Swann Wireless OutdoorCam SW231-WCX User manual

NightHawk™

Extra Wireless

Outdoor Camera

with Night Vision

www.swannsecurity.com

Enquiries: [email protected]

Product Code: SW231-WOX

Wireless Surveillance

• 380 TV Lines for clear image resolution

• 16ft (5m) infra red night vision

• Wireless 2.4GHz transmission over 100 - 150ft (30 - 50m)*

• Sturdy weather resistant casing for outdoor use

• Top selling home & office wireless video camera depending on local conditions

WIRELESS

Warranty

month

* Depending on local conditions

Color when Sheltered

Weather Resistant

Sees in the Dark

Up to 16ft (5m)

www.swannsecurity.com

Please note that the information

contained within this document is

subject to change without notification.

Product Specifications

Create your own security solution:

- Add to the Swann NightHawk Wireless Outdoor Camera (SW231-WOC) or

MicroCam II (SW232-M2A) for a DIY wireless surveillance solution with no cabling required

- Ideal addition to an existing wireless security solution

Place the camera anywhere within reception range up to 100 -150ft (30 - 50m)*

- Under the eaves around the house

- Monitor the pool, yard, entrances, garage and driveway

- Protect your business, store or warehouse

Mains power adapter included

Camera Specifications:

• Image Sensor: 1/3” CMOS (8.5mm)

• Video Format: NTSC (USA); PAL (AU, UK, EU)

• CMOS Total Pixels: 628 x 582 pixels (PAL);

510 x 492 pixels (NTSC)

• Minimum Illumination: 0 Lux (Infra red)

• Horizontal Resolution: 380 TV Lines

• Frequency: 2.4GHz

• Output Power: 10mW (3mW in USA)

• Power Supply: +8VDC

• Power Consumption Current: 65mA/105mA (IR ON)

• Operation Temperature: 32°F - 113°F (0°C - 45°C)

• Operation Humidity: 85% RH

• Dimensions (W) x (L) x (H): 2” x 13/4” x 2½” (53 x 43.5 x 64mm)

• Weight: 7oz (197g)

• Unobstructed Effective Range: 330ft/100m line of sight

NightHawk™

Extra Wireless Outdoor Camera

with Night Vision

WIRELESS

Package Contents

• NightHawk 2.4GHz Wireless Color Camera

• 1 x Power Adapter

• 1 x 9V Battery Adapter

• Quickstart Manual

Note: IP ratings stated on the front panel are for cameras only.

* Actual transmission range may vary according to location, interference & building construction.

How the extra camera works:

Antenna

Power Adapter

Separate Wireless Receiver

Extra

SW231-WOC Extra Camera
