua-Kem®Liquid

Holding Tank Deodorant as per

instructions on package.

2. To Flush

Depress ush button. (Note: Do not

depress button when unit is empty.)

To Empty RV Model

The Electra Magic is tted with ater-

mination valve on the bottom of the

unit. Depending on the installation, follow one of these

procedures:

A. Without holding tank – attach discharge hose to outlet

and open termination valve.

B. With holding tank – open termination valve. This dumps

contents of unit into the holding tank.

To Evacuate Marine Model

See your boat owner’s manual.

Congratulations!

…on your purchase of Thetford’s Electra Magic recirculat

ing

toilet, the most popular recirculating toilet in the world.

This unit is a 100% self-contained sanitation system which

requires no pressure water connection or holding tank

installation (an optional holding tank may be installed to

increase total capacity). The Electra Magic is operated by

a simple D.C. hookup, available in a 12-Volt or a 24-Volt

model, and may be discharged directly into the sewer or

into an optional holding tank.

Unique Filtration

Thetford’s unique ltration system puts an end to unpleasant

clogging. The exclusive lter cone assures that only ltered

uid is delivered to the recirculating pump.

Any Questions…

about your toilet or this Owner’s Manual?

Simply call Thetford’s

Customer Relations Department at

1-800-521-3032

Enfocus Software - Customer Support

1-800-543-1219

RV Installation Instructions continue on Page 5.

Installation

RV Model

1. Install the two closet bolts in closet ange.

2. While holding bolt up so the head touches underside

of closet ange, install one nut on each bolt and screw

nuts down until they

touchtopofgauge.If

gauge is misplaced,

bottom surface of

nuts should be 1.34

in. (3.4 cm) above

oor.

5. Place unit on closet ange and locate position for plastic

locator disc by tracing around one of the front legs. Drill

5/32” dia. hole in oor and fasten disc to oor with at

sides oriented as shown. Use #10 screw provided.

Important: This disc prevents toilet from moving on

ﬂoor.

6. Lower toilet onto closet ange until nuts on closet bolts

go through rectangular holes in metal brackets, seal rests

on closet ange, and leg locates over locating disc.

Makesure white

fork-shaped

slides are in

forward posi-

tion.

3. Turn the toilet upside-down and install closetange seal

on Slide-EZ Valve with at side against toilet.

Electrical Hookup

RV and Marine Models

Connect your 12-Volt or 24-Volt model Electra Magic

directly to the appropriate D.C. source as a separate circuit.

Use minimum size #14 gauge wire. (Black wire to positive

[hot], white to negative [ground].)

Important – Be sure polarity of power supply has been

properly determined and correctly connected to lead wires

before operating.

Enfocus Software - Customer Support

MULTIPLE POSITIONS

SUMP DISCHARGE

Side Discharge Rear Discharge

Installation

Marine Model

CAUTION: Toilet is not explosion proof and must not be

located in an area where an explosive atmosphere exists,

such as gasoline fumes, etc.

1. Install white fork-

shaped slides on

brackets. Make one

right bracket as-

sembly and one left

bracket assembly.

(Right bracket assembly shown.)

2. Mount bracket assemblies and sump to bottom of toilet

with four screws. Brackets are sandwiched between sump

and toilet.

3. Locate toilet position with template and install bolts

in oor drilling 7/32” dia. hole in oor, putting acorn

nut on screw, and driving bolts into oor with wrench.

Remove acorn nuts.

4. Also using template, locate position for plastic locator

disc. Drill 5/32” dia. hole in oor and fasten disc to oor

with at sides oriented parallel to sides of toilet.

Important: This disc prevents toilet from moving on

ﬂoor.

5. Install one nut on each bolt and screw nuts down until they

touch top of gauge. If

gauge is misplaced,

bottom surface of nuts

should be 1.34 in. (3.4

cm) above oor.

6. Lower toilet over bolts until nuts go through rectangular

holes in metal brackets, and the unit rests on its feet.

Marine Installation Instructions continue on Page 5.

Enfocus Software - Customer Support

Installation Continued

RV and Marine Models

7. Insert a screwdriver or other long rigid instrument under

toilet. With a sharp blow drive each slide back until it

slides under nut and snaps into position.

8. If slides cannot be driven by one or two blows, remove

toilet and adjust each nut one-half turn upward and repeat

procedure from Step 6.

9. If toilet wobbles excessively, remove slides by catching

tabs with a hooked instrument and pulling forward, as

shown below. Lift toilet off, adjust each nut one-half

turn downward and repeat procedure from Step 6.

