Teltonika RUT850 User manual
1
USER MANUAL
RUT850 LTE Router
2
Legal notice
Cll rights reserved. Reproduction, transfer, distribution or storage
of part or all of the contents in this document in any form without the prior written permission of
TELTONIKA Ltd is prohibited. The manufacturer reserves the right to modify the product and manual
for the purpose of technical improvement without prior notice.
Other product and company names mentioned herein may be trademarks or trade names of
their respective owners.
Attention
Before using the device we strongly recommend reading this user manual first.
Do not rip open the device. Do not touch the device if the device block is broken.
All wireless devices for data transferring may be susceptible to interference,
which could affect performance.
The device is not water-resistant. Keep it dry.
Device is powered by low voltage +9V DC power adapter.
Please do not scratch the device. Scratched device is not fully protected.
3
Safety information
The RUT850 router must be used in compliance with any and all applicable national and international
laws and with any special restrictions regulating the utilization of the communication module in
prescribed applications and environments.
You have to be familiar with the safety requirements before using the device!
Specifications
Software
RUT850_R_XX.XX.XXX
Frequency bands*
EEE802,11b/g/n 2400 MHz, GSM/3G/4G, UMTS/HSPA+
Max. RF power
20 dBm@WiFi, 33 dBm@GSM/GPRS/EDGE, 24 dBm@LTE/WSDMA
Representative accessories specifications
Power
AC/DC power adapter 9 V 1 A, or Cigarette plug socket, or 12/24 V battery, 4
pin plug
GSM/WCDMA/LTE antenna
703-960/1710-1990/2110-2170/2500-2690 gain** 1
dBi, omnidirectional, vertical polarization, Fakra-D plug
GPS antenna
1561-1615 , active total gain** 18dBi (typ.), linear
polarization, Fakra-C plug
* Supported frequency bands are dependent on geographical location and may not be available in all markets.
** If an extension cable is used to attach the antenna, the antenna gain may be higher by the amount of cable
attenuation. The user is responsible for the compliance with the legal regulations.
4
To avoid burning and voltage caused traumas, of the personnel working with the device, please
follow these safety requirements:
The device is intended for supply from a Limited Power Source (LPS) that power
consumption should not exceed 15VA and current rating of over current protective
device should not exceed 2A.
The highest transient over voltage in the output (secondary circuit) of used PSU shall
not exceed 36V peak.
The device can be used with the Personal Computer (first safety class) or Notebook
(second safety class). Associated equipment: PSU (power supply unit) (LPS) and
personal computer (PC) shall comply with the requirements of standard EN 60950-1.
Do not mount or service the device during a thunderstorm.
To avoid mechanical damages to the device it is recommended to transport it packed
in a damage-proof pack.
Protection in primary circuits of associated PC and PSU (LPS) against short circuits
and earth faults of associated PC shall be provided as part of the building
installation.
To avoid mechanical damage to the device it is recommended to transport it packed in a damage-
proof pack. When using the device it should be placed so that its indicating LEDs would be visible as
they inform in which working mode the device is in and if it has any working problems.
Protection against over current, short circuiting and earth faults should be provided as a part of the
building installation.
Signal level of the device depends on the environment in which it is working in. In case the device
starts working insufficiently, please refer to qualified personnel in order to repair this product. We
recommend forwarding it to a repair center or the manufacturer. There are no exchangeable parts
inside the device.
5
Introduction
Thank you for purchasing a RUT850 automotive LTE router! RUT850 is a compact mobile router with
a high speed wireless connection.
share their internet on the go or in a vehicle, as it is not
restricted by a cumbersome cable connection.
For in-depth information on how to use and configure a RUT850 router, visit our wiki page:
http://wiki.teltonika.lt/index.php?title=RUT850
Hardware installation
1. Push the SIM holder with the SIM needle.
2. Pull out the SIM holder
3. Insert your SIM card into the SIM holder
4. Slide the SIM holder back into the router.
5. Attach LTE and GPS antennas.
6. Connect the power adapter to the socket on the back of the device. Then plug the other end of
the power adapter into the power socket.
7. Connect to the device wirelessly (SSID: RUT850_001E42 ****** (unique to each device)).
6
Front and back panels
Front view
1. Power LED
2. SIM holder
3. Reset button
4. WiFi LED
5. Mobile network type LEDs
6. Mobile signal strength indication LEDs
Back view
1. Power socket
2. GPS antenna connector
3. LTE antenna connectors
7
Configure your computer (Windows)
1. E
Enable the wireless network connection (go to Start >
Control Panel > Network and Internet > Network and
Sharing Center. In the left panel click Change adapter
settings link. Right click on Wireless Network
Connection and select Enable).
2. Setup the wireless network adapter on your computer
(right click on Wireless Network Connection and select
Properties). After that select Internet Protocol Version
4 (TCP/IP) and click Properties).
3. Select Obtain IP address automatically and Obtain
DNS server address automatically if they are not
selected. Click OK.
4. Right click on Wireless Network Connection
and click Connect to see available wireless
networks.
5. Choose the wireless network RUT850_001E42
****** from the list and click Connect.
8
Login to device
1. To enter the routers Web interface type http://192.168.1.1 into your internet browser
2. Use the following parameters when prompted for authentication:
3. Configuration Wizard will start after logging in. It is necessary to complete Configuration Wizard
to setup the router to the correct mode. You can leave default settings but it is strongly
recommended that you change the default password and enable Wireless Security.
4. Go to Status > Network information and pay attention to Signal Strength. To maximize the
performance try adjusting the antennas or changing the location of your device to achieve the
best signal conditions:
9
LED indications
constant blinking every 500 ms: Router is turning on
Wi-Fi LED turned ON/OFF: Wi-Fi Enabled/Disabled;
2G, 3G and 4G LEDs constant blinking every 1 sec: No SIM or bad PIN
One of 2G, 3G or 4G LEDs blinking every 1 sec: Connected to 2G, 3G or 4G respectively
but no data session established
Blinking from 2G LED to 4G LED repeatedly: SIM holder not inserted
One of 2G, 3G or 4G LEDs turned on: Connected to 2G, 3G or 4G respectively with data
session
One of 2G, 3G or 4G LEDs blinking rapidly: Connected to 2G, 3G or 4G respectively with
data session and data is being transferred
Signal strength LEDs
No. of lit up LEDs
Signal strength value
0
-111 dBm
1
-110 dBm to -97 dBm
2 -96 dBm to -82 dBm
-96 dBm to -82 dBm
3
-81 dBm to -67 dBm
4
-66 dBm to -52 dBm
5
-51 dBm
10
Specifications
Wi-Fi
IEEE 802.11b/g/n WiFi standards
AP and STA modes
WPA2-Enterprise - PEAP, TLS, TTLS, AES-CCMP, TKIP, Auto Cipher modes, Client separation
2.401 –2.495GHz Wi-Fi frequency range*
20dBm max WiFi TX power
SSID stealth mode and access control based on MAC address
Hardware
High performance 550 MHz CPU with 64 Mbytes of DDR2 memory
External SIM holder
4 pin DC connector
Reset/restore to default button
2 x RG174 connectors for LTE
1 x RG174 connector for GPS
3 x connection type status LEDs, 1 x r WiFi status LED, 5 x connection strength LEDs, 1 x Power LED
Electrical, Mechanical & Environmental
Dimensions (W x D x H) 131 mm x 79 mm x 18 mm
Weight 115g
Input voltage range 9 –30VDC
Power consumption < 5W
Operating temperature -40°to 75°C
Operating humidity 10% to 90% Non-condensing
*Supported frequency bands are dependent on geographical location and may not be available in all markets