Extension Handle Valve

Toilet Model 24320 Only

Multiple positions using extension handle valve:

08707 Slide-EZ Valve

08737 Screw

02792 Lockwasher

08636 Mounting Bracket

03915 Screw

08737 Screw

02792 Lockwasher

08707 Slide-EZ Valve

08636 Mounting Bracket

12979 Base Moulding

05248 Base Moulding

03915 Screw

Enfocus Software - Customer Support

Parts List

RV and Marine Models (12- and 24-Volt Models

are available.)

Product ID Label

Key Part

No. No.Description

1 039

21 Hinge Pin (2)

2 03922 Retaining Ring (2)

3 03916 Seat Cover Assy.*

4 08166 Lid Seal

5 03953 Left Hinge*

6 03904 Seat & Bumper Assy.*

7 03936 Cap*

8 05656 Splash Guard

9 03912 Cover & Bowl Assy.*

10 03984 Vinyl Skirt Assy.

11 03946 Inlet Tube

12 12938 Left Side Base

Moulding*

13 12979 Base Moulding w/

Hole*

14 08167 Main Housing Seal

15 1284057Main Housing Assy.*

16 03943 Front Screw (2)

17 03923 Cover Mtg. Screw (2)

18 03924 Motor Cover Assy.*

Key Part

No. No. Description

19 03905 Right Hinge*

20 03927 Nut (4)

21 03990 Lock Washer (4)

22 03979 Rear Screw (2)

23 24615 Level Indicator

24 03937 Hinge Mtg. Screw (2)

25 03928 Pump Mtg. Gasket

26 03925 Pump Mtg. Screw (4)

27 05700 Motor Kit: 12 Volt

14082 Motor Kit: 24 Volt

28 05534 Filter Cone

29 03950

Pump Assy.: 12 Volt**

14083 Pump Assy.: 24 Volt**

30 05248 Right Side Base

Moulding*

31 03915 Moulding Mtg. Screw

(2)

** Includes Motor

*Indicate Color When Ordering

Enfocus Software - Customer Support

RV Slide-EZ Valve

Key Part

No. No. Description

1 12836 Slide-EZ Valve

2 03911 Handle*

3 03913 Retaining Ring

4 08637 Slides (2)

5 08737 Screw (4)

6 24304 Flange Seal

7 02690 Nut (2)

8 12525 Closet Bolt (2)

9 08636 Mtg. Bracket (2)

10 12838 Mounting Package

(comprised of Key

Parts 4-9)

Note: Slide-EZ Valve No. 03632 is

used on pre-1978 toilets. Toilets

manufacturedin1978 or laterusean

ABS-Slide EZ Valve No. 12836.

Record Your Product ID Information Here

MODEL :

PART NO :

CODE :

(See Parts List on Pg. 6 for location

of Product ID Label)

(For Service/Part info, call 1-800-521-3032)

Key Part

No. No. Description

1 03940 Sump Assy.

2 08637 Slides (2)

3 01663 Screw (4)

4 12984 Acorn Nut (2)

5 12983 Bolt (2)

6 08636 Mtg. Bracket (2)

7 05063 Mounting Package

(comprised of Key

Parts 2-6)

Enfocus Software - Customer Support

1-800-543-1219)

Disassembly

RV and Marine Models

1. Fuse Replacement

A. Remove two (2) #03923 cover mounting screws and

#03924 Motor Cover Assembly.

B. The fuse is now readily accessible for checking or

changing.

2. Switch Removal

A. Disconnect lead wires from power source.

B. Remove two (2) #03923 cover mounting screws and

#03924 Motor Cover Assembly.

C. Remove switch retaining nut and remove wires from

switch terminals.

3. Slide-EZ Valve Removal

A. Disconnect lead wires from power source.

B. Completely evacuate unit.

Note: Ifyouhavea#24320extensionhandleunit,cotterpin

and extension handle must be removed at this point.

C. Remove two (2) #03915 moulding mounting screws and

remove two (2) base mouldings (See Pg. 6).

D. Removeslidesbycatchingtabswith ahookedinstrument

and pulling forward (Pg. 5).

E. Lift toilet from closet ange and invert unit.

Remove four (4) #08737 screws; remove valve (Pg. 5).

4. Sump Removal

A. Disconnect lead wires from power source.

B. Completely evacuate unit.

C. Remove two (2) #03915 moulding mounting screws and

remove two (2) base mouldings (Pg. 6).

D. Removeslidesbycatchingtabswith ahookedinstrument

and pulling forward (Pg. 5).

E. Remove exible hose from sump and invert unit.

Remove four (4) #01663 screws; remove sump (Pg. 7).

5. Pump Removal

A. Complete steps 2A and 2B above.

B. Completely evacuate unit.

C. Removecoverandbowlassemblyscrewstwo(2)#03979

in rear from top side and two (2) #03943 in front from

bottomsideandremove#03912coverandbowlassembly

(Pg. 6).

D. Remove four (4) #03925 pump mounting screws.

E. Disconnect #03946 inlet tube from pump outlet.

F. Remove #03950 pump assembly (Pg. 6).

Enfocus Software - Customer Support

Service Parts

For parts and/or service – including those under warranty

– contact a local Thetford Certied Service Center (CSC),

or a RV or Marine Dealer. Or, call Thetford’s Customer

Relations Department for information at 1-800-521-3032.

For warranty consideration, parts must be sent to Thetford.

Call 1-800-521-3032 for a Returned Goods Authorization

Number before sending it in. When you call have this

information available:

1. Your name and address.

2. The toilet Model, Part No. and Code (located on the ID

label on the front of the toilet).

3. Reason for return.

4. Date of vehicle/toilet purchase.

REFILL PKG. #03947

Chrome-plated rell adapter

connects Electra Magic

directly to vehicle or ves-

sels demand water supply.

Opening rell valve allows

easy toilet recharging and

cleaning.Eliminatesneed for

manually adding recharge

water.

VENT KIT #05223

(Included in Model

#24330)

Provides extra vent-

ing to reduce odors.

Primarily for marine

use.

Accessories

Enfocus Software - Customer Support

1-800-543-1219.

1-800-543-1219

Maintenance

To clean unit, use Thetford’s Aqua-CleanTM or other

high grade, non-abrasive cleaner. DO NOT use highly

concentrated or high-acid content household cleaner, nor

those containing abrasive, such as cleaning or scouring

powder. These may damage the seals or the plastic parts

of the toilet.

Storage

A. Completelyevacuate unitasdescribed

under Operating Instructions.

B. Rell unit to bottom of bowl with

fresh water.

C. Add a cup (8oz./236.56 cc) of Aqua-

CleanTM.

D. Cycle three times by depressing ush

button for 10 seconds each.

E. Let stand a few minutes for cleaning

action.

F. Completely evacuate unit again.

Winter Use/Winterizing

For winter use, replace one-half of the charge water with

an approved RV anti-freeze. For winter storage, completely

evacuate unit.

Speciﬁcations

RV and Marine Models

Capacity: 6.2 Gallons (23.5 liters)

Model #24330 United States Coast Guard Certication

Number: 159.015/1804/0 (for inspected and uninspected

vessels).

Enfocus Software - Customer Support

Table of contents

Other Thetford Plumbing Product manuals

Thetford

Thetford 51802 Setup guide

Thetford

Thetford Style Plus Lite & II 34122 User manual

Thetford

Thetford 2384978 Setup guide

Thetford

Thetford Sani-Con User manual

Thetford

Thetford Aqua-Magic 33186 User manual

Thetford

Thetford 23709 Setup guide

Thetford

Thetford Aqua-Magic V User manual

Thetford

Thetford SmartTote User manual

Thetford

Thetford Sani-Con Turbo User manual

Thetford

Thetford 33226 User manual

Thetford

Thetford Aqua-Magic 34120 User manual

Thetford

Thetford Sanicon Turbo 500 User manual

Thetford

Thetford Aqua-Magic STYLE PLUS User manual

Thetford

Thetford EasyFit User manual

Thetford

Thetford 100 Series User manual

Thetford

Thetford 19833 User manual

Thetford

Thetford XR17200 User manual

Thetford

Thetford C500 User manual

Thetford

Thetford 92909 Series Setup guide

Thetford

Thetford Tecma Silence 2G-RV User manual

Popular Plumbing Product manuals by other brands

Weka

Weka 506.2020.00E ASSEMBLY, USER AND MAINTENANCE INSTRUCTIONS

Kohler

Kohler K-6228 Installation and care guide

UBERHAUS DESIGN

UBERHAUS DESIGN 75175017 Operator's manual

American Standard

American Standard DetectLink 6072121 manual

Uponor

Uponor Contec TS Mounting instructions

Pfister

Pfister Selia 49-SL Quick installation guide

Fortis

Fortis VITRINA 6068700 quick start guide

Fortis

Fortis MILANO 78211JS installation instructions

Kohler

Kohler K-12183 Homeowner's guide

Maxxus

Maxxus MX-M206-01 instruction manual

Moen

Moen 5922 Series installation instructions

Viega

Viega Prevista Pure 8512 Instructions for use

Kohler

Kohler Centerset K-15240 Homeowner's guide

Viega

Viega Prevista Dry 8522.33 Instructions for use

Sanela

Sanela Lema SLP 59RB Instructions for use

Elkay

Elkay EDF15AC Installation, care & use manual

Hans Grohe

Hans Grohe AXOR Citterio E 36702000 Instructions for use/assembly instructions

baliv

baliv WT-140 manual
